MULTIFUNCTION SWITCH AND PRESET SWITCH SELF-DIAGNOSIS FUNCTION
The ON/OFF operation (continuity) of each switch in the multifunction switch and preset switch can be checked.
Self-diagnosis Mode
- Press the "BACK" switch and the "UP" switch of the 8-direction switches within 10 seconds after turning the ignition switch from OFF to ACC and hold them for 3 seconds or more. Then the buzzer sounds, all indicators of the preset switch illuminate, and the self-diagnosis mode starts.
- The continuity of each switch at the ON position can be checked by pressing the switch. The buzzer sounds if the switch is normal.
Note. The hazard switch and disk eject switch cannot be checked.
Scheme 117
Finishing Self-diagnosis Mode
Self-diagnosis mode is canceled when turning the ignition switch OFF.
MULTI AV SYSTEM ON BOARD DIAGNOSIS FUNCTION
- The AV control unit diagnosis function starts up with multifunction switch operation and the AV control unit performs a diagnosis for each unit in the system during the on board diagnosis.
- Perform a CONSULT diagnosis if the on board diagnosis does not start, e.g., the screen does not display anything, the multifunction switch does not function, etc.
- Start the self-diagnosis function and select "Self Diagnosis". Self-diagnosis subdivision screen is displayed, and the self-diagnosis mode starts. The bar graph visible on the center of the self-diagnosis subdivision screen indicates progress of the trouble diagnosis.
- Diagnosis results are displayed after the self-diagnosis is completed. The unit names and the connection lines are color-coded according to the diagnostic results.
| Diagnosis results | Unit | Connection line |
|---|---|---|
| Normal | Green | Green |
| Connection malfunction | Gray | Yellow |
| Unit malfunction Note | Red | Green |
Scheme 118
Note. Control unit (AV control unit) and is displayed in red.
- Replace AV control unit if "Self-Diagnosis did not run because of a control unit malfunction" is indicated. The symptom is AV control unit internal error. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ".
- If multiple errors occur at the same time for a single unit, the screen switch colors are determined according to the following order of priority: red > gray. The comments of the self-diagnosis results can be viewed with a component in the diagnosis result screen.
Scheme 119
Detection Range of Self-diagnosis Mode
- The self-diagnosis mode allows the technician to diagnose the connection in the communication line between AV control unit and each unit and the internal operation of the AV control unit.
- Because the start condition of diagnosis function is a switch operation, the on board diagnosis function cannot be started up if any malfunction is detected in the communication circuit between AV control unit and multifunction switch.
SELF-DIAGNOSIS RESULTS
Check the applicable display at the following table, and then repair the malfunctioning parts
Only Unit Part Is Displayed In Red.
| Screen switch | Description | Possible malfunction location/Action to take |
|---|---|---|
| Control unit | Malfunction is detected in AV control unit power supply and ground circuits. | Check AV control unit power supply and ground circuits. When detecting no malfunction in those components, replace AV control unit. |
A Connecting Cable Between Units Is Displayed In Yellow.
| Area with yellow connection lines | Description | Possible malfunction location/Action to take |
|---|---|---|
| Control unit <=> Front Display | Malfunction is detected in serial communication circuits between AV control unit and front display unit. | Serial communication circuits between AV control unit and front display unit. |
| Control unit <=> SAT | When either one of the following items is detected: satellite radio tuner power supply and ground circuit malfunction is detected. malfunction is detected in communication circuits between AV control unit and satellite radio tuner. malfunction is detected in request signal circuit between AV control unit and satellite radio tuner. | Satellite radio tuner power supply and ground circuit. Communication circuit between AV control unit and satellite radio tuner. Request signal circuit between AV control unit and satellite radio tuner. |
| Control unit <=> BTHF | When either one of the following items is detected: TEL adapter unit power supply and ground circuits are malfunctioning. AV communication circuits between AV control unit and TEL adapter unit are malfunctioning. | TEL adapter unit power supply and ground circuits. AV communication circuits between AV control unit and TEL adapter unit are malfunctioning. |
Speaker Test
Select "Speaker Test" to display the Speaker Diagnosis screen. Press "Start" to generate a test tone in a speaker. Press "Start" again to generate a test tone in the next speaker. Press "End" to stop the test tones.
Scheme 120
Vehicle CAN Diagnosis
- CAN communication status and error counter is displayed.
- The error counter displays "OK" if any malfunction was not detected in the past and displays "0" if a malfunction is detected. It increases by 1 if the condition is normal at the next ignition switch ON cycle. The upper limit of the counter is 39.
- The error counter is erased if "Reset" is pressed.
| Items | Display (Current) | Malfunction counter (Past) |
|---|---|---|
| Tx(HVAC) | OK/??? | OK/0 - 39 |
| Rx(ECM) | OK/??? | OK/0 - 39 |
| Rx(Cluster) | OK/??? | OK/0 - 39 |
| Rx(BCM) | OK/??? | OK/0 - 39 |
| Rx(HVAC) | OK/??? | OK/0 - 39 |
| Rx(USM) | OK/??? | OK/0 - 39 |
| Rx(STRG) | OK/??? | OK/0 - 39 |
Scheme 121
Note. "???" indicates UNKWN.
AV COMM Diagnosis
- Displays the communication status between AV control unit (master unit) and each unit.
- The error counter displays "OK" if any malfunction was not detected in the past and displays "0" if a malfunction is detected. It increases by 1 if the condition is normal at the next ignition switch ON cycle. The upper limit of the counter is 39.
- The error counter is erased if "Reset" is pressed.
| Items | Status (Current) | Counter (Past) |
|---|---|---|
| C Tx(ITM-PrimarySW) | OK/??? | OK/0 - 39 |
| C Rx(PrimarySW-ITM) | OK/??? | OK/0 - 39 |
| C Rx(BTHF-ITM) | OK/??? | OK/0 - 39 |
Scheme 122
Note. "???" indicates UNKWN.
