CONTROL DIAGRAM

Control Diagram - Lin Bus - Sheet 1 Of 2

Item Number	Description
O = local interconnect network (LIN) bus
1	Central junction box (CJB)
2	Battery backed sounder
3	Intrusion detection module
4	Rain/Light sensor
5	Rear junction box (RJB)
6	Battery monitoring system module
7	Rear view camera
8	Transmission control module (TCM)
9	Generator
10	Driver's door switch pack
11	Rear door control module
12	Driver's door control module
13	Engine control module (ECM)
14	Electronic transmission selector
15	Driver's seat module
16	Driver's seat switch pack
17	Rear door control module
18	Front passenger door control module
19	Clockspring
20	Audio and telephone steering wheel switches
21	Instrument cluster
22	Start control module

Control Diagram - Lin Bus - Sheet 2 Of 2

Item Number	Description
O = local interconnect network (LIN) bus
1	Automatic temperature control (ATC) module
2	Stepper motor - Windshield defrost
3	Stepper motor - Face/feet distribution
4	Stepper motor - left-hand (LH) temperature blend
5	Stepper motor - right-hand (RH) temperature blend
6	Electric booster heater
7	Stepper motor - right-hand (RH) outer face level vent
8	Stepper motor - right-hand (RH) inner face level vent
9	Stepper motor - left-hand (LH) inner face level vent
10	Stepper motor - left-hand (LH) outer face level vent

Control Diagram - Medium Speed Can Bus

Item Number	Description
N = Medium speed controller area network (CAN) bus
1	Parking aid module
2	Rear junction box (RJB)
3	Keyless vehicle module
4	Right-hand (RH) blind spot monitoring module
5	Driver's seat module
6	Front seat climate control module
7	Information control module
8	Automatic temperature control (ATC) module
9	Central junction box (CJB)
10	Diagnostic socket
11	Instrument cluster
12	Integrated control panel
13	Front passenger door control module
14	Tire Pressure Monitoring System (TPMS) module
15	Driver's door control module
16	Left-hand (LH) blind spot monitoring module

Control Diagram - High Speed Can Bus

Item Number	Description
D = High speed controller area network (CAN) bus
1	Electric steering column lock
2	Instrument cluster
3	Diagnostic socket
4	Adaptive speed control module
5	Electronic transmission selector
6	Occupant classification system control module
7	Headlamp leveling module
8	Anti-lock brake system (ABS) module
9	Engine control module (ECM)
10	Transmission control module (TCM)
11	Pedestrian protection system control module
12	Electric park brake module
13	Restraints control module (RCM)
14	Adaptive damping control module

Control Diagram - Most Ring

Item Number	Description
P = MOST ring
1	Entertainment system control module
2	Software download socket
3	Touch Screen Display (TSD)
4	Portable audio interface
5	Bluetooth® telephone module
6	Integrated audio module
7	Multi-media module
8	DAB/SDARS receiver
9	Television (TV) tuner
10	Audio system amplifier

CAN Network Integrity Checks

In the event that one or more control modules are not communicating on either the Medium Speed (MS) or High Speed (HS) CAN Buses, checks can be performed to confirm the integrity of the CAN harness.

The following information is applicable to HS and MS CAN Buses accessible via the J1962 diagnostic connector.

Module Connections to the CAN Harness

Modules are connected to the CAN harness either in a 'loop' or 'spur' configuration. In the 'loop' type configuration the CAN harness loops into the module (via two connector pins) and then loops out of the module (via another two connector pins). In the 'spur' type configuration, a harness spur is spliced into the main 'backbone' of the CAN harness and the module is connected to the harness spur via two connector pins.

CAN Harness Architecture

For a detailed description of the CAN Networks and architecture, refer to OVERVIEW and SYSTEM OPERATION AND COMPONENT DESCRIPTION .

IDS Vehicle Integrity Test

If a control module is suspected of non-communication, the Network Integrity test application available on the manufacturer approved diagnostic system can be used to confirm if communication is possible between the control modules on the vehicle and the manufacturer approved diagnostic system (via the J1962 diagnostic connector). The results from the test can be used to determine if either a single module or multiple modules are failing to communicate.

