MULTIFUNCTION SWITCH AND PRESET SWITCH SELF-DIAGNOSIS FUNCTION
The ON/OFF operation (continuity) of each switch in the multifunction switch and preset switch can be checked.
Self-diagnosis Mode
- Press the "BACK" switch and the "UP" switch of the 8-direction switches within 10 seconds after turning the ignition switch from OFF to ACC and hold them for 3 seconds or more. Then the buzzer sounds, all indicators of the preset switch illuminate, and the self-diagnosis mode starts.
- The continuity of each switch at the ON position can be checked by pressing the switch. The buzzer sounds if the switch is normal.
Note. The hazard switch and disk eject switch cannot be checked.
Scheme 11
Finishing Self-diagnosis Mode
Self-diagnosis mode is canceled when turning the ignition switch OFF.
MULTI AV SYSTEM ON BOARD DIAGNOSIS FUNCTION
- The AV control unit diagnosis function starts up with multifunction switch operation and the AV control unit performs a diagnosis for each unit in the system during the on board diagnosis.
- Perform a CONSULT diagnosis if the on board diagnosis does not start, e.g., the screen does not display anything, the multifunction switch does not function, etc.
On Board Diagnosis Item
| Mode | Description | ||
|---|---|---|---|
| Self Diagnosis | AV control unit diagnosis. Diagnoses the connections across system components, between AV control unit and GPS antenna. | ||
| Confirmation/Adjustment | Display Diagnosis | The following check functions are available: color tone check by color bar display and white display, light and shade check by gray scale display and touch panel calibration response check. | |
| Vehicle Signals | Diagnosis of signals can be performed for vehicle speed, parking brake, lights, ignition, reverse, side view switch and room lamp. | ||
| Climate Control | Start auto air conditioner system self-diagnosis. | ||
| Navigation | Steering Angle Adjustment | When there is a difference between the actual turning angle and the vehicle mark turning angle, it can be adjusted. | |
| Speed Calibration | When there is a difference between the current location mark and the actual location, it can be adjusted. | ||
| Error History | The system malfunction and the frequency when occurring in the past are displayed. When the malfunctioning item is selected, the time and place that the selected malfunction last occurred are displayed. | ||
| Synchronizer FES Clock | |||
| Speaker Test | The connection of a speaker can be confirmed by test tone. | ||
| Vehicle CAN Diagnosis | The transmitting/receiving of CAN communication can be monitored. | ||
| AV COMM Diagnosis | The communication condition of each unit of Multi AV system can be monitored. | ||
| Hands-free Phone | The received volume adjustment of hands-free phone, microphone speaker check, and erase memory can be performed. | ||
| Camera Cont. | It can perform the confirmation of a signal connection to around view monitor control unit, the calibration of each camera, Correct Draw Line of Camera Image, and Fine Tuning of Birds-Eye View. | ||
| Delete Unit Connection Log | Erase the connection history of unit and error history. | ||
| Initialize Settings | Initializes the AV control unit memory. | ||
| Version Information | Version information of the AV control unit is displayed. | ||
Scheme 12
- Start the engine.
- Turn the audio system OFF.
- While pressing the "SETTING" button, turn the volume control dial clockwise or counterclockwise for 40 clicks or more. (When the self-diagnosis mode is started, a short beep will be heard.) Shifting from current screen to previous screen is performed by pressing "BACK" button.
- The trouble diagnosis initial screen is displayed, and then the items of "Self Diagnosis" and "Confirmation/Adjustment" can be selected.
Scheme 13
- Start the self-diagnosis function and select "Self Diagnosis". Self-diagnosis subdivision screen is displayed, and the self-diagnosis mode starts. The bar graph visible on the center of the self-diagnosis subdivision screen indicates progress of the trouble diagnosis.
- Diagnosis results are displayed after the self-diagnosis is completed. The unit names and the connection lines are color-coded according to the diagnostic results.
| Diagnosis results | Unit | Connection line |
|---|---|---|
| Normal | Green | Green |
| Connection malfunction | Gray | Yellow |
| Unit malfunction Note | Red | Green |
Scheme 14
Note. Control unit (AV control unit) is displayed in red.
- Replace AV control unit if "Self-Diagnosis did not run because of a control unit malfunction" is indicated. The symptom is AV control unit internal error. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ".
- If multiple errors occur at the same time for a single unit, the screen switch colors are determined according to the following order of priority: red > gray. The comments of the self-diagnosis results can be viewed with a component in the diagnosis result screen.
Scheme 15
Detection Range of Self-diagnosis Mode
- The self-diagnosis mode allows the technician to diagnose the connection in the communication line between AV control unit and each unit and the internal operation of the AV control unit.