SELF DIAGNOSIS RESULT
- In CONSULT self-diagnosis, self-diagnosis results and error history are displayed collectively.
- The current malfunction indicates "CRNT". The past malfunction indicates "PAST".
- The timing is displayed as "0" if any of the error codes [U1000], [U1010], [U1300] and [U1310] is detected. The counter increases by 1 if the condition is normal at the next ignition switch ON cycle.
| Error item | Description | Possible malfunction factor/Action to take |
|---|---|---|
| CAN COMM CIRCUIT [U1000] | CAN communication malfunction is detected. | Refer to " DIAGNOSIS PROCEDURE ". |
| CONTROL UNIT (CAN) [U1010] | CAN initial diagnosis malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. |
| CONTROL UNIT (AV) [U1310] | AV communication circuit initial diagnosis malfunction is detected. | |
| Cont Unit [U1200] | AV control unit malfunction is detected. | |
| CAN CONT [U1216] | ||
| SUB CPU CONN [U1228] | ||
| IPod® CERTIFICATION [U1229] | ||
| Built-in AUDIO CONN [U122E] | ||
| USB CONTROLLER | [U1225] USB connection malfunction is detected. | Check that the connection to the USB connector is normal. |
| DSP CONN [U121D] | AV control unit malfunction is detected. | If a disc can be played, then there is a possibility of the detection of a temporary malfunction. Replace the AV control unit if the malfunction occurs constantly. |
| DSP COMM [U121E] | ||
| CONFIG UNFINISH [U122A] | The writing of configuration data is incomplete. | Write configuration data with CONSULT. |
| ST ANGLE SEN CALIB [U1232] | Predictive course line center position adjustment of the steering angle sensor is incomplete. | Adjust the predictive course line center position of the steering angle sensor. Refer to " ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION: SPECIAL REPAIR REQUIREMENT ". |
| FRONT DISP CONN [U1243] | When either one of the following items is detected: Front display unit power supply and ground circuits malfunction is detected. Communication circuits between AV control unit and front display unit. | Front display unit power supply and ground circuits. Communication circuits between AV control unit and front display unit. |
| SAT CONN [U1255] | When either one of the following items is detected: satellite radio tuner power supply and ground circuit malfunction is detected. malfunction is detected in communication circuits between AV control unit and satellite radio tuner. malfunction is detected in request signal circuit between AV control unit and satellite radio tuner. | Satellite radio tuner power supply and ground circuit. Communication circuit between AV control unit and satellite radio tuner. Request signal circuit between AV control unit and satellite radio tuner. |
| USB OVERCURRENT [U1263] | Detection of overcurrent in USB connector. | Check USB harness between the AV control unit and USB connector. |
| AV COMM CIRCUIT [U1300] SWITCH CONN [U1240] | When either one of the following items is detected: multifunction switch power supply and ground circuits are malfunctioning. AV communication circuits between AV control unit and multifunction switch are malfunctioning. | Multifunction switch power supply and ground circuits. AV communication circuits between AV control unit and multifunction switch. |
| AV COMM CIRCUIT [U1300] HAND FREE CONN [U1256] | When either one of the following items is detected: TEL adapter unit power supply and ground circuits are malfunctioning. AV communication circuits between AV control unit and TEL adapter unit are malfunctioning. | TEL adapter unit power supply and ground circuits. AV communication circuits between AV control unit and TEL adapter unit. |
| AV COMM CIRCUIT [U1300] SWITCH CONN [U1240] HAND FREE CONN [U1256] | Malfunction is detected in AV communication circuits between AV control unit and multifunction switch. | AV communication circuits between AV control unit and multifunction switch. |
SELF-DIAGNOSIS RESULTS DISPLAY ITEM LIST
HANDS-FREE PHONE SYSTEM ON BOARD DIAGNOSIS
During on board diagnosis the diagnosis function of TEL adapter unit starts with the operation of the steering switch and performs the diagnosis when ignition switch ACC.
ON BOARD DIAGNOSIS ITEM
The on board diagnosis has 3 modes: the self-diagnosis mode that performs the trouble diagnosis, the speaker adaptation data deleting mode and the hands-free phone system initialization mode.
| CAUTION | Perform the diagnosis with the vehicle stopped. Perform STEP2 if necessary. |
| STEP | MODE | Description |
|---|---|---|
| STEP1 | Self-diagnosis | The self-diagnosis mode performs the microphone test and the diagnosis of TEL adapter unit, TEL antenna and steering unit, and then reads out the results with the sound and indicates them on the display. |
| STEP2 | Speaker adaptation data deleting | The speaker adaptation data deleting mode can delete the speaker adaptation data. |
| Hands-free phone system initialization | Hands-free phone system initialization mode can perform the initialization of hands-free phone system. |
Self-diagnosis mode reads out the self-diagnosis results.
Note. Error count is read out simultaneously when reading out the DTC name. The errors are read out continuously when some errors occur at the same time.
