Audio, Visual & Navigation System (Navigation): Removal & Installation Infiniti FX50 II рестайлинг

Entertainment Systems 33 illustrations ~1140 words

BEFORE REPLACEMENT

When replacing AV control unit, save or print current vehicle specification with CONSULT configuration before replacement.

AFTER REPLACEMENT

CAUTIONWhen replacing AV control unit, you must perform "After Replace ECU" or "Manual Configuration" with CONSULT.
  1. Complete the procedure of "After Replace ECU" or "Manual Configuration" in order.
  2. If you set incorrect "After Replace ECU" or "Manual Configuration", incidents might occur.
  3. Configuration is different for each vehicle model. Confirm configuration of each vehicle model.

Removal and Installation

CAUTIONBefore replacing AV control unit, perform "READ CONFIGURATION" to save or print current vehicle specification. For details, refer to " ADDITIONAL SERVICE WHEN REPLACING AV CONTROL UNIT: DESCRIPTION ". Remove battery terminal and AV control unit after a lapse of 30 seconds or more after turning the ignition switch OFF.

Note. After the ignition switch is turned OFF, the AV control unit continues operating for approximately 30 seconds. Therefore, data corruption may occur if battery voltage is cut off within 30 seconds.

REMOVAL

  1. Remove front display unit. Refer to " «EXPLODED VIEW»(ref-523997-S07380420072013012500000) ".
  2. Remove AV control unit with a unified meter and A/C amp. as a single unit from the body.
  3. Remove bracket screws, and then remove AV control unit.

INSTALLATION

Installation is the reverse order of removal.

CAUTIONSince AV control unit connector and unified meter and A/C amp. connector have the same form, be careful not to insert them wrongly. Be sure to perform "WRITE CONFIGURATION" when replacing AV control unit.

Scheme 24

Scheme 24: REMOVAL
Scheme 24: REMOVAL

Scheme 25

Scheme 25: DISASSEMBLY
Scheme 25: DISASSEMBLY
  1. Remove cluster lid D. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
  2. Remove front display unit mounting screws.
  3. Disconnect connector, and remove front display unit.

Installation is the reverse order of removal.

Scheme 26

Scheme 26: Exploded View
Scheme 26: Exploded View
  1. Remove front door finisher. Refer to " «EXPLODED VIEW»(ref-524011-S09991688552013012500000) ".
  2. Remove front door speaker mounting bolts.
  3. Disconnect connector and remove front door speaker.

Installation is the reverse order of removal.

Scheme 27

Scheme 27: Exploded View
Scheme 27: Exploded View
  1. Remove rear door finisher. Refer to " «EXPLODED VIEW»(ref-524011-S42629557552013012500000) ".
  2. Remove rear door speaker mounting bolts.
  3. Disconnect connector and remove rear door speaker.

Installation is the reverse order of removal.

Scheme 28

Scheme 28: Exploded View
Scheme 28: Exploded View
  1. Remove speaker grille. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
  2. Remove front squawker mounting screws.
  3. Disconnect connector and remove front squawker.

Installation is the reverse order of removal.

Scheme 29

Scheme 29: Exploded View
Scheme 29: Exploded View
  1. Remove luggage side finisher upper. Refer to " «EXPLODED VIEW»(ref-524011-S25532630132013012500000) ".
  2. Remove rear squawker mounting screws.
  3. Remove rear squawker.

Installation is the reverse order of removal.

Scheme 30

Scheme 30: Exploded View
Scheme 30: Exploded View
  1. Remove center speaker grille. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
  2. Remove center speaker mounting screws, lift up the center speaker and disconnect connector.
  3. Remove center speaker.

Installation is the reverse order of removal.

Scheme 31

Scheme 31: Exploded View
Scheme 31: Exploded View
  1. Pull up luggage finisher cover and hang the strap to upper body.
  2. Remove woofer clamp.
  3. Remove harness clip and connector.
  4. Remove woofer.

Installation is the reverse order of removal.

Scheme 32

Scheme 32: REMOVAL
Scheme 32: REMOVAL

Scheme 33

Scheme 33: DISASSEMBLY
Scheme 33: DISASSEMBLY
  1. Remove luggage floor spacer (LH). Refer to " «EXPLODED VIEW»(ref-524011-S25532630132013012500000) ".
  2. Remove BOSE amp. mounting nuts.
  3. Disconnect connector and remove BOSE amp.

Installation is the reverse order of removal.

