Engine Cooling (2.5L/3.0L): Maintenance Jaguar S-type I рестайлинг

Cooling System Draining, Filling and Bleeding - General Procedures

All Vehicles

Scheme 58

Scheme 59

1. Relieve the cooling system pressure. Unscrew the coolant expansion tank cap slowly.
2. Remove the coolant expansion tank cap.
3. Remove the radiator splash shield. Refer to «Front End Body Panels»(ref-311270) article.
4. Remove the radiator lower cowl.
5. Remove the coolant drain plug. Drain the coolant into a suitable container.
6. Install the drain plug when all coolant has drained. Tighten to 1 Nm. Remove the drain tray.
7. Install the radiator lower cowl.
8. Install the radiator splash shield. Refer to «Front End Body Panels»(ref-311270) article.

Vehicles without supercharger

Scheme 60

1. Remove the coolant expansion tank bleed screw.
2. Fill the cooling system up to the MAX mark on the coolant expansion tank using a fifty percent mixture of Jaguar Premium Cooling System Fluid or equivalent, meeting Jaguar specification WSS M97B44-D and fifty percent water.
3. Install the coolant expansion tank bleed screw. Tighten to 1 Nm.
4. Install the coolant expansion tank pressure cap.
5. START and RUN the engine.
6. SET the heating system to MAX heat, the blower motor to MAX speed and the air distribution to instrument panel registers.
7. Allow the engine to RUN until hot air is emitted from the instrument panel registers, while observing the engine temperature gauge.
8. Switch off the engine.
9. Allow the engine to cool.
10. Release the cooling system pressure. Remove the coolant expansion tank pressure cap.
11. Fill the cooling system up to the MAX mark on the coolant expansion tank using a fifty percent mixture of Jaguar Premium Cooling System Fluid or equivalent, meeting Jaguar specification WSS M97B44-D and fifty percent water.
12. Install the coolant expansion tank pressure cap.

Cooling System Draining and Vacuum Filling - General Procedures

All vehicles

Note. Vehicles fitted with supercharged engines shown, V8 NA and V6 engines similar.

Scheme 61

1. Set the heater controls to maximum HOT.
2. Remove the coolant expansion tank pressure cap.
3. Remove the radiator splash shield. Refer to «Radiator Splash Shield»(ref-311270-S23247288102009032500000) article.
4. Remove the coolant drain plug. Drain the coolant into a suitable container.
5. Install the coolant drain plug.

Vehicles with supercharger

Scheme 62

1. Disconnect the supercharger radiator bottom hose. Release the clip. Allow the coolant to drain.
2. Connect the supercharger bottom hose. Secure the clip.

All vehicles

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

1. Remove the suitable container.
2. Lower the vehicle.
3. Install the cooling system vacuum refill adaptor to the expansion tank.
4. Install the vacuum filler gauge to the cooling system vacuum refill adaptor.
5. Install the venturi tube assembly to the vacuum filler gauge.
6. Connect a regulated compressed air supply to the venturi tube assembly.
7. Position the coolant pick-up pipe into a container of clean coolant.
8. Position the evacuated air hose into a container.
9. Open the air supply valve.
10. Open the coolant supply valve for 2 seconds to prime the coolant supply hose.
11. Apply air pressure progressively until the arrow on the vacuum filler gauge reaches the green segment.
12. Close the air supply valve.
13. Allow one minute to check the vacuum is held. Disconnect the air supply.
14. Open the coolant supply valve and allow the coolant to be drawn into the system.
15. Remove the vacuum filler gauge and cooling system vacuum refill adaptor assembly.
16. Check and top up the cooling system if required.
17. Install the coolant expansion tank filler cap.

Vehicles with supercharger

Scheme 71

1. Remove the engine cover.
2. Remove the supercharger coolant filler plug. Remove and discard the sealing washer.
3. Top up the coolant through the supercharger fill port.
4. Switch ignition on.
5. Allow the supercharger pump to run and top up the coolant through supercharger fill port.
6. Switch the ignition off.
7. Install the supercharger coolant fill plug. Install a new sealing washer. Tighten to 45 Nm. Clean off any spillages.
8. Install the engine cover.

All vehicles

1. START and RUN the engine.
2. SET the heating system to MAX heat, the blower motor to MAX speed and the air distribution to instrument panel registers.
3. Allow the engine to RUN until hot air is emitted from the instrument panel registers, while observing the engine temperature gauge.
4. Switch off the engine.
5. Allow the engine to cool.
6. Check and top up the cooling system if required.

Cooling System Flushing - General Procedures

Vehicles with 2.5L or 3.0L engine

1. Remove the air cleaner. Refer to «Intake Air Distribution and Filtering»(ref-311276) article.

Vehicles with 4.2L engine

1. Remove the air cleaner. Refer to «Intake Air Distribution and Filtering»(ref-311275) article.

All vehicles

Scheme 72

Scheme 73

1. Remove the thermostat. «Thermostat - Removal and Installation (2.5L/3.0L)»(ref-311313-S37384767022009032500000) .
2. Detach the lower coolant hose from the radiator and position to one side.
3. Detach the upper coolant hose from the radiator. NOTE: To remove rust, sludge and other foreign material from the cooling system, use Premium Cooling System flush, meeting Jaguar specification EGR-M14P7-A, which is safe for use with aluminum cooling systems. This cleaning restores cooling system efficiency and helps prevent overheating. NOTE: In severe cases where cleaning solvents will not properly clean the cooling system, it will be necessary to use the pressure flushing method using Cooling System Flusher, 164-R3670 to restore efficient operation. NOTE: A pulsating or reversed direction of flushing water will loosen sediment more quickly than a steady flow in the normal coolant flow direction. NOTE: Dispose of old coolant and flushing water contaminated with coolant and cleaning chemicals in accordance with local, state and federal laws.
4. Connect a hose pipe to the radiator upper coolant hose connection using a suitable connector.
5. Flush the radiator using the hose pipe until the coolant flowing from the radiator lower coolant hose connection is clear.
6. Remove the hose pipe from the radiator upper coolant hose connection.
7. Connect a hose pipe to the upper coolant hose using a suitable connector.
8. Flush the engine using the hose pipe until the coolant flowing from the radiator lower coolant hose is clear.
9. Remove the hose pipe from the upper coolant hose connection.
10. Connect the upper coolant hose to the radiator.
11. Connect the lower coolant hose to the radiator.
12. Install the thermostat. «Thermostat - Removal and Installation (2.5L/3.0L)»(ref-311313-S37384767022009032500000) .
13. Fill the cooling system. «Cooling System Draining, Filling and Bleeding - General Procedures»(ref-311313-S39233980912009032500000) .

Vehicles with 2.5L or 3.0L engine

1. Install the air cleaner. Refer to «Intake Air Distribution and Filtering»(ref-311276) article.

Vehicles with 4.2L engine

1. Install the air cleaner. Refer to «Intake Air Distribution and Filtering»(ref-311275) article.