Self-diagnosis results
| DTC | DTC name | Possible causes |
|---|---|---|
| DTC 10000 | INTERNAL FAILURE | TEL adapter unit |
| DTC 01000 | ANT. SHORT TO BATT OR OPEN | TEL antenna |
| DTC 00100 | ANT. SHORT TO GROUND | |
| DTC 00010 | STEERING REMOTE BUTTON STUCK A | Steering switch |
| DTC 00001 | STEERING REMOTE BUTTON STUCK B | |
| DTC 00000 | THERE ARE NO FAILURE RECORDS TO REPORT |
VALUES ON THE DIAGNOSIS TOOL
CONSULT MONITOR ITEM
| Monitor Item | Condition | Value/Status | |
|---|---|---|---|
| VHCL SPD SIG | Ignition switch ON | Vehicle speed > 0 km/h (0 MPH) | On |
| Vehicle speed = 0 km/h (0 MPH) | Off | ||
| PKB SIG | Ignition switch ON | Parking brake is applied. | On |
| Parking brake is released. | Off | ||
| ILLUM SIG | Ignition switch ON | Light switch ON | On |
| Light switch OFF | Off | ||
| IGN SIG | Ignition switch ON | On | |
| Ignition switch ACC | Off | ||
| REV SIG | Ignition switch ON | Selector lever in R position | On |
| Selector lever in any position other than R | Off | ||
Scheme 123
SELF-DIAGNOSIS RESULTS DISPLAY ITEM
| DTC | Display item | Refer to |
|---|---|---|
| U1000 | CAN COMM CIRCUIT [U1000] | " DIAGNOSIS PROCEDURE " |
| U1010 | CONTROL UNIT (CAN) [1010] | " DTC LOGIC " |
| U1200 | Cont Unit [U1200] | " DTC LOGIC " |
| U1216 | CAN CONT [U1216] | " DTC LOGIC " |
| U121D | DSP CONN [U121D] | " DIAGNOSIS PROCEDURE " |
| U121E | DSP COMM [U121E] | " DIAGNOSIS PROCEDURE " |
| U1225 | USB CONTROLLER [U1225] | " DTC LOGIC " |
| U1228 | SUB CPU CONN [U1228] | " DTC LOGIC " |
| U1229 | IPod® CERTIFICATION [U1229] | " DTC LOGIC " |
| U122A | CONFIG UNFINISH [U122A] | " DIAGNOSIS PROCEDURE " |
| U122E | Built-in AUDIO CONN [U122E] | " DTC LOGIC " |
| U1232 | ST ANGLE SEN CALIB [1232] | " DIAGNOSIS PROCEDURE " |
| U1243 | FRONT DISP CONN [U1243] | " DIAGNOSIS PROCEDURE " |
| U1255 | SAT CONN [U1255] | " DIAGNOSIS PROCEDURE " |
| U1263 | USB OVERCURRENT [U1263] | " DIAGNOSIS PROCEDURE " |
| U1310 | CONTROL UNIT (AV) [U1310] | " DTC LOGIC " |
| U1300 U1240 | AV COMM CIRCUIT [U1300] SWITCH CONN [U1240] | " DESCRIPTION " |
| U1300 U1256 | AV COMM CIRCUIT [U1300] HAND FREE CONN [U1256] | " DESCRIPTION " |
| U1300 U1240 U1256 | AV COMM CIRCUIT [U1300] SWITCH CONN [U1240] HAND FREE CONN [U1256] | " DESCRIPTION " |
AV CONTROL UNIT DTC INDEX
Scheme 124
DTC DETECTION LOGIC
| DTC | Display contents of CONSULT | DTC detection condition | Probable malfunction location |
|---|---|---|---|
| U1000 | CAN COMM CIRCUIT [U1000] | AV control unit is not transmitting or receiving CAN communication signal for 2 seconds or more. | CAN communication system. |
Diagnosis Procedure
- PERFORM SELF-DIAGNOSTIC Turn ignition switch ON and wait for 2 seconds or more. Check "Self Diagnostic Result" of "MULTI AV". Is "CAN COMM CIRCUIT" displayed? YES: Refer to "LAN system". Refer to " «TROUBLE DIAGNOSIS FLOW CHART»(ref-523993-S38740783062013012500000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ".
| DTC | Display contents of CONSULT | DTC detection condition | Probable malfunction factor |
|---|---|---|---|
| U1010 | CONTROL UNIT (CAN) [U1010] | CAN initial diagnosis malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. |
DTC Logic
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1200 | Cont Unit [U1200] | AV control unit malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. |
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1216 | CAN CONT [U1216] | AV control unit malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. |
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U121D | DSP CONN [U121D] | AV control unit malfunction is detected. | If a disc can be played, then there is a possibility of the detection of a temporary malfunction. Replace the AV control unit if the malfunction occurs constantly. |
- CHECK PLAYBACK OF A DISK (CD) Can a disk (CD) be played? YES: Malfunction may be detected transitory. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ".
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U121E | DSP COMM [U121E] | AV control unit malfunction is detected. | If a disc can be played, then there is a possibility of the detection of a temporary malfunction. Replace the AV control unit if the malfunction occurs constantly. |
- CHECK PLAYBACK OF A DISK (CD) Can a disk (CD) be played? YES: Malfunction may be detected transitory. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ".
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1225 | USB CONTROLLER [U1225] | USB connection malfunction is detected. | Check that the connection to the USB connector is normal. |
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1228 | SUB CPU CONN [U1228] | AV control unit malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. |
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1229 | IPod® CERTIFICATION [U1229] | AV control unit malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. |
| DTC | Display contents of CONSULT | DTC detection condition | Action to take |
|---|---|---|---|
| U122A | CONFIG UNFINISH [U122A] | The writing of configuration data is incomplete. | Write configuration data with CONSULT. |
- PERFORM THE SELF-DIAGNOSIS When U122A is detected, write configuration data with CONSULT. : Write configuration data with CONSULT. Refer to " «CONFIGURATION (AV CONTROL UNIT): WORK PROCEDURE»(ref-524059-S28285656052013012500000) ".
