Specifications
| Description | Specification |
|---|
| Jaguar Premium Cooling System Fluid | WSS M97B44-D |
| Jaguar Premium Cooling System Flush | EGR-M14P7-A |
Lubricants, Fluids, Sealers and Adhesives
| Description | Liters |
|---|
| Cooling system refill | 13.5 |
| Description | Nm |
|---|
| Coolant expansion tank retaining bolt | 7 |
| Coolant expansion tank bleed screw | 3 |
| Cooling fan motor and shroud retaining bolts | 7 |
| Water pump retaining bolts | 10 |
| Water pump pulley retaining bolts | 24 |
| Charge air cooler to radiator retaining bolts | 7 |
| Air conditioning condenser retaining bolts | 7 |
| Radiator mounting bracket retaining bolts | 7 |
| Charge air cooler intake elbow | 7 |
| Radiator drain plug | 2 |
Scheme 88
Scheme 88: Vehicles with Manual Transmission
| Item Number | Description |
|---|
| 1 | Coolant expansion tank |
| 2 | Engine coolant outlet |
| 3 | Vent hose |
| 4 | Radiator |
| 5 | Charge air cooler outlet |
| 6 | Auxiliary coolant flow pump |
| 7 | Cooling fan motor |
| 8 | Exhaust gas re-circulation coolant hose |
| 9 | Engine coolant inlet |
| 10 | Thermostat housing |
| 11 | Charge air cooler inlet |
Scheme 89
Scheme 89: Vehicles with Automatic Transmission
| Item Number | Description |
|---|
| 1 | Coolant expansion tank |
| 2 | Engine coolant outlet |
| 3 | Vent hose |
| 4 | Radiator |
| 5 | Charge air cooler outlet |
| 6 | Auxiliary coolant flow pump |
| 7 | Cooling fan motor |
| 8 | Exhaust gas re-circulation coolant hose |
| 9 | Transmission oil cooler coolant control valve |
| 10 | Engine coolant inlet |
| 11 | Transmission oil cooler inlet |
| 12 | Transmission oil cooler outlet |
| 13 | Thermostat housing |
| 14 | Charge air cooler inlet |
Scheme 90
Scheme 90: Engine Cooling System Components
| Item Number | Description |
|---|
| 1 | Engine coolant outlet assembly |
| 2 | Engine coolant inlet assembly |
| 3 | Water pump |
