Supercharger Cooling - Diagnostic Procedures

1. Verify the customer concern by operating the system.
2. Visually inspect for obvious signs of mechanical and electrical damage. Visual Inspection Chart Mechanical Electrical Leak(s) Hose(s) Charge air cooler radiator Supercharger cooling water pump Coolant expansion tank Coolant pressure cap Radiator Engine cooling water pump Cooling fan Fuse(S) Wiring harness Electrical connector(S) Engine coolant temperature sensor Cooling fan motor Supercharger cooling water pump
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the cause is not visually evident, verify the symptom and refer to the Jaguar Approved Diagnostic System.

Component tests

Pressure test. Refer to Engine Cooling or Supercharger Cooling . Coolant pressure cap pressure test. Refer to Engine Cooling or Supercharger Cooling . Thermostat test. Refer to Engine Cooling or Supercharger Cooling . Radiator leak test. Refer to Engine Cooling or Supercharger Cooling .

Scheme 79

Scheme 80

Scheme 81

1. Release the cooling system pressure. Remove the coolant expansion tank pressure cap.
2. Remove the radiator splash shield. Refer to «Front End Body Panels»(ref-311270) article.
3. Remove the radiator lower cowl.
4. Remove the radiator drain plug. Drain the coolant into a suitable container.
5. Install the radiator drain plug when all coolant has drained. Tighten to 1 Nm. Remove the container. Clean off any spillages.
6. Install the radiator lower cowl.
7. Install the radiator splash shield. Refer to «Front End Body Panels»(ref-311270) article.
8. Remove the coolant expansion tank bleed screw.
9. Fill the cooling system up to the MAX mark on the coolant expansion tank using a fifty percent mixture of Jaguar Premium Cooling System Fluid or equivalent, meeting Jaguar specification WSS M97B44-D and fifty percent water.
10. Install the coolant expansion tank bleed screw. Tighten to 1 Nm.
11. Install the coolant expansion tank pressure cap.
12. Remove the engine cover.
13. Remove the supercharger coolant filler plug. Remove and discard the sealing washer.
14. Top up the coolant through the supercharger fill port.
15. Switch ignition on.
16. Allow the supercharger pump to run and top up the coolant through supercharger fill port.
17. Switch the ignition off.
18. Install the supercharger coolant fill plug. Install a new sealing washer. Tighten to 45 Nm. Clean off any spillages.
19. Install the engine cover.
20. START and RUN the engine.
21. SET the heating system to MAX heat, the blower motor to MAX speed and the air distribution to instrument panel registers.
22. Allow the engine to RUN until hot air is emitted from the instrument panel registers, while observing the engine temperature gauge.
23. Switch off the engine.
24. Allow the engine to cool.
25. Release the cooling system pressure. Remove the coolant expansion tank pressure cap.
26. Fill the cooling system up to the MAX mark on the coolant expansion tank using a fifty percent mixture of Jaguar Premium Cooling System Fluid or equivalent, meeting Jaguar specification WSS M97B44-D and fifty percent water.
27. Install the coolant expansion tank pressure cap.

Scheme 82

Scheme 83

Scheme 84

Scheme 85

1. Remove the water pump.
2. Remove the oil cooler. Refer to «Engine»(ref-311288) article.
3. Lower the vehicle.
4. Disconnect the radiator coolant vent hose.
5. Raise the vehicle.
6. Disconnect the left-hand radiator hose.
7. Disconnect the right-hand radiator hose.
8. Remove the water pump retaining bracket. Remove the retaining bolt. Remove the water pump retaining bracket.
9. Remove the cooling module retaining bolt.
10. Remove the cooling module retaining bolt.
11. Remove the radiator.

Scheme 86

1. To install, reverse the removal procedure. Tighten to 7 Nm.
2. Tighten to7 Nm.
3. Tighten to 7 Nm.

Scheme 87

1. Carry out the supercharging cooling system draining procedure. «Supercharger Cooling System Draining, Filling and Bleeding - General Procedures»(ref-311314-S16415549992009032500000) .
2. Disconnect the water pump coolant hoses. Disconnect the water pump electrical connector. Disconnect the water pump coolant hoses.
3. Remove the water pump. Remove the water pump retaining bolt. Remove the water pump.