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U122E | Built-in AUDIO CONN [U122E] | AV control unit malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. |
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1232 | ST ANGLE SEN CALIB [1232] | Predictive course line center position adjustment of the steering angle sensor is incomplete. | Adjust the predictive course line center position of the steering angle sensor. |
- ADJUST THE PREDICTIVE COURSE LINE CENTER POSITION OF THE STEERING ANGLE SENSOR When U1232 is detected, adjust the predictive course line center position of the steering angle sensor. : Adjusts the steering angle sensor neutral position on ABS actuator and electrical unit (control unit) side. Refer to " «ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION: SPECIAL REPAIR REQUIREMENT»(ref-524026-S18933176772013012500000) ".
| DTC | Display contents of CONSULT | DTC Detection Condition | Possible causes |
|---|---|---|---|
| U1243 | FRONT DISP CONN [U1243] | When either one of the following items is detected: front display unit power supply and ground circuit malfunction is detected. malfunction is detected in communication circuits between front display unit and AV control unit. | Front display unit power supply and ground circuit. Communication circuits between front display unit and AV control unit. |
- CHECK FRONT DISPLAY UNIT POWER SUPPLY AND GROUND CIRCUITS Check front display unit power supply and ground circuits. Refer to " «FRONT DISPLAY UNIT: DIAGNOSIS PROCEDURE»(ref-524059-S21142680692013012500000) ". Is inspection result normal? YES: GO TO 2. NO: Repair malfunctioning parts.
- CHECK CONTINUITY COMMUNICATION CIRCUITS Turn ignition switch OFF. Disconnect front display unit connector and AV control unit connector. Check continuity between front display unit harness connector and AV control unit harness connector. Front display unit AV control unit Continuity Connector Terminals Connector Terminals M194 11 M202 70 Existed 22 71 Check continuity between front display unit harness connector and ground. Front display unit Ground Continuity Connector Terminals M194 11 Not existed 12 Is inspection result normal? YES: GO TO 3. NO: Repair harness or connector.
- CHECK COMMUNICATION SIGNAL Connect front display unit connector and AV control unit connector. Turn ignition switch ON. Check signal between front display unit harness connector and ground. (+) (-) Condition Reference value Front display unit Connector Terminal M194 11 Ground When adjusting display brightness. Is inspection result normal? YES: GO TO 4. NO: Replace AV control unit.
- CHECK COMMUNICATION SIGNAL Check signal between front display unit harness connector and ground. (+) (-) Condition Reference value Front display unit Connector Terminal M194 22 Ground When adjusting display brightness. Is inspection result normal? YES: INSPECTION END NO: Replace front display unit.
| DTC | Display contents of CONSULT | DTC Detection Condition | Possible causes |
|---|---|---|---|
| U1255 | SAT CONN [U1255] | When either one of the following items is detected: satellite radio tuner power supply and ground circuits malfunction is detected. malfunction is detected in communication circuits between AV control unit and satellite radio tuner. malfunction is detected in request signal circuit between AV control unit and satellite radio tuner. | Satellite radio tuner power supply and ground circuits. Communication circuits between AV control unit and satellite radio tuner. Request signal circuit between AV control unit and satellite radio tuner. |
- CHECK SATELLITE RADIO TUNER POWER SUPPLY AND GROUND CIRCUIT Check satellite radio tuner power supply and ground circuit. Refer to " «SATELLITE RADIO TUNER: DIAGNOSIS PROCEDURE»(ref-524059-S17333741362013012500000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair malfunctioning parts.
- CHECK CONTINUITY COMMUNICATION CIRCUIT AND REQUEST SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect AV control unit connector and satellite radio tuner connector. Check continuity between AV control unit harness connector and satellite radio tuner harness connector. AV control unit Satellite radio tuner Continuity Connector Terminals Connector Terminals M206 129 B236 8 Existed 130 9 122 10 Check continuity between AV control unit harness connector and ground. AV control unit Ground Continuity Connector Terminals M206 129 Not existed 130 122 Is the inspection result normal? YES: GO TO 3. NO: Repair harness or connector.
- CHECK AV CONTROL UNIT VOLTAGE Connect AV control unit connector. Turn ignition switch ON. Check voltage between AV control unit harness connector and ground. (+) (-) Voltage (Approx.) AV control unit Connector Terminals M206 129 Ground 7.5 V 130 7.0 V Is the inspection result normal? YES: GO TO 4. NO: Replace AV control unit.
- CHECK SATELLITE RADIO TUNER Turn ignition switch OFF. Disconnect AV control unit connector. Connect satellite radio tuner. Turn ignition switch ON. Check voltage between satellite radio tuner harness connector and ground. (+) (-) Voltage (Approx.) Satellite radio tuner Connector Terminal B236 10 Ground 7.0 V Is the inspection result normal? YES: INSPECTION END NO: Replace satellite radio tuner.
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1263 | USB OVERCURRENT [U1263] | Detection of overcurrent in USB connector. | Check USB harness between the AV control unit and USB connector. |
- CHECK USB HARNESS Visually check USB harness. Is the inspection result normal? YES: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ". NO: Replace USB harness.
| DTC | Display contents of CONSULT | DTC Detection Condition | Possible causes |
|---|---|---|---|
| U1300 U1240 | AV COMM CIRCUIT [U1300] SWITCH CONN [U1240] | When either one of the following items is detected: multifunction switch power supply and ground circuits are malfunctioning. AV communication circuits between AV control unit and multifunction switch are malfunctioning. | Multifunction switch power supply and ground circuits. AV communication circuits between AV control unit and multifunction switch. |
| U1300 U1256 | AV COMM CIRCUIT [U1300] HAND FREE CONN [U1256] | When either one of the following items is detected: TEL adapter unit power supply and ground circuits are malfunctioning. AV communication circuits between AV control unit and TEL adapter unit are malfunctioning. | TEL adapter unit power supply and ground circuits. AV communication circuits between AV control unit and TEL adapter unit. |
| U1300 U1240 U1256 | AV COMM CIRCUIT [U1300] SWITCH CONN [U1240] HAND FREE CONN [U1256] | Malfunction is detected in AV communication circuits between AV control unit and multifunction switch. | AV communication circuits between AV control unit and multifunction switch. |
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1310 | CONTROL UNIT (AV) [U1310] | An initial diagnosis error is detected in AV communication circuit. | Replace the AV control unit if the malfunction occurs constantly. |
AV CONTROL UNIT: Diagnosis Procedure
- CHECK FUSE Check for blown fuses. Power source Fuse No. Battery 34 Ignition switch ACC or ON 19 Is the inspection result normal? YES: GO TO 2. NO: Be sure to eliminate cause of malfunction before installing new fuse.
