GENERAL SPECIFICATIONS

VehicleEngineApproximate LitersRefill Capacity Approximate dry capacity, includes cooler and tubes. Check the lever at normal operating temperature. DO NOT OVERFILL. If it is necessary to add or change fluid, use only fluid which has been certified by the supplier as meeting the Jaguar Cars Ltd specification shown. U.S. QuartsFluid Type
S-Type -5R55N3.0L9.09.5WSS-M2C 202B
S-Type -5R55N4.0L9.09.5WSS-M2C 202B

General Specifications Table

TORQUE SPECIFICATIONS

DescriptionNm
Converter housing to engine retaining bolts47
Crossmember retaining bolts50
Extension housing fill plug20
Intermediate shaft speed (ISS) sensor retaining nut10
Main control valve body retaining screws10
Manual valve detent spring10
Output shaft flange retaining nut131
Output shaft speed sensor (OSS) retaining screw10
Pressure switch retaining bolts10
Reverse servo cover retaining screws10
Torque converter flexplate (4.0L engine)28
Torque converter to flywheel retaining nuts38
Solenoid body retaining screws10
Transmission control body retaining screws10
Transmission cooler line retaining nut35
Transmission fluid filter retaining screws10
Transmission fluid pan drain plug26
Transmission fluid pan level plug10
Transmission fluid pan retaining screws10
Turbine shaft speed (TSS) sensor retaining screw10

Torque Specification

Scheme 28

Scheme 28: Transmission Fluid Draining
  1. Raise and support the vehicle.
  2. Place a suitable container under the transmission drain plug.
  3. Remove the transmission filler plug assembly.
  4. Remove the transmission drain plug assembly and drain the transmission fluid.

Scheme 29

Scheme 29: Transmission Fluid Filling

Scheme 30

Scheme 30
  1. Install the transmission drain plug assembly. Tighten to 26 Nm. (Scheme 29)
  2. Remove the transmission fluid level plug from the center of the transmission drain plug assembly.
  3. Fill the transmission until the fluid flows from the center of the transmission drain plug assembly. Use WSS-M2C 202B Automatic Transmission Fluid or equivalent meeting Jaguar specification.
  4. Install the transmission fluid level plug. Tighten to 10 Nm. (Scheme 30)
  5. Install the filler plug. Tighten to 20 Nm. (Scheme 28)

TORQUE DEMAND

The torque demand downshift occurs (automatically) during part throttle acceleration when the demand for torque is greater than the engine can provide at that gear ratio. If applied, the transmission will disengage the TCC to provide added acceleration.

TORQUE CONVERTER

The torque converter transmits and multiplies torque. The torque converter is a four-element device

  1. Impeller assembly.
  2. Turbine and damper assembly.
  3. Reactor assembly.
  4. Clutch.

The standard torque converter components operate as follows

  1. Rotation of the converter housing and impeller set the fluid in motion.
  2. The turbine reacts to the fluid motion from the impeller, transferring rotation to the geartrain through the input shaft.
  3. The reactor redirects fluid going back into the impeller, allowing for torque multiplication.
  4. The clutch and damper assembly dampens powertrain torsional vibration and provides a direct mechanical connection for improved efficiency.
  5. Power is transmitted from the torque converter to the planetary gear sets and other components through the input shaft.

Scheme 31

Scheme 31

Torque Converter Clutch (TCC) Solenoid

The torque converter clutch (TCC) solenoid is a pulse width modulating type solenoid which is used to control the apply and release of the TCC.