- Because the start condition of diagnosis function is a switch operation, the on board diagnosis function cannot be started up if any malfunction is detected in the communication circuit between AV control unit and multifunction switch.
SELF-DIAGNOSIS RESULTS
Check the applicable display at the following table, and then repair the malfunctioning parts
Only Unit Part Is Displayed In Red.
| Screen switch | Description | Possible malfunction location/Action to take |
|---|---|---|
| Control Unit | Malfunction is detected in AV control unit power supply and ground circuits. | Check AV control unit power supply and ground circuits. When detecting no malfunction in those components, replace AV control unit. |
A Connecting Cable Between Units Is Displayed In Yellow.
| Area with yellow connection lines | Description | Possible malfunction location/Action to take |
|---|---|---|
| Control unit <=> Front Display | Malfunction is detected in serial communication circuits between AV control unit and front display unit. | Serial communication circuits between AV control unit and front display unit. |
| Control unit <=> GPS Antenna | GPS antenna connection malfunctions detected. | GPS antenna |
| Control unit <=> Around view | When either one of the following items are detected: around view monitor control unit power supply and ground circuits are malfunctioning. AV communication circuits between around view monitor control unit and multifunction switch are malfunctioning. | Around view monitor control unit power supply and ground circuits. AV communication circuits between around view monitor control unit and multifunction switch. |
| Control unit <=> SAT Antenna | Satellite radio antenna connection malfunction is detected. | Satellite radio antenna disconnection |
| Around view <=> Sonar | When either one of the following items are detected: sonar control unit power supply and ground circuits are malfunctioning. AV communication circuits between AV control unit and sonar control unit are malfunctioning. | Sonar control unit power supply and ground circuits. AV communication circuits between AV control unit and sonar control unit. |
Speaker Test
Select "SPEAKER DIAGNOSIS" to display the Speaker Diagnosis screen. Press "Start" to generate a test tone in a speaker. Press "Start" to generate a test tone in the next speaker. Press "Stop" to stop the test tones.
Scheme 16
Vehicle CAN Diagnosis
- CAN communication status and error counter is displayed.
- The error counter displays "OK" if any malfunction was not detected in the past and displays "0" if a malfunction is detected. It increases by 1 if the condition is normal at the next ignition switch ON cycle. The upper limit of the counter is 39.
- The error counter is erased if "Reset" is pressed.
Scheme 17
| Items | Display (Current) | Malfunction counter (Past) |
|---|---|---|
| Tx(HVAC) | OK/??? | OK/0 - 39 |
| Rx(ECM) | OK/??? | OK/0 - 39 |
| Rx(Cluster) | OK/??? | OK/0 - 39 |
| Rx(HVAC) | OK/??? | OK/0 - 39 |
| Rx(USM) | OK/??? | OK/0 - 39 |
| Rx(TPMS) | OK/??? | OK/0 - 39 |
| Rx(STRG) | OK/??? | OK/0 - 39 |
Note. "???" indicates UNKWN.
AV COMM Diagnosis
- Displays the communication status between AV control unit (master unit) and each unit.
- The error counter displays "OK" if any malfunction was not detected in the past and displays "0" if a malfunction is detected. It increases by 1 if the condition is normal at the next ignition switch ON cycle. The upper limit of the counter is 39.
- The error counter is erased if "Reset" is pressed.
Scheme 18
| Items | Status (Current) | Counter (Past) |
|---|---|---|
| C Tx(ITM-PrimarySW) | OK/??? | OK/0 - 39 |
| C Rx(PrimarySW-ITM) | OK/??? | OK/0 - 39 |
| C Rx(AVM-ITM) | OK/??? | OK/0 - 39 |
Note. "???" indicates UNKWN
Hands-Free Phone
The hands-free phone reception volume adjustment and microphone and speaker test functions are also available.
Scheme 19
SELF DIAGNOSIS RESULT
- In CONSULT self-diagnosis, self-diagnosis results and error history are displayed collectively.
- The current malfunction indicates "CRNT". The past malfunction indicates "PAST".
- The timing is displayed as "0" if any of the error codes [U1000], [U1010], [U1300] and [U1310] is detected. The counter increases by 1 if the condition is normal at the next ignition switch ON cycle.