CAN Terminating Modules

If the Network Integrity test indicates that one or more module on one of the CAN networks (HS or MS) are failing to communicate, there are several checks that can be made. The first step is to identify if both of the CAN terminating modules on each individual CAN Bus are communicating. If both CAN terminating modules for each individual CAN Bus are communicating (identified via the Network Integrity test), then it can be confirmed that the main 'backbone' of the CAN harness is complete. The main 'backbone' of the CAN harness consists of all the modules connected to the CAN harness via a 'loop' configuration and also includes the two terminating modules.

Communication with both CAN terminating modules via the Network Integrity test confirms the physical integrity of the main 'backbone' of the CAN harness (and the harness spur to the J1962 diagnostic connector). This means that there is no requirement to check the resistance of the CAN Network. This is because the standard check for 60 ohms across the CAN High and CAN Low lines will not provide any additional information regarding the physical condition of the CAN harness, beyond what has already been determined from the Network Integrity test.

Non-Communication of a Terminating Module

If a Network Integrity test reveals a terminating module is failing to communicate it can indicate a break in the main 'backbone' of the CAN harness. The first checks should always be to confirm the power and ground supplies to the non-communicating module are correct. Providing these are correct, the resistance between the CAN High and CAN Low lines at the J1962 connector can be checked to determine the integrity of the main 'backbone' of the CAN harness. After disconnecting the battery a reading of 120 ohms would indicate an open circuit in the main 'backbone' of the CAN harness. Alternatively, a reading of 60 ohms would indicate that there is no open circuit fault with the main 'backbone' of the CAN harness.

It is worth noting that even if one of the terminating modules is disconnected from the CAN harness, communications between the modules still connected may still be possible. Therefore communication between the manufacturer approved diagnostic system and the connected modules may also be possible.

Locating CAN Harness Open Circuits

In the case where multiple modules, including a terminating module, are failing to communicate, having first confirmed the power and ground supplies are correct, the approximate location of the open circuit can be identified from analysis of the Network Integrity test results and reference to the relevant CAN network circuit diagrams. For example, if an open circuit existed in a certain position on the CAN harness, any module positioned on the Network between the J1962 connector and the open circuit should return a response during the Network Integrity test. No responses would be returned from any modules past the open circuit fault in the Network.

CAN Harness 'Spur' Type Configuration Circuits

If, after the initial checks (Network Integrity test using the manufacturer approved diagnostic system, and power and ground supplies to the module have been checked and confirmed as correct), a module that is connected to the CAN harness via a 'spur' type configuration is suspected of not communicating, then the physical integrity of the CAN harness 'spur' can be checked.

This is most easily undertaken by individually checking the continuity of the CAN High and CAN Low lines between the non-communicating module connector (with the module disconnected) and the J1962 diagnostic connector.

'Lost Communications' DTCs

For example, if a global DTC read were to be carried out, only DTCs stored in the modules that the manufacturer approved diagnostic system could communicate with would be displayed. If there were an open circuit fault in a certain position on the CAN harness, the modules that could display DTCs would all be prior to the open circuit on the Network, and these modules should display 'Lost Communications' DTCs with all the modules located on the Network past the open circuit fault.

Note. Additional DTCs may also be logged along with the 'Lost Communications' DTCs.

CONTROLLER AREA NETWORK (CAN)

Control Module Connections to the CAN Harness

Control modules are connected to the CAN harness either in a 'loop' or 'spur' configuration. In the 'loop' type configuration the CAN harness loops into the module (via two connector pins) and then loops out of the module (via another two connector pins). In the 'spur' type configuration, a harness spur is spliced into the main 'backbone' of the CAN harness and the module is connected to the harness spur via two connector pins.

CAN Harness Architecture

For a detailed description of the CAN Networks and architecture, refer to the relevant Description and Operation section in the Workshop Manual.

CAN Network Integrity Tests

CAN Terminating Modules

Non-Communication of a Terminating Module

Locating CAN Harness Open Circuits

CAN Harness 'Spur' Type Configuration Circuits

'Lost Communications' DTCs

As well as the methods described so far in this document, which can be used to determine the location of an open circuit in the CAN harness, 'Lost Communications' DTCs can also be used for this purpose. Lost communication DTCs mean that a module is not receiving CAN information from another module.

For example, if a global DTC read were to be carried out, only DTCs stored in the modules that the manufacturer approved diagnostic system could communicate with would be displayed. If there was an open circuit fault in a certain position on the CAN harness, the modules that could display DTCs would all be prior to the open circuit on the Network, and these modules should display 'Lost Communications' DTCs with all the modules located on the Network past the open circuit fault.

'Bus off' DTCs

The references to bus and its condition refer to the network concerned and the modules on that network.

