Transmission/transaxle Cooling: Maintenance Jaguar S-type I

Loss of automatic transmission fluid

Possible Source(s)

1. Connections to the automatic transmission and the automatic transmission fluid cooler. Action(s) to take: Check the torque of the tubes, if correct, check the tubes and connections.

Loss of the automatic transmission fluid

Possible Source(s)

1. Leak at oil cooler. Action(s) to take: INSTALL new oil cooler.

Scheme 98

Scheme 99

Scheme 100

1. Remove the radiator. For additional information, refer to «RADIATOR»(ref-161157-S00051718852004032200000) for 4.0L.
2. Disconnect the power assisted steering hose from the oil cooler. Allow the fluid to drain into a suitable container.
3. Disconnect the power assisted steering hose from the reservoir.
4. Remove the oil cooler. Disconnect the transmission hoses. Remove the oil cooler.