Self-diagnosis Results Display Item
| Error item | Description | Possible malfunction factor/Action to take |
|---|---|---|
| CAN COMM CIRCUIT [U1000] | CAN communication malfunction is detected. | Refer to " DIAGNOSIS PROCEDURE ". |
| CONTROL UNIT (CAN) [U1010] | CAN initial diagnosis malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. |
| CONTROL UNIT (AV) [U1310] | AV communication circuit initial diagnosis malfunction is detected. | |
| Cont Unit [U1200] | AV control unit malfunction is detected. | |
| GYRO NO CONN [U1201] | ||
| G-SENSOR NO CONN [U1202] | ||
| CAN CONT [U1216] | ||
| BLUETOOTH MODULE [U1217] | ||
| SUB CPU CONN [U1228] | ||
| IPod CERTIFICATION [U1229] | ||
| Built-in AUDIO CONN [U122E] | ||
| HDD CONN [U1218] | AV control unit malfunction is detected. | If the music box function has no malfunctions, then there is a possibility of the detection of a temporary malfunction. Replace the AV control unit if the malfunction occurs constantly. |
| HDD READ [U1219] | ||
| HDD WRITE [U121A] | ||
| HDD COMM [U121B] | ||
| HDD ACCESS [U121C] | ||
| GPS COMM [U1204] | GPS malfunction is detected. | An intermittent error caused by strong radio interference may be detected unless any symptom (GPS reception error, etc.) occurs. Replace the AV control unit if the malfunction occurs constantly. |
| GPS ROM [U1205] | ||
| GPS RAM [U1206] | ||
| GPS RTC [U1207] | ||
| USB CONTROLLER [U1225] | USB connection malfunction is detected. | Check that the connection to the USB connector is normal. |
| DSP CONN [U121D] | AV control unit malfunction is detected. | If a disc can be played, then there is a possibility of the detection of a temporary malfunction. Replace the AV control unit if the malfunction occurs constantly. |
| DSP COMM [U121E] | ||
| DVD COMM [U1227] | AV control unit malfunction is detected. | If DVD can be played, then there is a possibility of the detection of a temporary malfunction. Replace the AV control unit if the malfunction occurs constantly. |
| CONFIG UNFINISH [U122A] | The writing of configuration data is incomplete. | Write configuration data with CONSULT. |
| ST ANGLE SEN CALIB [U1232] | Predictive course line center position adjustment of the steering angle sensor is incomplete. | Adjust the predictive course line center position of the steering angle sensor. Refer to " ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION: SPECIAL REPAIR REQUIREMENT ". |
| FRONT DISP CONN [U1243] | When either one of the following items are detected: front display unit power supply and ground circuits malfunction is detected. communication circuits between AV control unit and front display unit. | Front display unit power supply and ground circuits. Communication circuits between AV control unit and AV front display unit. |
| GPS ANTENNA CONN [U1244] | GPS antenna connection malfunction is detected. | Check the connection of the GPS antenna connector. |
| XM ANTENNA CONN [U1258] | Satellite radio antenna connection malfunction is detected. | Satellite radio antenna disconnection. |
| USB OVERCURRENT [U1263] | Detection of overcurrent in USB connected. | Check USB harness between the AV control unit and USB connector. |
| AV COMM CIRCUIT [U1300] SWITCH CONN [U1240] | When either one of the following items are detected: multifunction switch power supply and ground circuits are malfunctioning. AV communication circuits between AV control unit and multifunction switch are malfunctioning. | Multifunction switch power supply and ground circuits. AV communication circuits between AV control unit and multifunction switch. |
| AV COMM CIRCUIT [U1300] AROUND CAMERA CONN [U125B] | When either one of the following items are detected: around view monitor control unit power supply and ground circuits are malfunctioning. AV communication circuits between multifunction switch and around view monitor control unit are malfunctioning. | Around view monitor control unit power supply and ground circuits. AV communication circuits between multifunction switch and around view monitor control unit. |
| AV COMM CIRCUIT [U1300] SONAR CONN [U125C] | When either one of the following items are detected: sonar control unit power supply and ground circuits are malfunctioning. AV communication circuits between AV control unit and sonar control unit are malfunctioning. | Sonar control unit power supply and ground circuits. AV communication circuits between AV control unit and sonar control unit. |
| AV COMM CIRCUIT [U1300] SWITCH CONN [U1240] AROUND CAMERA CONN [U125B] | AV communication circuits between AV control unit and multifunction switch are malfunctioning. | AV communication circuits between AV control unit and multifunction switch. |
On Board Diagnosis Function
The diagnosis function of around view monitor control unit is displayed when selecting "Camera Cont." of Confirmation/Adjustment mode in the multi AV system.
| AV control unit Confirmation/Adjustment mode | Function | ||
|---|---|---|---|
| Camera Cont. | Connection Confirmation | The status of signals input to around view monitor control unit can be checked. | |
| Calibrating Camera Image | Rear Camera | Performs the calibration of rear camera. | |
| Pass-Side Camera | Performs the calibration of side camera RH. | ||
| Front Camera | Performs the calibration of front camera. | ||
| Dr-Side Camera | Performs the calibration of side camera LH. | ||
| Initialize Camera Image Calibration* | The calibration can be initialized to NISSAN factory shipment condition. | ||
| Fine Tuning of Birds-Eye View | The confirmation and adjustment of the difference between each camera can be performed. The system changes to the ZOOM function by the operation of shift and the ZOOM ratio of each camera can be changed. | ||
| Correct Draw Line of Wide View | Rear-Wide View | The position of rear wide view guideline can be changed. | |
AROUND VIEW MONITOR CONTROL UNIT DIAGNOSIS ITEM LIST
| CAUTION | *: Never perform other operations for approximately 10 seconds after performing "Initialize Camera Image Calibration". |
SELF-DIAGNOSTIC RESULTS
For details, refer to " DTC INDEX ".