If a module logs a 'Bus Off' DTC, it means that the module has detected CAN transmission errors and has disabled it's own CAN transmissions and disconnected itself from the network in an attempt to allow the rest of the network to function. At this point the 'Bus Off' DTC is set. A common cause of 'Bus Off' DTCs can be a short circuit in the CAN network.

Scheme 7

Scheme 7: MEDIA ORIENTED SYSTEMS TRANSPORT (MOST)

Item	Description
1	Information and entertainment control module
2	MOST diagnostic connector
3	Touch screen display
4	Telephone module
5	Portable audio interface module
6	Integrated audio module
7	Power amplifier
8	Navigation control module
9	DAB tuner module
10	Television receiver

Overview

The basic guidelines are covered in the description and operation section, such as not attempting to repair fibre optic cables, but additional precautions include

Do not touch the exposed ends of the optical fibres (grease from skin can contaminate the fibre)
Whenever the fibre optic cable is disconnected, cover the connectors to prevent dust contamination
Do not expose the fibre optic cable to heat
Do not bend the fibre optic cable through less than a 25 mm (one inch) radius
Do not use laser pens to test the fibre optic cable's ability to pass light

MOST Diagnostic Tools

There are two dedicated tools for testing the MOST system

Scheme 8

MOST tester. The MOST tester is connected to the MOST network in place of a control module. It will confirm receipt of any existing MOST signal and transmit it to the next control module on the network. Perform the following tests to validate the operation of the MOST tester. GO to Pinpoint Test A .

Scheme 9

MOST prism. The MOST prism is connected in the same way as the MOST tester but will simply reflect any existing signal onward to the next control module. Using the MOST prism before or after a long run of harness may cause a ring break as a good signal may be too weak after travelling the extended distance. Also, the MOST prism will pass light in either direction so will not detect reversed MOST terminals elsewhere in the network. For these reasons, the MOST tester is the preferred tool and should be used unless limited access does not permit it

MOST Ring Break Indication

A ring break in the MOST network is indicated by a blank touch screen display if the break is before the touch screen display or a flashing logo of the break is after the touch screen display. Possible causes of ring breaks are listed in the symptom chart

Central Junction Box (CJB)

CAUTION

When probing connectors to take measurements in the course of the pinpoint tests, use the adaptor kit, part number 3548-1358-00

Note. If the control module or a component is suspect and the vehicle remains under manufacturer warranty, refer to the Warranty Policy and Procedures manual (section B1.2), or determine if any prior approval programme is in operation, prior to the installation of a new module/component.

Note. Generic scan tools may not read the codes listed, or may read only five digit codes. Match the five digits from the scan tool to the first five digits of the seven digit code listed to identify the fault (the last two digits give extra information read by the manufacturer-approved diagnostic system).

Note. When performing voltage or resistance tests, always use a digital multimeter (DMM) accurate to three decimal places and with a current calibration certificate. When testing resistance, always take the resistance of the DMM leads into account.

Note. Check and rectify basic faults before beginning diagnostic routines involving pinpoint tests.

Note. If DTCs are recorded and, after performing the pinpoint tests, a fault is not present, an intermittent concern may be the cause. Always check for loose connections and corroded terminals.