- CHECK POWER SUPPLY CIRCUIT Check voltage between AV control unit harness connectors and ground. Signal name Connector No. Terminal No. Ignition switch position Value (Approx.) Battery power supply M201 19 OFF Battery voltage ACC power supply M201 7 ACC Battery voltage Is the inspection result normal? YES: GO TO 3. NO: Check harness between AV control unit and fuse.
- CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect AV control unit connectors. Check continuity between AV control unit harness connectors and ground. Signal name Connector No. Terminal No. Ignition switch position Continuity Ground M201 20 OFF Existed Is the inspection result normal? YES: INSPECTION END NO: Repair harness or connector.
FRONT DISPLAY UNIT: Diagnosis Procedure
- CHECK POWER SUPPLY CIRCUIT (DISPLAY SIDE) Check voltage between display unit harness connector and ground. Signal name Connector No. Terminal No. Ignition switch position Value (Approx.) Inverter VCC M194 2 ACC 8.8 V Signal VCC 3 Is the inspection result normal? YES: GO TO 4 . NO: GO TO 2.
- CHECK POWER SUPPLY CIRCUIT (CONTINUITY) Turn ignition switch OFF. Disconnect the harness connector between front display unit and AV control unit. Check continuity between front display unit harness connector and AV control unit harness connector. Front display unit AV control unit Continuity Connector Terminal Connector Terminal M194 2 M202 48 Existed 3 36 Existed Check continuity between front display unit harness connector and ground. Front display unit Ground Continuity Connector Terminal M194 2 Not existed 3 Not existed Is the inspection result normal? YES: GO TO 3. NO: Repair harness or connector.
- CHECK POWER SUPPLY CIRCUIT (AV CONTROL UNIT SIDE) Connect the AV control unit harness connector. Turn ignition switch ACC. Check voltage between AV control unit harness connector and ground. (+) (-) Ignition switch position Voltage (Approx.) AV control unit Connector Terminal M202 48 Ground ACC 8.8 V 36 8.8 V Is the inspection result normal? YES: INSPECTION END NO: Replacement of AV control unit.
- CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect front display unit connector. Check continuity between front display unit harness connectors and ground. Signal name Connector No. Terminal No. Ignition switch position Continuity Ground M194 1 OFF Existed Is the inspection result normal? YES: INSPECTION END NO: Repair harness or connector.
BOSE AMP.: Diagnosis Procedure
- CHECK FUSE Check for blown fuses. Power source Fuse No. Battery 8 Is the inspection result normal? YES: GO TO 2. NO: Be sure to eliminate cause of malfunction before installing new fuse.
- CHECK POWER SUPPLY CIRCUIT Check voltage between BOSE amp. harness connector and ground. Signal name Connector No. Terminal No. Ignition switch position Value (Approx.) Battery power supply B42 11 OFF Battery voltage Is the inspection result normal? YES: GO TO 3. NO: Check harness between BOSE amp. and fuse.
- CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect BOSE amp. connector. Check continuity between BOSE amp. harness connector and ground. Signal name Connector No. Terminal No. Ignition switch position Continuity Ground B42 12 OFF Existed Is the inspection result normal? YES: INSPECTION END NO: Repair harness or connector.
SATELLITE RADIO TUNER: Diagnosis Procedure
- CHECK FUSE Check for blown fuses. Power source Fuse No. Battery 34 Ignition switch ACC or ON 19 Is the inspection result normal? YES: GO TO 2. NO: Be sure to eliminate cause of malfunction before installing new fuse.
- CHECK POWER SUPPLY CIRCUIT Check voltage between satellite radio tuner harness connector and ground. Signal name Connector No. Terminal No. Ignition switch position Value (Approx.) Battery power supply B236 12 OFF Battery voltage ACC power supply B236 16 ACC Battery voltage Is the inspection result normal? YES: INSPECTION END NO: Check harness between satellite radio tuner and fuse.
TEL ADAPTER UNIT: Diagnosis Procedure
- CHECK FUSE Check for blown fuses. Power source Fuse No. Battery 34 Ignition switch ACC or ON 19 Is the inspection result normal? YES: GO TO 2. NO: Be sure to eliminate cause of malfunction before installing new fuse.
- CHECK POWER SUPPLY CIRCUIT Check voltage between TEL adapter unit harness connector and ground. Signal name Connector No. Terminal No. Ignition switch position Value (Approx.) Battery power supply B87 1 OFF Battery voltage ACC power supply B87 2 ACC Battery voltage Is the inspection result normal? YES: GO TO 3. NO: Check harness between TEL adapter unit and fuse.
- CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect TEL adapter unit connector. Check continuity between TEL adapter unit harness connector and ground. Signal name Connector No. Terminal No. Ignition switch position Continuity Ground B87 4 OFF Existed Is the inspection result normal? YES: INSPECTION END NO: Repair harness or connector.
- CHECK CONTINUITY RGB (G: GREEN) SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect front display unit connector and AV control unit connector. Check continuity between front display unit harness connector and AV control unit harness connector. Front display unit AV control unit Continuity Connector Terminal Connector Terminal M194 6 M202 44 Existed Check continuity between front display unit harness connector and ground. Front display unit Ground Continuity Connector Terminal M194 6 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK RGB (G: GREEN) SIGNAL Connect front display unit connector and AV control unit connector. Turn ignition switch ON. Check signal between front display unit harness connector and ground. (+) (-) Condition Reference value Front display unit Connector Terminal M194 6 Ground Start confirmation/adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on DISPLAY DIAGNOSIS screen. Is the inspection result normal? YES: Replace front display unit. Refer to " «EXPLODED VIEW»(ref-524059-S32556523132013012500000) ". NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ".