ACTIVE TEST
| Active test item | Function |
|---|---|
| BUZZER | This test is able to check buzzer operation. |
| SONAR SENSOR | This test is able to check each sonar sensor operation. |
VALUES ON THE DIAGNOSIS TOOL
| Monitor Item | Condition | Value/Status | |
|---|---|---|---|
| VHCL SPD SIG | Ignition switch ON | Vehicle speed > 0 km/h (0 MPH) | On |
| Vehicle speed = 0 km/h (0 MPH) | Off | ||
| PKB SIG | Ignition switch ON | Parking brake is applied. | On |
| Parking brake is released. | Off | ||
| ILLUM SIG | Ignition switch ON | Light switch ON | On |
| Light switch OFF | Off | ||
| IGN SIG | Ignition switch ON | On | |
| Ignition switch ACC | Off | ||
| REV SIG | Ignition switch ON | Selector lever in R position | On |
| Selector lever in any position other than R | Off | ||
| SIDE VIEW SW | Ignition switch ON | This item is displayed, but cannot be monitored. | Off |
| ROOM LAMP (1) | Ignition switch ON | After opening any door; 5 seconds | On |
| Except for above. | Off | ||
| (1) Check 10 seconds later, after closing all doors. | |||
| (1) | Check 10 seconds later, after closing all doors. |
CONSULT MONITOR ITEM LIST
Scheme 20
SELF-DIAGNOSIS RESULTS DISPLAY ITEM
| DTC | Display item | Refer to |
|---|---|---|
| U1000 | CAN COMM CIRCUIT [U1000] | " DIAGNOSIS PROCEDURE " |
| U1010 | CONTROL UNIT (CAN) | [1010] " DTC LOGIC " |
| U1200 | Cont Unit [U1200] | " DTC LOGIC " |
| U1201 | GYRO NO CONN [U1201] | " DTC LOGIC " |
| U1202 | G-SENSOR NO CONN [U1202] | " DTC LOGIC " |
| U1204 | GPS COMM [U1204] | " DIAGNOSIS PROCEDURE " |
| U1205 | GPS ROM [U1205] | " DIAGNOSIS PROCEDURE " |
| U1206 | GPS RAM [U1206] | " DIAGNOSIS PROCEDURE " |
| U1207 | GPS RTC [U1207] | " DIAGNOSIS PROCEDURE " |
| U1216 | CAN CONT [U1216] | " DTC LOGIC " |
| U1217 | BLUETOOTH MODULE [U1217] | " DTC LOGIC " |
| U1218 | HDD CONN [U1218] | " DIAGNOSIS PROCEDURE " |
| U1219 | HDD READ [U1219] | " DIAGNOSIS PROCEDURE " |
| U121A | HDD WRITE [U121A] | " DIAGNOSIS PROCEDURE " |
| U121B | HDD COMM [U121B] | " DIAGNOSIS PROCEDURE " |
| U121C | HDD ACCESS [U121C] | " DIAGNOSIS PROCEDURE " |
| U121D | DSP CONN [U121D] | " DIAGNOSIS PROCEDURE " |
| U121E | DSP COMM [U121E] | " DIAGNOSIS PROCEDURE " |
| U1225 | USB CONTROLLER [U1225] | " DTC LOGIC " |
| U1227 | DVD COMM [U1227] | " DIAGNOSIS PROCEDURE " |
| U1228 | SUB CPU CONN [U1228] | " DTC LOGIC " |
| U1229 | IPod CERTIFICATION [U1229] | " DTC LOGIC " |
| U122A | CONFIG UNFINISH [U122A] | " DIAGNOSIS PROCEDURE " |
| U122E | Built-in AUDIO CONN [U122E] | " DTC LOGIC " |
| U1232 | ST ANGLE SEN CALIB [1232] | " DIAGNOSIS PROCEDURE " |
| U1243 | FRONT DISP CONN [U1243] | " DIAGNOSIS PROCEDURE " |
| U1244 | GPS ANTENNA CONN [U1244] | " DIAGNOSIS PROCEDURE " |
| U1258 | XM ANTENNA CONN [U1258] | " DIAGNOSIS PROCEDURE " |
| U1263 | USB OVERCURRENT [U1263] | " DIAGNOSIS PROCEDURE " |
| U1310 | CONTROL UNIT (AV) [U1310] | " DTC LOGIC " |
| U130 U1240 | AV COMM CIRCUIT [U1300] SWITCH CONN [U1240] | " DESCRIPTION " |
| U1300 U125B | AV COMM CIRCUIT [U1300] AROUND CAMERA CONN [U125B] | " DESCRIPTION " |
| U1300 U125C | AV COMM CIRCUIT [U1300] SONAR CONN [U125C] | " DESCRIPTION " |
| U1300 U1240 U125B | AV COMM CIRCUIT [U1300] SWITCH CONN [U1240] AROUND CAMERA CONN [U125B] | " DESCRIPTION " |
AV CONTROL UNIT DTC INDEX
Scheme 21
| Monitor Item | Condition | Value/Status | |
|---|---|---|---|
