Specifications
| Description | Nm |
|---|---|
| Engine oil cooler retaining bolts | 7 |
| Cooling module retaining bolts | 7 |
| Charge air cooler water pump bracket retaining bolts | 7 |
| Charge air cooler radiator drain plug | 1 |
| Coolant expansion tank bleed screw | 1 |
| Supercharger coolant fill plug | 45 |
Torque Specifications
| Description | Specification |
|---|---|
| Jaguar Premium Cooling System Fluid | WSS M97B44-D |
Lubricants, Fluids, Sealers and Adhesives
Scheme 77
| Item Number | Description |
|---|---|
| 1 | Coolant hose - water pump to charge air coolers. |
| 2 | Coolant hose - coolant expansion tank to radiator. |
| 3 | Coolant hose - radiator vent. |
| 4 | Coolant expansion tank. |
| 5 | Coolant hose - charge air coolers to radiator. |
| 6 | Radiator. |
| 7 | Coolant hose - radiator to water pump to. |
| 8 | Water pump. |
Scheme 78
| Item Number | Description |
|---|---|
| 1 | Charge air cooler water pump. |
| 2 | Radiator. |
| 3 | Cooling fan. |
| 4 | Coolant expansion tank. |
| 5 | Engine. |
| 6 | Charge air cooler. |
| 7 | Throttle housing. |
| 8 | Heater core. |
| 9 | Cooling system water pump. |
| 10 | Charge air cooler. |
| 11 | Thermostat. |
| 12 | Auxiliary coolant flow pump. |
| 13 | Charge air cooler radiator. |
The supercharger cooling system is integrated with in the engine cooling system but uses a separate radiator and electrical water pump.
Radiator
The supercharger radiator is of aluminum construction. The radiator is mounted to the cooling module between the oil cooler and the air conditioning condenser. A coolant drain plug is located at the left-hand bottom of the radiator.
Water pump
The charge air cooler water pump is electrically driven, continuously while the ignition is on. The charge air cooler water pump provides an efficient coolant flow to the charge air coolers.