DTC	Description	Possible Cause	Action
B00D511	Restraint System Passenger Disable Indicator	PAD lamp supply circuit - short to ground	Refer to the electrical circuit diagrams and check PAD lamp supply circuit for short to ground
B00D512	Restraint System Passenger Disable Indicator	PAD lamp supply circuit - short to power	Refer to the electrical circuit diagrams and check PAD lamp supply circuit for short to power
B00D513	Restraint System Passenger Disable Indicator	PAD lamp supply circuit - open circuit	Refer to the electrical circuit diagrams and check PAD lamp supply circuit for open circuit
B100951	Ignition Authorisation	Faulty instrument cluster Target SID re-synchronisation error following programming CAN fault	Check ignition, power and ground supplies to CJB and instrument cluster. Re-synchronize ID by re-configuring the instrument cluster as a new module. Check CAN communications between instrument cluster and tester
B100962	Ignition Authorisation	Low speed CAN fault CJB fault Instrument cluster fault Incorrect module installed (CJB/Instrument cluster) Target SID synchronization error following re-programming Noise/EMC related error	Check CAN communications between CJB and instrument cluster. Check ignition, power and ground supplies to CJB and instrument cluster. Confirm correct module is installed. Re-synchronise ID by re-configuring the instrument cluster as a new module. Check CAN network for interference/EMC related issues
B100963	Ignition Authorisation	CJB fault Low speed CAN fault Instrument cluster fault Low battery voltage <9V	Check Power and Ground supplies to CJB and instrument cluster. Check CAN communications between CJB and instrument cluster. Check battery is in fully charged and serviceable condition, refer to the battery care manual
B100964	Ignition Authorisation	CJB fault Low speed CAN fault Instrument cluster fault	Check power and ground supplies to CJB and instrument cluster. Check CAN communications between CJB and instrument cluster
B102B67	Passive Key	CJB fault Low speed CAN fault Remote Keyless Entry (RKE) module fault Write target SID synchronization error following re-programming	Check power and ground supplies to CJB and RKE module. Check CAN communications between CJB and RKE module. Re-synchronise ID by re-configuring the RKE module as a new module
B102B87	Passive Key	CJB fault Low speed CAN fault RKE module fault Key fob battery low/battery contact issue Interference from other RF signal EMC/noise Receiver fault Receiver not programmed correctly Serial communications fault (between receiver and RKE module) Key fault Passive antenna fault Confirm placement of key within vehicle	Check power and ground supplies to CJB, RKE module and receiver. Check CAN communications between CJB and instrument cluster. Check key fob battery. Confirm vehicle surroundings, move vehicle. Check CAN network for interference/EMC related issues. Disconnect battery, then re-connect - confirm operation by re-programming keys. Check serial circuit between receiver and RKE module. Confirm spare key works. Refer to the electrical circuit diagrams and test circuits to all 3 antennas. Check whereabouts of key
B108413	Boot/Trunk Motor Close Switch	Trunk latch open signal circuit - open circuit	Refer to the electrical circuit diagrams and check trunk latch open signal circuit for open circuit
B108783	LIN Bus "A"	Checksum of the received LIN frame from battery backed sounder, roof header console, and/or rain/light sensor is incorrect	Check operation of rain/light sensor by covering sensor or applying water to screen, install a new sensor as required
B108788	LIN Bus "A"	Bus off. Battery backed sounder, roof header console, and/or rain/light sensor LIN circuit - short to ground, power	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check battery backed sounder, roof header console, and rain/light sensor LIN circuit for short to ground, power
B108A11	Start Button	Start/Stop switch analogue input circuits 1 or 2 - short to ground	Refer to the electrical circuit diagrams and check Start/Stop switch analogue input circuits 1 and 2 for short to ground
B108A12	Start Button	Start/Stop switch analogue input circuits 1 or 2 - short to power	Refer to the electrical circuit diagrams and check Start/Stop switch analogue input circuits 1 and 2 for short to power
B109512	Wiper On/Off Relay	Wiper On/Off relay control circuit - short to power	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check wiper On/Off relay control circuit for short to power
B109514	Wiper On/Off Relay	Wiper On/Off relay control circuit - short to ground, open circuit	Refer to the electrical circuit diagrams and check wiper On/Off relay control circuit for short to ground, open circuit
B109612	Wiper High/Low Relay	Wiper Fast/Slow relay control circuit - short to power	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check wiper Fast/Slow relay control circuit for short to power
B109614	Wiper High/Low Relay	Wiper Fast/Slow relay control circuit - short to ground, open circuit	Refer to the electrical circuit diagrams and check wiper Fast/Slow relay control circuit for short to ground, open circuit
B109712	Heated Windshield Relay	Heated windshield relay control circuit - short to power	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check heated windshield relay control circuit for short to power
B109714	Heated Windshield Relay	Heated windshield relay control circuit - short to ground, open circuit	Refer to the electrical circuit diagrams and check heated windshield relay control circuit for short to ground, open circuit