| SONAR OPE | Ignition switch ON | Around view monitor operating (sonar operating). | On |
| Around view monitor non-operating (sonar non-operating). | Off | ||
| BUZZER OUTPUT | Ignition switch ON | Buzzer is output condition. | On |
| Buzzer is not output condition. | Off | ||
| CR SEN [FL] | Ignition switch ON | When a sensor is abnormal. | ERROR |
| When a sensor is not detection. | LV.0 | ||
| The distance between the corner sensor and an obstacle is 60 cm (23.6 in) or more and less then 70 cm (27.5 in). | LV.2 | ||
| The distance between the corner sensor and an obstacle is 40 cm (15.7 in) or more and less then 60 cm (23.6 in). | LV.3 | ||
| The distance between corner sensor and an obstacle less than 40 cm (15.7 in). | LV.4 | ||
| CR SEN [FR] | Ignition switch ON | When a sensor is abnormal. | ERROR |
| When a sensor is not detection. | LV.0 | ||
| The distance between the corner sensor and an obstacle is 60 cm (23.6 in) or more and less then 70 cm (27.5 in). | LV.2 | ||
| The distance between the corner sensor and an obstacle is 40 cm (15.7 in) or more and less then 60 cm (23.6 in). | LV.3 | ||
| The distance between corner sensor and an obstacle less than 40 cm (15.7 in). | LV.4 | ||
| CR SEN [RL] | Ignition switch ON | When a sensor is abnormal. | ERROR |
| When a sensor is not detection. | LV.0 | ||
| The distance between the corner sensor and an obstacle is 60 cm (23.6 in) or more and less then 70 cm (27.5 in). | LV.2 | ||
| The distance between the corner sensor and an obstacle is 40 cm (15.7 in) or more and less then 60 cm (23.6 in). | LV.3 | ||
| The distance between corner sensor and an obstacle less than 40 cm (15.7 in). | LV.4 | ||
| CR SEN [RR] | Ignition switch ON | When a sensor is abnormal. | ERROR |
| When a sensor is not detection. | LV.0 | ||
| The distance between the corner sensor and an obstacle is 60 cm (23.6 in) or more and less then 70 cm (27.5 in). | LV.2 | ||
| The distance between the corner sensor and an obstacle is 40 cm (15.7 in) or more and less then 60 cm (23.6 in). | LV.3 | ||
| The distance between corner sensor and an obstacle less than 40 cm (15.7 in). | LV.4 | ||
CONSULT MONITOR ITEM LIST
Scheme 22
DTC Index
| DTC | Display item | Malfunction is detected when... | Reference |
|---|---|---|---|
| B2700 | CORNER SENSOR [FL] [B2700] | Corner sensor (FL) is malfunctioning. | " DTC LOGIC " |
| B2701 | SENSOR HARNESS OPEN [CR-FL] [B2701] | Corner sensor (FL) harness circuit is open. | " DIAGNOSIS PROCEDURE " |
| B2702 | CORNER SENSOR [FR] [B2702] | Corner sensor (FR) is malfunctioning. | " DTC LOGIC " |
| B2703 | SENSOR HARNESS OPEN [CRFR] [B2703] | Corner sensor (FR) harness circuit is open. | " DIAGNOSIS PROCEDURE " |
| B2704 | CORNER SENSOR [RL] [B2704] | Corner sensor (RL) is malfunctioning. | " DTC LOGIC " |
| B2705 | SENSOR HARNESS OPEN [CR-RL] [B2705] | Corner sensor (RL) harness circuit is open. | " DIAGNOSIS PROCEDURE " |
| B2706 | CORNER SENSOR [RR] [B2706] | Corner sensor (RR) is malfunctioning. | " DTC LOGIC " |
| B2707 | SENSOR HARNESS OPEN [CRRR] [B2707] | Corner sensor (RR) harness circuit is open. | " DIAGNOSIS PROCEDURE " |
SONAR CONTROL UNIT (WITH AROUND VIEW MONITOR)
Note. "TIME" means the following
- 0: Means detected malfunction at present. (From malfunction detection to turning ignition switch OFF)
- 1-39: Means detected malfunction in past.
