Multifunction Electronic Modules: Removal & Installation Jaguar XF I

Communication Devices 2 illustrations ~143 words

INSTALLATION

  1. To install, reverse the removal procedure.
  2. If a new component has been installed, configure using Jaguar approved diagnostic equipment.

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Scheme 11

Scheme 11: REMOVAL
Scheme 11: REMOVAL
  1. Make the air bag supplemental restraint system (SRS) safe. Refer to «Standard Workshop Practices»(ref-568389-S00771621212013072200000) information.
  2. Refer to «Front Seat»(ref-568428-S22610106892013072200000) information.
  1. To install, reverse the removal procedure.
  2. If a new component has been installed, configure using Jaguar approved diagnostic equipment.

Note. Removal steps in this procedure may contain installation details.

  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Refer to «Front Door Trim Panel»(ref-568405-S17125890272013072200000) information.
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 12

Scheme 12: REMOVAL
Scheme 12: REMOVAL
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Refer to «Rear Door Trim Panel»(ref-568405-S08079644482013072200000) information.
  3. Torque: 1.5 Nm
  1. To install, reverse the removal procedure.