B10A612	Main Light Switch	Master light switch signal from roof header console circuit - short to power	Refer to the electrical circuit diagrams and check master light switch signal from roof header console circuit for short to power
B10A623	Main Light Switch	Master light switch signal from roof header console signal stuck low. Switch is read as ON for too long a time	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check master light switch signal from roof header console for short to ground
B10AD09	Rain Sensor	Component failures	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Suspect the rain/light sensor, check and install a new sensor as required
B10AD11	Rain Sensor	Rain/light sensor power circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check rain/light sensor power circuit for short to ground
B10AD96	Rain Sensor	Component internal failure	Suspect the rain/light sensor, check and install a new sensor as required
B10E511	PCM Wake-up Signal	ECM wake-up signal circuit - short to ground	Refer to the electrical circuit diagrams and check ECM wake-up signal circuit for short to ground
B10E512	PCM Wake-up Signal	ECM wake-up signal circuit - short to power	Refer to the electrical circuit diagrams and check ECM wake-up signal circuit for short to power
B10E513	PCM Wake-up Signal	ECM wake-up signal circuit - open circuit	Refer to the electrical circuit diagrams and check ECM wake-up signal circuit for open circuit
B10F111	Key In Switch	Keyless vehicle module, key IN status circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check keyless vehicle module, key IN status circuit for short to ground
B10F112	Key In Switch	Keyless vehicle module, key IN status circuit - short to power	Refer to the electrical circuit diagrams and check keyless vehicle module, key IN status circuit for short to power
B10F113	Key In Switch	Keyless vehicle module, key IN status circuit - open circuit	Refer to the electrical circuit diagrams and check keyless vehicle module, key IN status circuit for open circuit
B10F211	Sunroof Control	Sunroof enable signal circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check sunroof enable signal circuit for short to ground
B10F212	Sunroof Control	Sunroof enable signal circuit - short to power	Refer to the electrical circuit diagrams and check sunroof enable signal circuit for short to power
B10F213	Sunroof Control	Sunroof enable signal circuit - open circuit	Refer to the electrical circuit diagrams and check sunroof enable signal circuit for open circuit
B10F311	Left Front Position Light	Left front side lamps circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check left front side lamps circuit for short to ground
B10F315	Left Front Position Light	Left front side lamps circuit - short to power, open circuit	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check left front side lamps circuit for short to power, open circuit
B10F411	Right Front Position Light	Right front side lamps circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check right front side lamps circuit for short to ground
B10F415	Right Front Position Light	Right front side lamps circuit - short to power, open circuit	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check right front side lamps circuit for short to power, open circuit
B10F812	Accessory socket 'A' relay	Accessory socket 'A' relay control circuit - short to power	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check accessory socket 'A' relay control circuit for short to power
B10F814	Accessory socket 'A' relay	Accessory socket 'A' relay control circuit - short to ground, open circuit	Refer to the electrical circuit diagrams and check accessory socket 'A' relay control circuit for short to ground, open circuit
B10F912	Accessory socket 'B' relay	Front powerpoint, trailer tow connector, road pricing connector, sunblind power supply circuits - short to power	Refer to the electrical circuit diagrams and check front powerpoint, trailer tow connector, road pricing connector, sunblind power supply circuits for short to power
B10F914	Accessory socket 'B' relay	Front powerpoint, trailer tow connector, road pricing connector, sunblind power supply circuits - short to ground, open circuit	Refer to the electrical circuit diagrams and check front powerpoint, trailer tow connector, road pricing connector, sunblind power supply circuits for short to ground, open circuit
B10F993	Accessory socket 'B' relay	Front powerpoint, trailer tow connector, road pricing connector, sunblind power supply circuits - short to power, ground, open circuit	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check front powerpoint, trailer tow connector, road pricing connector, sunblind power supply circuits for short to power, ground, open circuit
B10FA93	Delayed Power Off relay	ADRC ECM, roof header console lamp, glove box lamp, RH/LH footwell lamps, JAG Sense glove box module, RH/LH sunvisor lamps, rear dome lamps switched power circuits - short to power, open circuit	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check ADRC ECM, roof header console lamp, glove box lamp, RH/LH footwell lamps, JAG Sense glove box module, RH/LH sunvisor lamps, rear dome lamps switched power circuits for short to power, open circuit
B10FF11	Ignition control	ECM and FPDB ignition control circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check ECM and FPDB ignition control circuit for short to ground
B10FF13	Ignition control	ECM and FPDB ignition control circuit - open circuit	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check ECM and FPDB ignition control circuit for open circuit