- CHECK CONTINUITY RGB SYNCHRONIZING SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect front display unit connector and AV control unit connector. Check continuity between front display unit harness connector and AV control unit harness connector. Front display unit AV control unit Continuity Connector Terminal Connector Terminal M194 19 M202 42 Existed Check continuity between front display unit harness connector and ground. Front display unit Ground Continuity Connector Terminal M194 19 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK RGB SYNCHRONIZING SIGNAL Connect front display unit connector and AV control unit connector. Turn ignition switch ON. Check signal between front display unit harness connector and ground. (+) (-) Reference value Front display unit Connector Terminal M194 19 Ground Is the inspection result normal? YES: Replace front display unit. Refer to " «EXPLODED VIEW»(ref-524059-S32556523132013012500000) ". NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ".
- CHECK CONTINUITY RGB AREA (YS) SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect front display unit connector and AV control unit connector. Check continuity between front display unit harness connector and AV control unit harness connector. Front display unit AV control unit Continuity Connector Terminal Connector Terminal M194 9 M202 40 Existed Check continuity between front display unit harness connector and ground. Front display unit Ground Continuity Connector Terminal M194 9 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK RGB AREA (YS) SIGNAL Connect front display unit connector and AV control unit connector. Turn ignition switch ON. Check signal between front display unit harness connector and ground. (+) (-) Condition Reference value (Approx.) Front display unit Connector Terminal M194 9 Ground At RGB image is displayed 5.0 V At camera image is displayed Is the inspection result normal? YES: Replace front display unit. Refer to " «EXPLODED VIEW»(ref-524059-S32556523132013012500000) ". NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ".
- CHECK CONTINUITY HORIZONTAL SYNCHRONIZING (HP) SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect front display unit connector and AV control unit connector. Check continuity between front display unit harness connector and AV control unit harness connector. Front display unit AV control unit Continuity Connector Terminal Connector Terminal M194 8 M202 38 Existed Check continuity between front display unit harness connector and ground. Front display unit Ground Continuity Connector Terminal M194 8 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK HORIZONTAL SYNCHRONIZING (HP) SIGNAL Connect front display unit connector and AV control unit connector. Turn ignition switch ON. Check signal between front display unit harness connector and ground. (+) (-) Reference value Front display unit Connector Terminal M194 8 Ground Is the inspection result normal? YES: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ". NO: Replace front display unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ".
- CHECK CONTINUITY VERTICAL SYNCHRONIZING (VP) SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect front display unit connector and AV control unit connector. Check continuity between front display unit harness connector and AV control unit harness connector. Front display unit AV control unit Continuity Connector Terminal Connector Terminal M194 20 M202 50 Existed Check continuity between front display unit harness connector and ground. Front display unit Ground Continuity Connector Terminal M194 20 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK VERTICAL SYNCHRONIZING (VP) SIGNAL Connect front display unit connector and AV control unit connector. Turn ignition switch ON. Check signal between front display unit harness connector and ground. (+) (-) Reference value Front display unit Connector Terminal M194 20 Ground Is the inspection result normal? YES: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ". NO: Replace front display unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ".
- CHECK CONTINUITY CAMERA POWER SUPPLY CIRCUIT Turn ignition switch OFF. Disconnect AV control unit connector and rear view camera connector. Check continuity between AV control unit harness connector and rear view camera harness connector. AV control unit Rear view camera Continuity Connector Terminal Connector Terminal M203 73 D121 1 Existed Check continuity between AV control unit harness connector and ground. AV control unit Ground Continuity Connector Terminal M203 73 Not existed Is inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK VOLTAGE CAMERA POWER SUPPLY Connect AV control unit connector and rear view camera connector. Turn ignition switch ON. Shift the selector lever to "R". Check voltage between AV control unit harness connector and ground. (+) (-) Condition Voltage (Approx.) AV control unit Connector Terminal M203 73 Ground Shift position is "R". 6.0 V Is inspection result normal? YES: GO TO 3. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ".
- CHECK CONTINUITY CAMERA IMAGE SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect AV control unit connector and rear view camera connector. Check continuity between AV control unit harness connector and rear view camera harness connector. AV control unit Rear view camera Continuity Connector Terminal Connector Terminal M203 62 D121 3 Existed Check continuity between AV control unit harness connector and ground. AV control unit Ground Continuity Connector Terminal M203 62 Not existed Is inspection result normal? YES: GO TO 4. NO: Repair harness or connector.
- CHECK CAMERA IMAGE SIGNAL Connect AV control unit connector and rear view camera connector. Turn ignition switch ON. Shift the selector lever to "R". Check signal between AV control unit harness connector and ground. (+) (-) Condition Reference value AV control unit Connector Terminal M203 62 Ground At rear view camera image is displayed. Is inspection result normal? YES: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ". NO: Replace rear view camera. Refer to " «EXPLODED VIEW»(ref-524059-S26808428712013012500000) ".
- CHECK CONTINUITY DISK EJECT SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect multifunction switch connector and AV control unit connector. Check continuity between multifunction switch harness connector and AV control unit harness connector. Multifunction switch AV control unit Continuity Connector Terminal Connector Terminal M72 14 M204 96 Existed Check continuity between multifunction switch harness connector and ground. Multifunction switch Ground Continuity Connector Terminal M72 14 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK AV CONTROL UNIT VOLTAGE Connect AV control unit connector. Turn ignition switch ON. Check voltage between AV control unit harness connector and ground. (+) (-) Reference value (Approx.) AV control unit Connector Terminal M204 96 Ground 3.3 V Is the inspection result normal? YES: Replace preset switch. Refer to " «EXPLODED VIEW»(ref-524059-S39258867732013012500000) ". NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ".
