RECEIVER DRIER
The receiver drier is mounted on the condenser RH end tank and removes solid impurities and moisture from the refrigerant. It also provides a reservoir for liquid refrigerant to accommodate changes of heat load at the evaporator.
Note. The receiver drier is part of the condenser assembly and is not serviceable separately.
Refrigerant entering the receiver drier passes through a filter and a desiccant pack, then collects in the base of the unit before flowing through the outlet pipe back to the condenser.
Scheme 18
The refrigerant pressure sensor is located in the high pressure/temperature refrigerant line between the condenser and the thermostatic expansion valve. Refer to Control Components article.
Scheme 19
| Item Number | Description |
|---|---|
| 1 | Metering valve |
| 2 | Housing |
| 3 | Diaphragm |
| 4 | Temperature sensor |
| 5 | Outlet passage from evaporator |
| 6 | Inlet passage to evaporator |
The thermostatic expansion valve meters the flow of refrigerant into the evaporator, to match the refrigerant flow with the heat load of the air passing through the evaporator.
The thermostatic expansion valve is a block type valve located behind the heater assembly, and attached to the inlet and outlet ports of the evaporator. The thermostatic expansion valve consists of an aluminum housing containing inlet and outlet passages. A ball and spring metering valve is installed in the inlet passage and a temperature sensor is installed in the outlet passage. The temperature sensor consists of a temperature sensitive tube connected to a diaphragm. The bottom end of the temperature sensitive tube acts on the ball of the metering valve. Pressure on top of the diaphragm is controlled by the evaporator outlet temperature conducted through the temperature sensitive tube. The bottom of the diaphragm senses evaporator outlet pressure.
Liquid refrigerant flows through the metering valve into the evaporator. The restriction across the metering valve reduces the pressure and temperature of the refrigerant. The restriction also changes the liquid stream of refrigerant into a fine spray, to improve the evaporation process. As the refrigerant passes through the evaporator, it absorbs heat from the air flowing through the evaporator. The increase in temperature causes the refrigerant to vaporize and increase in pressure.
The temperature and pressure of the refrigerant leaving the evaporator acts on the diaphragm and temperature sensitive tube, which regulate the metering valve opening and so control the volume of refrigerant flowing through the evaporator. The warmer the air flowing through the evaporator, the more heat available to evaporate refrigerant and thus the greater volume of refrigerant allowed through the metering valve.
Scheme 20
The evaporator is installed in the heater assembly, between the blower and the heater matrix, to absorb heat from the exterior or recirculated air. Low pressure, low temperature refrigerant changes from liquid to vapor in the evaporator, absorbing large quantities of heat as it changes state.
Most of the moisture in the air passing through the evaporator condenses into water, which drains out of the vehicle by passing through a drain tube to the underside of the vehicle.
REFRIGERANT LINES
To maintain similar flow velocities around the A/C system, the diameter of the refrigerant lines varies to suit the 2 pressure/temperature regimes. Larger diameter pipes are installed in the low pressure/temperature regime and smaller diameter pipes are installed in the high pressure/temperature regime.
Low and high pressure charging connections are incorporated into the refrigerant lines for system servicing.
Scheme 21
| Item Number | Description |
|---|---|
| 1 | Evaporator |
| 2 | Thermostatic expansion valve |
| 3 | High pressure servicing connection |
| 4 | Refrigerant pressure sensor |
| 5 | Engine cooling fan |
| 6 | Condenser |
| 7 | Receiver/Drier |
| 8 | Variable displacement A/C compressor |
| 9 | Low pressure servicing connection |
| 10 | Blower |
Note. A = Refrigerant liquid; B = Refrigerant vapor; C = Air flow
