Precautions For Harness Repair
ITS communication uses a twisted pair line. Be careful when repairing it.
Scheme 203
Scheme 204
- Solder the repaired area and wrap tape around the soldered area. NOTE: A fray of twisted lines must be within 110 mm (4.33 in).
- Bypass connection is never allowed at the repaired area. NOTE: Bypass connection may cause ITS communication error. The spliced wire becomes separated and the characteristics of twisted line are lost.