B110011	O2 sensor heater relay	FPDB O2 sensor heater relay control circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check FPDB O2 sensor heater relay control circuit for short to ground
B113D12	Sunroof Global Open/Close Control	Roof opening panel global open/close control circuit - short to power	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check roof opening panel global open/close control circuit for short to power
B113D14	Sunroof Global Open/Close Control	Roof opening panel global open/close control circuit - short to ground, open circuit	Refer to the electrical circuit diagrams and check roof opening panel global open/close control circuit for short to ground, open circuit
B114011	Engine Crank Authorisation	Engine crank authorization signal circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check engine crank authorization signal circuit for short to ground
B114211	Ignition Status 1	Ignition supply 1 circuits - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check all ignition supply 1 circuits for short to ground
B114311	Ignition Status 2	Ignition supply 2 circuits - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check all ignition supply 2 circuits for short to ground
B114411	Heated Steering Wheel Supply	Heated steering wheel supply circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check heated steering wheel supply circuit for short to ground
B114511	Glovebox Locking Motor	Glovebox latch locking motor circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check glovebox latch locking motor circuit for short to ground
B114512	Glovebox Locking Motor	Glovebox latch locking motor control circuit - short to power	Refer to the electrical circuit diagrams and check glovebox latch locking motor control circuit for short to power
B114513	Glovebox Locking Motor	Glovebox latch locking motor control circuit - open circuit	Refer to the electrical circuit diagrams and check glovebox latch locking motor control circuit for open circuit
B114612	Passive sounder Supply	Security passive sounder control circuit - short to power	Refer to the electrical circuit diagrams and check security passive sounder control circuit for short to power
B114614	Passive sounder Supply	Security passive sounder control circuit - short to ground, open circuit	Refer to the electrical circuit diagrams and check security passive sounder control circuit for short to ground, open circuit
B115811	Front Passenger Seat Heater Sensor	Front passenger seat heater sensor circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check front passenger seat heater sensor circuit for short to ground
B115813	Front Passenger Seat Heater Sensor	Front passenger seat heater sensor circuit - open circuit	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check front passenger seat heater sensor circuit for open circuit
B115911	Driver Seat Heater Sensor	Driver seat heater sensor circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check driver seat heater sensor circuit for short to ground
B115913	Driver Seat Heater Sensor	Driver seat heater sensor circuit - open circuit	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check driver seat heater sensor circuit for open circuit
B115A11	Front Passenger Seat Heater	Front passenger seat heater supply circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check front passenger seat heater supply circuit for short to ground
B115A15	Front Passenger Seat Heater	Front passenger seat heater supply circuit - short to power, open circuit	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check front passenger seat heater supply circuit for short to power, open circuit
B115B11	Driver Seat Heater	Driver seat heater supply circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check driver seat heater supply circuit for short to ground
B115B15	Driver Seat Heater	Driver seat heater supply circuit - short to power, open circuit	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check driver seat heater supply circuit for short to power, open circuit
B117513	Driver Door Ajar Switch	Driver door ajar switch signal circuit - open circuit	Refer to the electrical circuit diagrams and check driver door ajar switch signal circuit for open circuit
B117613	Passenger Door Ajar Switch	Passenger door ajar switch signal circuit - open circuit	Refer to the electrical circuit diagrams and check passenger door ajar switch signal circuit for open circuit
B117712	Screenwash Level Switch	Screenwash level switch signal circuit - short to power	Refer to the electrical circuit diagrams and check screenwash level switch signal circuit for short to power
B11C013	Driver Side Rear Door Ajar Switch	Left rear door ajar switch signal circuit - open circuit	Refer to the electrical circuit diagrams and check left rear door ajar switch signal circuit for open circuit
B11C113	Passenger Side Rear Door Ajar Switch	Right rear door ajar switch signal circuit - open circuit	Refer to the electrical circuit diagrams and check right rear door ajar switch signal circuit for open circuit
B122223	Master Lock/Unlock Switch	Master lock or unlock switch digital input circuit - signal stuck low	Refer to the electrical circuit diagrams and check master lock and unlock switch digital input circuits for short to ground, open circuit
B123711	Gear Shift Module Early Wake-up	Transmission shift module wake-up control circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check transmission shift module wake-up control circuit for short to ground