DTC DETECTION LOGIC
| DTC | Display contents of CONSULT | DTC detection condition | Probable malfunction location |
|---|---|---|---|
| U1000 | CAN COMM CIRCUIT [U1000] | AV control unit is not transmitting or receiving CAN communication signal for 2 seconds or more. | CAN communication system. |
Diagnosis Procedure
- PERFORM SELF-DIAGNOSTIC Turn ignition switch ON and wait for 2 seconds or more. Check "Self Diagnostic Result" of "MULTI AV". Is "CAN COMM CIRCUIT" displayed? YES: Refer to "LAN system". Refer to " «TROUBLE DIAGNOSIS FLOW CHART»(ref-523993-S38740783062013012500000) ". NO: Refer to " «INTERMITTENT INCIDENT»(ref-523989-S35030212592013012500000) ".
| DTC | Display contents of CONSULT | DTC detection condition | Probable malfunction factor |
|---|---|---|---|
| U1010 | CONTROL UNIT (CAN) [U1010] | CAN initial diagnosis malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. |
DTC Logic
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1200 | Cont Unit [U1200] | AV control unit malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. |
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1201 | GYRO NO CONN [U1201] | AV control unit malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. |
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1202 | G-SENSOR NO CONN [U1202] | AV control unit malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. |
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1204 | GPS CONN [U1204] | GPS malfunction is detected. | An intermittent error caused by strong radio interference may be detected unless any symptom (GPS reception error, etc.) occurs. Replace the AV control unit if the malfunction occurs constantly. |
- PERFORM THE SELF-DIAGNOSIS Delete the self-diagnosis results. Turn ignition switch OFF. Turn ignition switch ON. Perform the self-diagnosis again. Check that the DTC is detected again. Is any DTC detected? YES: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ". NO: An intermittent error caused by strong radio interference may be detected unless any symptom (GPS reception error, etc.) occurs.
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1205 | GPS ROM [U1205] | GPS malfunction is detected. | An intermittent error caused by strong radio interference may be detected unless any symptom (GPS reception error, etc.) occurs. Replace the AV control unit if the malfunction occurs constantly. |
- PERFORM THE SELF-DIAGNOSIS Delete the self-diagnosis results. Turn ignition switch OFF. Turn ignition switch ON. Perform the self-diagnosis again. Check that the DTC is detected again. Is any DTC detected? YES: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ". NO: An intermittent error caused by strong radio interference may be detected unless any symptom (GPS reception error, etc.) occurs.
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1206 | GPS RAM [U1206] | GPS malfunction is detected. | An intermittent error caused by strong radio interference may be detected unless any symptom (GPS reception error, etc.) occurs. Replace the AV control unit if the malfunction occurs constantly. |
- PERFORM THE SELF-DIAGNOSIS Delete the self-diagnosis results. Turn ignition switch OFF. Turn ignition switch ON. Perform the self-diagnosis again. Check that the DTC is detected again. Is any DTC detected? YES: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ". NO: An intermittent error caused by strong radio interference may be detected unless any symptom (GPS reception error, etc.) occurs.
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1207 | GPS RTC [U1207] | GPS malfunction is detected. | An intermittent error caused by strong radio interference may be detected unless any symptom (GPS reception error, etc.) occurs. Replace the AV control unit if the malfunction occurs constantly. |
- PERFORM THE SELF-DIAGNOSIS Delete the self-diagnosis results. Turn ignition switch OFF. Turn ignition switch ON. Perform the self-diagnosis again. Check that the DTC is detected again. Is any DTC detected? YES: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ". NO: An intermittent error caused by strong radio interference may be detected unless any symptom (GPS reception error, etc.) occurs.
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1216 | CAN CONT [U1216] | AV control unit malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. |
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1217 | BLUETOOTH MODULE [U1217] | AV control unit malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. |
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1218 | HDD CONN [U1218] | AV control unit malfunction is detected. | If the music box function has no malfunctions, then there is a possibility of the detection of a temporary malfunction. Replace the AV control unit if the malfunction occurs constantly. |
- CHECK MUSIC BOX FUNCTION Is music box function normal? YES: Malfunction may be detected transitory. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ".