Scheme 34

Scheme 34: Exploded View
Scheme 34: Exploded View
  1. Remove headlining (rear). Keep a service area. Refer to " «EXPLODED VIEW»(ref-524011-S05519117592013012500000) ".
  2. Remove antenna base mounting nut.
  3. Disconnect connector and remove antenna base.

Installation is the reverse order of removal.

CAUTIONBe careful about tightening torque. Antenna sensitivity becomes poor, and when it is excessive, roof panel may be deformed, when antenna base mounting nut tightening torque is loose.

Refer to " EXPLODED VIEW ".

Scheme 35

Scheme 35: DISASSEMBLY
Scheme 35: DISASSEMBLY
  1. Remove cluster lid D. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
  2. Remove multifunction switch mounting screws.
  3. Disconnect connector and remove multifunction switch.

Installation is the reverse order of removal.

Refer to " EXPLODED VIEW ".

Scheme 36

Scheme 36: DISASSEMBLY
Scheme 36: DISASSEMBLY
  1. Remove cluster lid C. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
  2. Remove preset switch mounting screws (A), (B) and (C).
  3. Disconnect connector and remove preset switch (2).

Scheme 37

Scheme 37
Scheme 37

Installation is the reverse order of removal.

Note. When installing preset switch, do not allow the print wire that connects preset switch and multifunction switch to get caught in between AV control unit and preset switch.

Scheme 38

Scheme 38: Exploded View
Scheme 38: Exploded View
  1. Remove console box assembly. Refer to " «EXPLODED VIEW»(ref-524023-S26869316852013012500000) ".
  2. Press the pawl from the back of console box assembly to remove USB connector.

Install in the reverse order of removal.

Refer to " EXPLODED VIEW ".

Scheme 39

Scheme 39: DISASSEMBLY
Scheme 39: DISASSEMBLY
  1. Remove map lamp assembly. Refer to " «EXPLODED VIEW»(ref-524011-S05519117592013012500000) ".
  2. Remove microphone, stretching pawls of map lamp assembly.

Installation is the reverse order of removal.

Scheme 40

Scheme 40: Exploded View
Scheme 40: Exploded View
  1. Remove instrument panel. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
  2. Remove GPS antenna mounting screw.
  3. Remove GPS antenna (1).

Scheme 41

Scheme 41
Scheme 41

Installation is the reverse order of removal.

Scheme 42

Scheme 42: Feeder Layout
Scheme 42: Feeder Layout

Scheme 43

Scheme 43: Exploded View
Scheme 43: Exploded View
  1. Remove front seat (LH side). Refer to " «EXPLODED VIEW»(ref-524039-S06437319262013012500000) ".
  2. Remove floor carpet. Keep a service area.
  3. Remove around view monitor control unit mounting screws.
  4. Disconnect connector and remove around view monitor control unit.
  1. Installation is the reverse order of removal.
  2. Perform camera image calibration. Refer to " «CALIBRATING CAMERA IMAGE (AROUND VIEW MONITOR): WORK PROCEDURE»(ref-523997-S40302317082013012500000) ".
  3. Perform predictive course line center position adjustment. Refer to " «PREDICTIVE COURSE LINE CENTER POSITION ADJUSTMENT: WORK PROCEDURE»(ref-523997-S30096446142013012500000) ".
CAUTIONPerform the calibration and perform the writing to the around view monitor control unit when removing and replacing each camera, removing the camera mounting parts (front grille, door mirror, etc.) and replacing the around view monitor control unit.

Scheme 44

Scheme 44: Exploded View
Scheme 44: Exploded View
  1. Remove front camera finisher.
  2. Remove front camera mounting rivet.
  3. Remove front camera.
  1. Installation is the reverse order of removal.
  2. Perform camera image calibration. Refer to " «CALIBRATING CAMERA IMAGE (AROUND VIEW MONITOR): WORK PROCEDURE»(ref-523997-S40302317082013012500000) ".
CAUTIONPerform the calibration and perform the writing to the around view monitor control unit when removing and replacing each camera, removing the camera mounting parts (front grille, door mirror, etc.) and replacing the around view monitor control unit.

Scheme 45

Scheme 45: Exploded View
Scheme 45: Exploded View
  1. Remove door handle cover upper. Refer to " «EXPLODED VIEW»(ref-524010-S42647225612013012500000) ".
  2. Remove rear camera mounting screws and rear camera harness connector.
  3. Remove rear camera.
  1. Installation is the reverse order of removal.
  2. Perform camera image calibration. Refer to " «CALIBRATING CAMERA IMAGE (AROUND VIEW MONITOR): WORK PROCEDURE»(ref-523997-S40302317082013012500000) ".
CAUTIONPerform the calibration and perform the writing to the around view monitor control unit when removing and replacing each camera, removing the camera mounting parts (front grille, door mirror, etc.) and replacing the around view monitor control unit.

