METHODS OF PREVENTING OVER-DISCHARGE
The following precautions must be taken to prevent over-discharging a battery.
Scheme 18
Scheme 19
Scheme 20
- The battery surface (particularly its top) should always be kept clean and dry.
- The terminal connections should be clean and tight.
- At every routine maintenance, check the electrolyte level. This also applies to batteries designated as "low maintenance" and "maintenance-free".
- When the vehicle is not going to be used over a long period of time, disconnect the negative battery terminal.
- Check the charge condition of the battery. Periodically check the specific gravity of the electrolyte. Keep a close check on charge condition to prevent over-discharge.
CHECKING ELECTROLYTE LEVEL
| WARNING | Do not allow battery fluid to come in contact with skin, eyes, fabrics, or painted surfaces. After touching a battery, do not touch or rub your eyes until you have thoroughly washed your hands. If acid contacts eyes, skin or clothing, immediately flush with water for 15 minutes and seek medical attention. Remove the cell plug using a suitable tool. Add distilled water up to the MAX level. |
Scheme 21
Sulphation
A battery will be completely discharged if it is left unattended for a long time and the specific gravity will become less than 1.100. This may result in sulphation on the cell plates.
To determine if a battery has been "sulphated", note its voltage and current when charging it. As shown in the figure, less current and higher voltage are observed in the initial stage of charging sulphated batteries.
A sulphated battery may sometimes be brought back into service by means of a long, slow charge, 12 hours or more, followed by a battery capacity test.
Scheme 22
Scheme 23
- Read hydrometer and thermometer indications at eye level.
- Use the chart below to correct your hydrometer reading according to electrolyte temperature.
Hydrometer Temperature Correction
| Battery electrolyte temperature °C (°F) | Add to specific gravity reading |
|---|---|
| 71 (160) | 0.032 |
| 66(150) | 0.028 |
| 60(140) | 0.024 |
| 54(130) | 0.020 |
| 49(120) | 0.016 |
| 43(110) | 0.012 |
| 38 (100) | 0.008 |
| 32 (90) | 0.004 |
| 27 (80) | 0 |
| 21 (70) | 0.004 |
| 16(60) | 0.008 |
| 10 (50) | 0.012 |
| 4 (40) | 0.016 |
| 1 (30) | 0.020 |
| 7 (20) | 0.024 |
| 12(10) | 0.028 |
| 18(0) | 0.032 |
HYDROMETER TEMPERATURE CORRECTION
| Corrected specific gravity | Approximate charge condition |
|---|---|
| 1.260-1.280 | Fully charged |
| 1.230 - 1.250 | 3/4 charged |
| 1.200 - 1.220 | 1/2 charged |
| 1.170 - 1.190 | 1 /4 charged |
| 1.140-1.160 | Almost discharged |
| 1.110-1.130 | Completely discharged |
ADJUSTED APPROXIMATE CHARGE CONDITION
| CAUTION | Do not "quick charge" a fully discharged battery. Keep the battery away from open flame while it is being charged. When connecting the charger, connect the leads first, then turn on the charger. Do not turn on the charger first, as this may cause a spark. If battery electrolyte temperature rises above 55°C (131°F), stop charging. Always charge battery at a temperature below 55°C (131°F). |
Charging Rates
| Amps | Time |
|---|---|
| 50 | 1 hour |
| 25 | 2 hours |
| 10 | 5 hours |
| 5 | 10 hours |
CHARGING RATES
Do not charge at more than 50 ampere rate.
Note. The ammeter reading on your battery charger will automatically decrease as the battery charges. This indicates that the voltage of the battery is increasing normally as the state of charge improves. The charging amps indicated above refer to initial charge rate. If, after charging, the specific gravity of any two cells varies more than 0.050, the battery should be replaced.
| CAUTION | When working with batteries, always wear appropriate eye protection. |
Note. To ensure a complete and thorough diagnosis, the battery, starter and alternator test segments must be done as a set from start to finish. If battery surface charge is detected while testing, the tester will prompt you to turn on the headlamps to remove the surface charge. If necessary, the tester will prompt you to determine if the battery temperature is above or below 0°C (32°F). Choose the appropriate selection by pressing the up or down arrow button, then press "ENTER" to make the selection.
Scheme 24
Scheme 25
Scheme 26
Scheme 27
Scheme 28
- Turn off all loads on the vehicle electrical system. Clean or repair as necessary.
- Visually inspect the battery, battery terminals and cable ends with ignition switch in "OFF" position. NOTE: The contact surface between the battery terminals, cable ends and tester leads must be clean for a valid test. A poor connection will prevent testing and a "CHECK CONNECTION" message will appear during the test procedures. If this occurs, clean the battery post and terminals, reconnect them and restart the test.
- Connect the red tester lead clamp to the positive battery terminal, and the black to the negative terminal.
- The tester will turn on automatically. Using the arrow keys, select "IN VEHICLE" on the tester and then press the "ENTER" key.
- Locate the battery type and rating stamped or written on the top case of the battery to be tested. NOTE: The battery type and rating will have either of the following. CCA : Cold Cranking Amps (490 CCA, 550 CCA, etc.) JIS : Japanese Industrial Standard. Battery is stamped with a number such as: 80D26L: 80 (rank of output), D (physical size-depth), 26 (width in cm). The last character L (post configuration) is not input into the tester. The tester requires the rating for the battery be entered exactly as it is written or stamped on the battery. Do not attempt a CCA conversion for JIS stamped batteries. JIS must be input directly.
- Using the arrow and "ENTER" keys alternately, select the battery type and rating. NOTE: The tester lists five choices; CCA, JIS, IEC, DIN, and EN. Only use CCA or JIS.
- Press "ENTER" to begin the test. Diagnosis results are displayed on the tester. Refer to " «DIAGNOSTIC RESULT ITEM CHART»(ref-212940-S34976632852005122400000) ".
- Press "ENTER", then test output code is displayed. Record the test output code on the repair order.
- Toggle back to the "DIAGNOSTIC SCREEN" for test results. NOTE: If necessary, the tester will ask the user to determine if the battery has just been charged. Choose the appropriate selection by pressing the up or down arrow button and then press the "ENTER" button to make the selection. When testing a battery installed in a vehicle that has recently been driven, select "BEFORE CHANGE". If the battery has just been slow charged due to a "CHARGE & RETEST" decision by the tester, and the tester asks the user "BEFORE CHARGE/AFTER CHARGE", select "AFTER CHARGE".