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1219 | HDD READ [U1219] | AV control unit malfunction is detected. | If the music box function has no malfunctions, then there is a possibility of the detection of a temporary malfunction. Replace the AV control unit if the malfunction occurs constantly. |
- CHECK MUSIC BOX FUNCTION Is music box function normal? YES: Malfunction may be detected transitory. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ".
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U121A | HDD WRITE [U121A] | AV control unit malfunction is detected. | If the music box function has no malfunctions, then there is a possibility of the detection of a temporary malfunction. Replace the AV control unit if the malfunction occurs constantly. |
- CHECK MUSIC BOX FUNCTION Is music box function normal? YES: Malfunction may be detected transitory. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ".
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U121B | HDD COMM [U121B] | AV control unit malfunction is detected. | If the music box function has no malfunctions, then there is a possibility of the detection of a temporary malfunction. Replace the AV control unit if the malfunction occurs constantly. |
- CHECK MUSIC BOX FUNCTION Is music box function normal? YES: Malfunction may be detected transitory. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ".
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U121C | HDD ACCESS [U121C] | AV control unit malfunction is detected. | If the music box function has no malfunctions, then there is a possibility of the detection of a temporary malfunction. Replace the AV control unit if the malfunction occurs constantly. |
- CHECK MUSIC BOX FUNCTION Is music box function normal? YES: Malfunction may be detected transitory. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ".
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U121D | DSP CONN [U121D] | AV control unit malfunction is detected. | If a disc can be played, then there is a possibility of the detection of a temporary malfunction. Replace the AV control unit if the malfunction occurs constantly. |
- CHECK PLAYBACK OF A DISK (CD) Can a disk (CD) be played? YES: Malfunction may be detected transitory. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ".
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U121E | DSP COMM [U121E] | AV control unit malfunction is detected. | If a disc can be played, then there is a possibility of the detection of a temporary malfunction. Replace the AV control unit if the malfunction occurs constantly. |
- CHECK PLAYBACK OF A DISK (CD) Can a disk (CD) be played? YES: Malfunction may be detected transitory. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ".
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1225 | USB CONTROLLER [U1225] | USB connection malfunction is detected. | Check that the connection to the USB connector is normal. |
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1227 | DVD COMM [U1227] | AV control unit malfunction is detected. | If DVD can be played, then there is a possibility of the detection of a temporary malfunction. Replace the AV control unit if the malfunction occurs constantly. |
- CHECK PLAYBACK OF A DISK (DVD) Can a disc (DVD) be played? YES: Malfunction may be detected transitory. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ".
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1228 | SUB CPU CONN [U1228] | AV control unit malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. |
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1229 | IPod CERTIFICATION [U1229] | AV control unit malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. |
| DTC | Display contents of CONSULT | DTC detection condition | Action to take |
|---|---|---|---|
| U122A | CONFIG UNFINISH [U122A] | The writing of configuration data is incomplete. | Write configuration data with CONSULT. |
- PERFORM THE SELF-DIAGNOSIS When U122A is detected, write configuration data with CONSULT. : Write configuration data with CONSULT. Refer to " «CONFIGURATION (AV CONTROL UNIT): WORK PROCEDURE»(ref-523997-S23317664852013012500000) ".
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U122E | Built-in AUDIO CONN [U122E] | AV control unit malfunction is detected. | Replace the AV control unit if the malfunction occurs constantly. |
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1232 | ST ANGLE SEN CALIB [1232] | Predictive course line center position adjustment of the steering angle sensor is incomplete. | Adjust the predictive course line center position of the steering angle sensor. |
- ADJUST THE PREDICTIVE COURSE LINE CENTER POSITION OF THE STEERING ANGLE SENSOR When U1232 is detected, adjust the predictive course line center position of the steering angle sensor. : Adjusts the steering angle sensor neutral position on ABS actuator and electrical unit (control unit) side. Refer to " «ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION: SPECIAL REPAIR REQUIREMENT»(ref-524026-S18933176772013012500000) ".
| DTC | Display contents of CONSULT | DTC Detection Condition | Possible causes |
|---|---|---|---|
| U1243 | FRONT DISP CONN [U1243] | When either one of the following items is detected: front display unit power supply and ground circuit malfunction is detected. malfunction is detected in communication circuits between front display unit and AV control unit. | Front display unit power supply and ground circuit. Communication circuits between front display unit and AV control unit. |
- CHECK FRONT DISPLAY UNIT POWER SUPPLY AND GROUND CIRCUITS Check front display unit power supply and ground circuits. Refer to " «FRONT DISPLAY UNIT: DIAGNOSIS PROCEDURE»(ref-523997-S16341312272013012500000) ". Is inspection result normal? YES: GO TO 2. NO: Repair malfunctioning parts.