- CHECK CONTINUITY COMPOSITE IMAGE SIGNAL CIRCUIT (AV CONTROL UNIT TO FRONT DISPLAY UNIT) Turn ignition switch OFF. Disconnect AV control unit connector and front display unit connector. Check continuity between AV control unit harness connector and front display unit harness connector. AV control unit Front display unit Continuity Connector Terminal Connector Terminal M202 47 M194 15 Existed Check continuity between AV control unit harness connector and ground. AV control unit Ground Continuity Connector Terminal M202 47 Not existed Is inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK COMPOSITE IMAGE SIGNAL (AV CONTROL UNIT TO FRONT DISPLAY UNIT) Connect AV control unit connector and front display unit connector. Turn ignition switch ON. Check signal between AV control unit harness connector and ground. (+) (-) Condition Reference value AV control unit Connector Terminal M202 47 Ground At rear view camera image is displayed. Is inspection result normal? YES: Replace front display unit. Refer to " «EXPLODED VIEW»(ref-524059-S32556523132013012500000) ". NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ".
- CHECK CONTINUITY BETWEEN TEL ADAPTER UNIT AND MICROPHONE CIRCUIT Turn ignition switch OFF. Disconnect TEL adapter unit connector and microphone connector. Check continuity between TEL adapter unit harness connector and microphone harness connector. TEL adapter unit Microphone Continuity Connector Terminals Connector Terminals B87 7 R17 1 Existed 8 2 29 4 Check continuity between TEL adapter unit harness connector and ground. TEL adapter unit Ground Continuity Connector Terminals B87 7 Not existed 29 Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK VOLTAGE MICROPHONE VCC Connect TEL adapter unit connector. Turn ignition switch ON. Check voltage between TEL adapter unit harness connector. (+) (-) Voltage (Approx.) TEL adapter unit TEL adapter unit Connector Terminal Connector Terminal B87 29 B87 8 5.0 V Is the inspection result normal? YES: GO TO 3. NO: Replace TEL adapter unit. Refer to " «EXPLODED VIEW»(ref-524059-S31346379882013012500000) ".
- CHECK MICROPHONE SIGNAL Turn ignition switch OFF. Connect microphone connector. Turn ignition switch ON. Check signal between TEL adapter unit harness connector. (+) (-) Condition Reference value TEL adapter unit TEL adapter unit Connector Terminal Connector Terminal B87 7 B87 8 Give a voice. Is the inspection result normal? YES: Replace TEL adapter unit. Refer to " «EXPLODED VIEW»(ref-524059-S31346379882013012500000) ". NO: Replace microphone. Refer to " «EXPLODED VIEW»(ref-524059-S10975714842013012500000) ".
- CHECK CONTINUITY CONTROL SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect TEL adapter unit connector. Check continuity between TEL adapter unit harness connector and ground. TEL adapter unit Ground Continuity Connector Terminals B87 20 Existed 23 24 Is the inspection result normal? YES: Replace TEL adapter unit. NO: Repair harness or connector.
- CHECK CONTINUITY MODE CHANGE SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect BOSE amp. connector and AV control unit connector. Check continuity between BOSE amp. harness connector and AV control unit harness connector. BOSE amp. AV control unit Continuity Connector Terminal Connector Terminal B41 17 M206 128 Existed Check continuity between BOSE amp. harness connector and ground. BOSE amp. Ground Continuity Connector Terminal B41 17 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK MODE CHANGE SIGNAL Connect BOSE amp. connector. Turn ignition switch ON. Check signal between BOSE amp. harness connector and ground. (+) (-) Condition Voltage (Approx.) BOSE amp. Connector Terminal B41 17 Ground Driver's Audio Stage ON 0 V Driver's Audio Stage OFF 8.5 V Is the inspection result normal? YES: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ". NO: Replace BOSE amp. Refer to " «EXPLODED VIEW»(ref-524059-S36816023772013012500000) ".
- CHECK CONTINUITY COMMUNICATION SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect satellite radio tuner connector and AV control unit connector. Check continuity between satellite radio tuner harness connector and AV control unit harness connector. Satellite radio tuner AV control unit Continuity Connector Terminals Connector Terminals B236 9 M206 130 Existed 10 122 Check continuity between satellite radio tuner harness connector and ground. Satellite radio tuner Ground Continuity Connector Terminals B236 9 Not existed 10 Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK COMMUNICATION SIGNAL (SAT-->CONT) Connect satellite radio tuner connector and AV control unit connector. Turn ignition switch ON. Check signal between satellite radio tuner harness connector and ground. (+) (-) Condition Reference value Satellite radio tuner Connector Terminal B236 9 Ground When satellite radio mode is selected. Is the inspection result normal? YES: GO TO 3. NO: Replace satellite radio tuner. Refer to " «EXPLODED VIEW»(ref-524059-S05127930762013012500000) ".
- CHECK COMMUNICATION SIGNAL (CONT-->SAT) Check signal between satellite radio tuner harness connector and ground. (+) (-) Condition Reference value Satellite radio tuner Connector Terminal B236 10 Ground When satellite radio mode is selected. Is the inspection result normal? YES: Replace satellite radio tuner. Refer to " «EXPLODED VIEW»(ref-524059-S05127930762013012500000) ". NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ".
- CHECK CONTINUITY REQUEST SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect satellite radio tuner connector and AV control unit connector. Check continuity between satellite radio tuner unit harness connector and AV control unit harness connector. Satellite radio tuner AV control unit Continuity Connector Terminal Connector Terminal B236 8 M206 129 Existed Check continuity between satellite radio tuner harness connector and ground. Satellite radio tuner Ground Continuity Connector Terminal B236 8 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK COMMUNICATION SIGNAL Connect satellite radio tuner connector and AV control unit connector. Turn ignition switch ON. Check signal between satellite radio tuner harness connector and ground. (+) (-) Condition Reference value Satellite radio tuner Connector Terminal B236 8 Ground When satellite radio mode is selected. Is the inspection result normal? YES: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ". NO: Replace satellite radio tuner. Refer to " «EXPLODED VIEW»(ref-524059-S05127930762013012500000) ".
