Driver Assistance System (Adas Control Unit): Other Infiniti QX80 I

Input Signal Item

Output Signal Item

Fail-safe

If a malfunction occurs in each system, ADAS control unit cancels each control, sounds a beep, and turns ON the warning lamp or indicator lamp.

METHOD OF STARTING

Scheme 30

Scheme 31

1. Turn the ignition switch OFF.
2. Start the engine.
3. Wait for 5 seconds after starting the engine. Push up the RESUME/ACCELERATE switch 5 times and push down the SET/COAST switch 5 times within 10 seconds. NOTE: If the above operation cannot be performed within 10 seconds after waiting for 5 seconds after starting the engine, repeat the procedure from step 1 .
4. The DTC is displayed on the set vehicle speed indicator (1) on the ICC system display on the information display when the on board self-diagnosis starts. Refer to " «DTC INDEX»(ref-618063-S11257413822014052700000) ".

Note. It displays for up to 5 minutes and then stops. If multiple malfunctions exist, up to 6 DTCs can be stored in memory at the most, and the most recent one is displayed first.

WORK SUPPORT

Note. Causes of the maximum five cancellations (system cancel) are displayed. The displayed cancellation causes display the number of the ignition switch ON/OFF up to 254. It is fixed to 254 if it is over 254. It returns to 0 when the same cancellation cause is detected again.

Scheme 32

Scheme 33

Scheme 34

Scheme 35

DATA MONITOR

Note. The following table includes information (items) inapplicable to this vehicle. For information (items) applicable to this vehicle, refer to CONSULT display items.

Scheme 36

Scheme 37

Scheme 38

Scheme 39

METER LAMP

Note. The test can be performed only when the engine is running.

STOP LAMP

ICC BUZZER

BRAKE ACTUATOR

Note. The test can be performed only when the engine is running.

Note. The test is finished in 10 seconds after starting

Scheme 40

Active Pedal

Note. Depress the accelerator pedal to check when performing the test. The test can be performed only when the engine is running.

Note. The test is finished in 10 seconds after starting

Scheme 41

DCA INDICATOR

Note. The test can be performed only when the engine is running.

LDP BUZZER

WARNING SYSTEM IND

LDP ON IND

LANE DEPARTURE W/L

BSW/BSI WARNING LAMP

BSI ON INDICATOR

PHYSICAL VALUES

If a malfunction occurs in each system, ADAS control unit cancels each control, sounds a beep, and turns ON the warning lamp or indicator lamp.

CAN COMMUNICATION

CAN (Controller Area Network) is a serial communication line for real time applications. It is an on-vehicle multiplex communication line with high data communication speed and excellent error detection ability. Modern vehicle is equipped with many electronic control units, and each control unit shares information and links with other control units during operation (not independent). In CAN communication, control units are connected with 2 communication lines (CAN-H, CAN-L) allowing a high rate of information transmission with less wiring. Each control unit transmits/receives data but selectively reads the required data only.

CAN communication signal chart. Refer to " CAN COMMUNICATION SYSTEM: CAN COMMUNICATION SIGNAL CHART ".

ITS COMMUNICATION

1. ITS communication is a multiplex communication system. This enables the system to transmit and receive large quantities of data at high speed by connecting control units with 2 communication lines.
2. ITS communication lines adopt twisted-pair line style (two lines twisted) for noise immunity.