Scheme 46

Scheme 46: Exploded View
Scheme 46: Exploded View

Scheme 47

Scheme 47: REMOVAL
Scheme 47: REMOVAL

Scheme 48

Scheme 48
Scheme 48
  1. Remove glass mirror (driver side). Refer to " «EXPLODED VIEW»(ref-524069-S24707938362013012500000) " (without ADP), " «EXPLODED VIEW»(ref-524061-S17833534172013012500000) " (with ADP).
  2. Remove screws (A), and actuator connector, and then actuator (1).
  3. Remove door mirror cover. Refer to " «EXPLODED VIEW»(ref-524069-S24707938362013012500000) " (without ADP), " «EXPLODED VIEW»(ref-524061-S17833534172013012500000) " (with ADP).
  4. Remove screws (A) and connector (1), and then remove side camera finisher assembly (LH).
  5. Remove side camera (LH) mounting screws
  6. Remove side camera (LH).
  1. Installation is the reverse order of removal.
  2. Perform camera image calibration. Refer to " «CALIBRATING CAMERA IMAGE (AROUND VIEW MONITOR): WORK PROCEDURE»(ref-523997-S40302317082013012500000) ".
CAUTIONPerform the calibration and perform the writing to the around view monitor control unit when removing and replacing each camera, removing the camera mounting parts (front grille, door mirror, etc.) and replacing the around view monitor control unit.

Scheme 49

Scheme 49: Exploded View
Scheme 49: Exploded View

Scheme 50

Scheme 50: REMOVAL
Scheme 50: REMOVAL

Scheme 51

Scheme 51
Scheme 51
  1. Remove glass mirror (passenger side). Refer to " «EXPLODED VIEW»(ref-524069-S24707938362013012500000) " (without ADP), " «EXPLODED VIEW»(ref-524061-S17833534172013012500000) " (with ADP).
  2. Remove screws (A) and actuator connector, and then actuator (1).
  3. Remove door mirror cover. Refer to " «EXPLODED VIEW»(ref-524069-S24707938362013012500000) " (without ADP), " «EXPLODED VIEW»(ref-524061-S17833534172013012500000) " (with ADP).
  4. Remove screws (A) and connector (1), and then remove side camera finisher assembly (RH).
  5. Remove side camera (RH) screws.
  6. Remove side camera (RH).
  1. Installation is the reverse order of removal.
  2. Perform camera image calibration. Refer to " «CALIBRATING CAMERA IMAGE (AROUND VIEW MONITOR): WORK PROCEDURE»(ref-523997-S40302317082013012500000) ".
CAUTIONPerform the calibration and perform the writing to the around view monitor control unit when removing and replacing each camera, removing the camera mounting parts (front grille, door mirror, etc.) and replacing the around view monitor control unit.

Scheme 52

Scheme 52: Exploded View
Scheme 52: Exploded View
  1. Remove AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ".
  2. Remove screws and connector, and then sonar control unit.

Install in the reverse order of removal.

Scheme 53

Scheme 53: FRONT: Exploded View
Scheme 53: FRONT: Exploded View
  1. Remove fender protector. Keep a service area. Refer to " «FENDER PROTECTOR: EXPLODED VIEW»(ref-524010-S39444529382013012500000) ".
  2. Remove sonar sensor connector.
  3. Press the sonar sensor (1) outside the front bumper, pressing the metal clips on the back to the direction of black arrows shown in the figure.

Scheme 54

Scheme 54
Scheme 54

Install the bumper when the pawl engages.

CAUTIONThe connector direction is within ±10° from the horizontal position when assembling the bumper.

A: Horizontal position

a: 10°

Scheme 55

Scheme 55
Scheme 55

REAR

Scheme 56

Scheme 56: REAR: Exploded View
Scheme 56: REAR: Exploded View
  1. Remove sonar sensor connector.
  2. Press the sonar sensor (1) outside the front bumper, pressing the metal clips on the back to the direction of black arrows shown in the figure.

Install the bumper when the pawl engages.

CAUTIONThe connector direction is within ±10° from the horizontal position when assembling the bumper.

A: Horizontal position

a: 10°