- CHECK STEERING SWITCH SIGNAL A CIRCUIT Disconnect AV control unit connector and spiral cable connector. Check continuity between AV control unit harness connector and spiral cable harness connector. AV control unit Spiral cable Continuity Connector Terminal Connector Terminal M201 6 M36 24 Existed Check continuity between AV control unit harness connector and ground. AV control unit Ground Continuity Connector Terminal M201 6 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK SPIRAL CABLE Check spiral cable. Is the inspection result normal? YES: GO TO 3. NO: Replace spiral cable. Refer to " «EXPLODED VIEW»(ref-523991-S30900375582013012500000) ".
- CHECK AV CONTROL UNIT VOLTAGE Connect AV control unit connector and spiral cable connector. Turn ignition switch ON. Check voltage between AV control unit harness connector. (+) (-) Voltage (Approx.) AV control unit AV control unit Connector Terminal Connector Terminal M201 6 M201 15 3.3 V Is the inspection result normal? YES: GO TO 4. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ".
- CHECK STEERING SWITCH Turn ignition switch OFF. Check steering switch. Refer to " «COMPONENT INSPECTION»(ref-524059-S11921132492013012500000) ". Is the inspection result normal? YES: INSPECTION END NO: Replace steering switch. Refer to " «EXPLODED VIEW»(ref-523991-S13963794372013012500000) ".
Component Inspection
Measure the resistance between the steering switch connector terminals 14 to 17 and 15 to 17.
Standard
Between terminals 14 and 17
TALK/PHONE switch ON: Approx. 716 - 730 ohms
MENU DOWN switch ON: Approx. 318 - 324 ohms
MENU UP switch ON: Approx. 120 - 122 ohms
SOURCE switch ON: Approx. 0 ohms
Between terminals 15 and 17
END CALL switch ON: Approx. 318 - 324 ohms
VOL UP switch ON: Approx. 120 - 122 ohms
VOL DOWN switch ON: Approx. 0 ohms
Scheme 125
- CHECK STEERING SWITCH SIGNAL B CIRCUIT Disconnect AV control unit connector and spiral cable connector. Check continuity between AV control unit harness connector and spiral cable harness connector. AV control unit Spiral cable Continuity Connector Terminal Connector Terminal M201 16 M36 31 Existed Check continuity between AV control unit harness connector and ground. AV control unit Ground Continuity Connector Terminal M201 16 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK SPIRAL CABLE Check spiral cable. Is the inspection result normal? YES: GO TO 3. NO: Replace spiral cable. Refer to " «EXPLODED VIEW»(ref-523991-S30900375582013012500000) ".
- CHECK AV CONTROL UNIT VOLTAGE Connect AV control unit connector and spiral cable connector. Turn ignition switch ON. Check voltage between AV control unit harness connector. (+) (-) Voltage (Approx.) AV control unit AV control unit Connector Terminal Connector Terminal M201 16 M201 15 3.3 V Is the inspection result normal? YES: GO TO 4. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ".
- CHECK STEERING SWITCH Turn ignition switch OFF. Check steering switch. Refer to " «COMPONENT INSPECTION»(ref-524059-S12610480782013012500000) ". Is the inspection result normal? YES: INSPECTION END NO: Replace steering switch. Refer to " «EXPLODED VIEW»(ref-523991-S13963794372013012500000) ".
Measure the resistance between the steering switch connector terminals 14 to 17 and 15 to 17.
Standard
Between terminals 14 and 17
TALK/PHONE switch ON: Approx. 716 - 730 ohms
MENU DOWN switch ON: Approx. 318 - 324 ohms
MENU UP switch ON: Approx. 120 - 122 ohms
SOURCE switch ON: Approx. 0 ohms
Between terminals 15 and 17
END CALL switch ON: Approx. 318 - 324 ohms
VOL UP switch ON: Approx. 120 - 122 ohms
VOL DOWN switch ON: Approx. 0 ohms
- CHECK STEERING SWITCH SIGNAL GND CIRCUIT Disconnect AV control unit connector and spiral cable connector. Check continuity between AV control unit harness connector and spiral cable harness connector. AV control unit Spiral cable Continuity Connector Terminal Connector Terminal M201 15 M36 33 Existed Connect AV control unit connector. Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK SPIRAL CABLE Check spiral cable. Is the inspection result normal? YES: GO TO 3. NO: Replace spiral cable. Refer to " «EXPLODED VIEW»(ref-523991-S30900375582013012500000) ".
- CHECK GROUND CIRCUIT Connect AV control unit connector. Check continuity between AV control unit harness connector and ground. AV control unit Ground Continuity Connector Terminal M201 15 Not existed Is the inspection result normal? YES: GO TO 4. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-524059-S32709120162013012500000) ".
- CHECK STEERING SWITCH Turn ignition switch OFF. Check steering switch. Refer to " «COMPONENT INSPECTION»(ref-524059-S22584515282013012500000) ". Is the inspection result normal? YES: INSPECTION END NO: Replace steering switch. Refer to " «EXPLODED VIEW»(ref-523991-S13963794372013012500000) ".
Measure the resistance between the steering switch connector terminals 14 to 17 and 15 to 17.
Standard
Between terminals 14 and 17
TALK/PHONE switch ON: Approx. 716 - 730 ohms
MENU DOWN switch ON: Approx. 318 - 324 ohms
MENU UP switch ON: Approx. 120 - 122 ohms
SOURCE switch ON: Approx. 0 ohms
Between terminals 15 and 17
END CALL switch ON: Approx. 318 - 324 ohms
VOL UP switch ON: Approx. 120 - 122 ohms
VOL DOWN switch ON: Approx. 0 ohms