B123712	Gear Shift Module Early Wake-up	Transmission shift module wake-up control circuit - short to power	Refer to the electrical circuit diagrams and check transmission shift module wake-up control circuit for short to power
B123713	Gear Shift Module Early Wake-up	Transmission shift module wake-up control circuit - open circuit	Refer to the electrical circuit diagrams and check transmission shift module wake-up control circuit for open circuit
B123E13	Crank Enable	OK to crank signal circuit - open circuit	Refer to the electrical circuit diagrams and check OK to crank signal circuit for open circuit
B1A8596	Ambient Light Sensor	Light sensor internal electronic failure	Check and install a new sensor as required
B1C4513	Front Wiper Park Position Switch	Windshield wiper motor park switch signal circuit - open circuit	Refer to the electrical circuit diagrams and check windshield wiper motor park switch signal circuit for open circuit
B1C4523	Front Wiper Park Position Switch	Signal stuck low	Refer to the electrical circuit diagrams and check front wiper park position switch input circuit for short, open circuit
B1C7812	Powerwash Relay	Powerwash relay control circuit - short to power	Refer to the electrical circuit diagrams and check powerwash relay control circuit for short to power
B1C7814	Powerwash Relay	Powerwash relay control circuit - short to ground, open circuit	Refer to the electrical circuit diagrams and check powerwash relay control circuit for short to ground, open circuit
B1C7911	Front Washer Pump	Screenwash pump control circuit - short to ground	Refer to the electrical circuit diagrams and check screenwash pump control circuit for short to ground
B1C7913	Front Washer Pump	Screenwash pump control circuit - open circuit	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check screenwash pump control circuit for open circuit
B1C9812	Left Corner Lamp Circuit	Left front corner lamp control circuit - short to power	Refer to the electrical circuit diagrams and check left front corner lamp control circuit for short to power
B1C9814	Left Corner Lamp Circuit	Left front corner lamp control circuit - short to ground, open circuit	Refer to the electrical circuit diagrams and check left front corner lamp control circuit for short to ground, open circuit
B1C9912	Right Corner Lamp Circuit	Right front corner lamp control circuit - short to power	Refer to the electrical circuit diagrams and check right front corner lamp control circuit for short to power
B1C9914	Right Corner Lamp Circuit	Right front corner lamp control circuit - short to ground, open circuit	Refer to the electrical circuit diagrams and check right front corner lamp control circuit for short to ground, open circuit
B1D0011	Left Low Beam	Left dip beam control circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check left dip beam control circuit for short to ground
B1D0012	Left Low Beam	Left dip beam control circuit - short to power	Refer to the electrical circuit diagrams and check left dip beam control circuit for short to power
B1D0013	Left Low Beam	Left dip beam control circuit - open circuit	Refer to the electrical circuit diagrams and check left dip beam control circuit for open circuit
B1D0111	Right Low Beam	Right dip beam control circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check right dip beam control circuit for short to ground
B1D0112	Right Low Beam	Right dip beam control circuit - short to power	Refer to the electrical circuit diagrams and check right dip beam control circuit for short to power
B1D0113	Right Low Beam	Right dip beam control circuit - open circuit	Refer to the electrical circuit diagrams and check right dip beam control circuit for open circuit
B1D0211	Left High Beam Circuit	Left high beam control circuit - short to ground	Refer to the electrical circuit diagrams and check left high beam control circuit for short to ground
B1D0212	Left High Beam Circuit	Left high beam control circuit - short to power	Refer to the electrical circuit diagrams and check left high beam control circuit for short to power
B1D0213	Left High Beam Circuit	Left high beam control circuit - open circuit	Refer to the electrical circuit diagrams and check left high beam control circuit for open circuit
B1D0311	Right High Beam Circuit	Right high beam control circuit - short to ground	Refer to the electrical circuit diagrams and check right high beam control circuit for short to ground
B1D0312	Right High Beam Circuit	Right high beam control circuit - short to power	Refer to the electrical circuit diagrams and check right high beam control circuit for short to power
B1D0313	Right High Beam Circuit	Right high beam control circuit - open circuit	Refer to the electrical circuit diagrams and check right high beam control circuit for open circuit
B1D1711	Battery Backed Sounder	Battery backed sounder inclination sensor control circuit - short to ground	Refer to the electrical circuit diagrams and check battery backed sounder inclination sensor control circuit for short to ground
B1D1811	Volumetric Sensor	Intrusion sensor module supply circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check intrusion sensor module supply circuit for short to ground
B1D2711	Heater Coolant Pump	Heater coolant pump control circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check heater coolant pump control circuit for short to ground
B1D2713	Heater Coolant Pump	Heater coolant pump control circuit - open circuit	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check heater coolant pump control circuit for open circuit
B1D9796	Tilt Sensor	Component internal failure	Suspect the battery backed sounder, check and install a new battery backed sounder as required
