Specifications
| Description | Specification |
|---|
| Jaguar Premium Cooling System Fluid | WSS M97B44-D |
| Jaguar Premium Cooling System Flush | EGR-M14P7-A |
Lubricants, Fluids, Sealers and Adhesives
| Engine | Capacity |
|---|
| 2.5L/3.0L | 9.4L |
| 4.2L | 13.3L |
Cooling System Refill Capacities
| Description | Nm |
|---|
| Coolant expansion tank retaining bolt | 3 |
| Coolant expansion tank bleed screw | 1 |
| Cooling fan motor and shroud retaining nuts | 7 |
| Thermostat housing retaining bolts - Vehicles with 2.5L or 3.0L engine | 10 |
| Thermostat housing retaining bolts - Vehicles with 4.2L engine | 9 |
| Water pump retaining bolts - Vehicles with 2.5L or 3.0L engine | 25 |
| Water pump retaining bolts - Vehicles with 4.2L engine | A |
| Water pump drive pulley retaining bolts - Vehicles with 4.2L engine | A |
| Radiator mounting bracket retaining bolts | 7 |
| Radiator drain plug | 1 |
| A = refer to the procedure for the correct torque sequence | |
Scheme 1
Scheme 1: Vehicles with 2.5L or 3.0L engine
| Item Number | Description |
|---|
| 1 | Bleed screw |
| 2 | Coolant expansion tank |
| 3 | Radiator |
| 4 | Radiator shroud |
| 5 | Cooling fan motor |
| 6 | Water pump |
| 7 | Thermostat housing |
| 8 | Engine coolant inlet |
| 9 | Engine coolant outlet |
| 10 | Vent hose |
Scheme 2
| Item Number | Description |
|---|
| 1 | Engine oil cooler |
| 2 | Retaining bolt |
| 3 | Engine oil cooler inlet and outlet tubes |
Scheme 3
Scheme 3: Vehicles with 4.2L engine
| Item Number | Description |
|---|
| 1 | Engine coolant outlet |
| 2 | Vent hose |
| 3 | Thermostat housing |
| 4 | Bleed screw |
| 5 | Heater hose connections |
| 6 | Auxiliary coolant flow pump |
| 7 | Dual coolant flow valve |
| 8 | Cooling fan motor |
| 9 | Radiator |
| 10 | Engine oil cooler connections |
| 11 | Engine coolant inlet |
Scheme 4
| Item Number | Description |
|---|
| 1 | Vent hose (SC radiator) |
| 2 | Coolant expansion tank |
| 3 | Vent hose |
| 4 | Radiator |
| 5 | Auxiliary coolant flow pump |
| 6 | Cooling fan motor |
| 7 | Engine coolant inlet |
| 8 | Engine coolant outlet |
| 9 | Thermostat housing |
| WARNING | Never remove the coolant pressure cap under any circumstances while the engine is operating. Failure to follow this instruction may result in personal injury. To avoid having scalding hot coolant or steam blow out of the cooling system, use extreme care when removing the coolant pressure cap from a hot cooling system. Wait until the engine has cooled, then wrap a thick cloth around the coolant pressure cap and turn it slowly until the pressure begins to release. Step back while the pressure is released from the system. When certain all the pressure has been released (still with a cloth) turn and remove the coolant pressure cap from the coolant expansion tank. Failure to follow these instructions may result in personal injury. |
| WARNING | To avoid the possibility of personal injury, do not operate the engine with the hood open until the fan blades have been examined for cracks and separation. Failure to follow this instruction may result in personal injury. |
| WARNING | Remove fuse 38 from the engine compartment fuse box prior to performing any under hood service in the area of the cooling fan when the engine is hot, since the cooling fan motor could operate if the engine has been switched OFF. Failure to follow this instruction may result in personal injury. |
| CAUTION | The engine cooling system must be maintained with the correct concentration and type of anti-freeze solution to prevent corrosion and frost damage. |
| CAUTION | Never remove the coolant pressure cap under any circumstances while the engine is operating. Failure to follow this instruction may result in damage to the engine. |
The cooling system consists of the following
- Radiator
- Coolant pressure cap
- Thermostat
- Water pump
- Electric cooling fan
- Coolant expansion tank
- Engine oil cooler