P057112	Brake Switch A Circuit	Footbrake switch circuit - short to power	Refer to the electrical circuit diagrams and check footbrake switch circuit for short to power
P080111	Reverse Inhibit Control Circuit	Electrochromic rear view mirror, reverse inhibit circuit - short to ground	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check electrochromic rear view mirror, reverse inhibit circuit for short to ground
P080112	Reverse Inhibit Control Circuit	Electrochromic rear view mirror, reverse inhibit circuit - short to power	Refer to the electrical circuit diagrams and check electrochromic rear view mirror, reverse inhibit circuit for short to power
P080113	Reverse Inhibit Control Circuit	Electrochromic rear view mirror, reverse inhibit circuit - open circuit	Refer to the electrical circuit diagrams and check electrochromic rear view mirror, reverse inhibit circuit for open circuit
P085013	Park/Neutral Switch Input Circuit	Park/Neutral signal circuit - open circuit	Refer to the electrical circuit diagrams and check Park/Neutral signal circuit for open circuit
P162413	Anti-theft System	RJB anti-theft signal circuit - open circuit	Refer to the electrical circuit diagrams and check RJB anti-theft signal circuit for open circuit
P254F13	Engine Hood Switch Circuit/Open	Hood ajar switch signal circuit - open circuit	Refer to the electrical circuit diagrams and check hood ajar switch signal circuit for open circuit
U001988	Low Speed CAN Communication Bus	Bus OFF	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system.
U014200	Lost Communication With Body Control Module "B"	No sub type information	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system.
U015500	Lost Communication With Instrument Panel Cluster (IPC) Control Module	No sub type information	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system.
U015600	Lost Communication With Information Center "A"	No sub type information	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system.
U016400	Lost Communication With HVAC Control Module	No sub type information	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system.
U016800	Lost Communication With Vehicle Security Control Module	No sub type information	Check power and ground supplies to vehicle security module
U019900	Lost Communication With "Door Control Module A"	No sub type information	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system.
U020000	Lost Communication With "Door Control Module B"	No sub type information	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system.
U021400	Lost Communication With Remote Function Actuation	No sub type information	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system.
U023100	Lost Communication With Rain Sensing Module	No sub type information	Check power and ground supplies to rain sensing module. LIN circuit fault
U030000	Internal Control Module Software Incompatibility	No sub type information	Suspect the CJB. Check and install a new CJB as required, refer to the new module/component installation note at the top of the DTC Index
U100000	Solid State Driver Protection Active - Driver Disabled	No sub type information	Check CJB for additional load related DTCs and refer to remedial actions for those DTCs
U1A1449	CAN Initialisation Failure	Internal electronic failure	Suspect the CJB. Check and install a new CJB as required, refer to the new module/component installation note at the top of the DTC Index
U200813	Sensor Cluster	Instrument cluster security signal circuit - open circuit	Refer to the electrical circuit diagrams and check instrument cluster security signal circuit for open circuit
U201012	Switch Illumination	Switch/interior illumination PWM supply circuit - short to power	Refer to the electrical circuit diagrams and check switch/interior illumination PWM supply circuit for short to power
U201014	Switch Illumination	Switch/interior illumination PWM supply circuit - short to ground, open circuit	Refer to the electrical circuit diagrams and check switch/interior illumination PWM supply circuit for short to ground, open circuit
U210000	Initial Configuration Not Complete	RJB configuration (parameters) failure	Re-configure the RJB using the manufacturer approved diagnostic system
U300049	Control Module	Internal electronic failure	Suspect the CJB. Check and install a new CJB as required, refer to the new module/component installation note at the top of the DTC Index
U300055	Control Module	Not configured	Re-configure the RJB using the manufacturer approved diagnostic system. Check the correct CJB is installed to vehicle market/specification. Install a new/correct CJB as required, refer to the new module/component installation note at the top of the DTC Index
U300087	Control Module	Missing message	Carry out CAN network integrity test using the manufacturer approved diagnostic system. Refer to the electrical circuit diagrams and check CAN network between RJB and CJB for short, open circuit. Check RJB and then CJB for related DTCs and refer to the relevant DTC Index
U300281	Vehicle Identification Number	Invalid serial data received	Suspect the CJB has previously been installed to another vehicle. Check and install the original or a new CJB
U300317	Battery Voltage	Circuit voltage above threshold	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system.
U300362	Battery Voltage	Mis-match in battery voltage, of 2 volts or more, between CJB and RJB	Carry out any pinpoint tests associated with this DTC using the manufacturer approved diagnostic system.

Rear Junction Box (RJB)