- CHECK CONTINUITY COMMUNICATION CIRCUITS Turn ignition switch OFF. Disconnect front display unit connector and AV control unit connector. Check continuity between front display unit harness connector and AV control unit harness connector. Front display unit AV control unit Continuity Connector Terminals Connector Terminals M195 9 M210 89 Existed 10 73 Check continuity between front display unit harness connector and ground. Front display unit Ground Continuity Connector Terminals M195 9 Not existed 10 Is inspection result normal? YES: GO TO 3. NO: Repair harness or connector.
- CHECK COMMUNICATION SIGNAL Connect front display unit connector and AV control unit connector. Turn ignition switch ON. Check signal between front display unit harness connector and ground. (+) (-) Condition Reference value Front display unit Connector Terminal M195 9 Ground When adjusting display brightness. Is inspection result normal? YES: GO TO 4. NO: Replace AV control unit.
- CHECK COMMUNICATION SIGNAL Check signal between front display unit harness connector and ground. (+) (-) Condition Reference value Front display unit Connector Terminal M195 10 Ground When adjusting display brightness. Is inspection result normal? YES: INSPECTION END NO: Replace front display unit.
| DTC | Display contents of CONSULT | DTC Detection Condition | Possible causes |
|---|---|---|---|
| U1244 | GPS ANTENNA CONN [U1244] | GPS antenna connection malfunction is detected. | GPS antenna disconnection |
- GPS ANTENNA CHECK Visually check GPS antenna and antenna feeder. Is inspection result normal? YES: GO TO 2. NO: Repair malfunctioning parts.
- CHECK AV CONTROL UNIT VOLTAGE Disconnect GPS antenna connector. Turn ignition switch ON. Check voltage between AV control unit terminal and ground. (+) (-) voltage (Approx.) AV control unit Terminal 153 Ground 5.0 V Is inspection result normal? YES: INSPECTION END NO: Replace AV control unit.
| DTC | Display contents of CONSULT | DTC Detection Condition | Possible causes |
|---|---|---|---|
| U1258 | XM ANTENNA CONN [U1258] | Satellite radio antenna connection malfunction is detected. | Satellite radio antenna disconnection |
- SATELLITE RADIO ANTENNA CHECK Visually check satellite radio antenna and antenna feeder. Is inspection result normal? YES: GO TO 2. NO: Repair malfunctioning parts.
- CHECK AV CONTROL UNIT VOLTAGE Disconnect satellite radio antenna connector. Turn ignition switch ON. Check voltage between AV control unit terminal and ground. (+) (-) Voltage (Approx.) AV control unit Terminal 159 Ground 4.0 V Is inspection result normal? YES: INSPECTION END NO: Replace AV control unit.
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1263 | USB OVERCURRENT [U1263] | Detection of overcurrent in USB connector. | Check USB harness between the AV control unit and USB connector. |
- CHECK USB HARNESS Visually check USB harness. Is the inspection result normal? YES: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ". NO: Replace USB harness.
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1300 U1240 | AV COMM CIRCUIT [U1300] SWITCH CONN [U1240] | When either one of the following items are detected: multifunction switch power supply and ground circuits are malfunctioning. AV communication circuits between AV control unit and multifunction switch are malfunctioning. | Multifunction switch power supply and ground circuits. AV communication circuits between AV control unit and multifunction switch. |
| U1300 U125B | AV COMM CIRCUIT [U1300] AROUND CAMERA CONN [U125B] | When either one of the following items are detected: around view monitor control unit power supply and ground circuits are malfunctioning. AV communication circuits between AV control unit and around view monitor control unit are malfunctioning. | Around view monitor control unit power supply and ground circuits. AV communication circuits between AV control unit and around view monitor control unit. |
| U1300 U125C | AV COMM CIRCUIT [U1300] SONAR CONN [U125C] | When either one of the following items are detected: sonar control unit power supply and ground circuits are malfunctioning. AV communication circuits between AV control unit and sonar control unit are malfunctioning. | Sonar control unit power supply and ground circuits. AV communication circuits between AV control unit and sonar control unit. |
| U1300 U1240 U125B | AV COMM CIRCUIT [U1300] SWITCH CONN [U1240] AROUND CAMERA CONN [U125B] | AV communication circuits between AV control unit and multifunction switch are malfunctioning. | AV communication circuits between AV control unit and multifunction switch. |
| DTC | Display contents of CONSULT | DTC detection condition | Possible malfunction factor |
|---|---|---|---|
| U1310 | CONTROL UNIT (AV) [U1310] | An initial diagnosis error is detected in AV communication circuit. | Replace the AV control unit if the malfunction occurs constantly. |
| DTC No. | CONSULT indication | DTC detection condition | Troubleshooting |
|---|---|---|---|
| B2700 | CORNER SENSOR [FL] [B2700] | Corner sensor (FL) is malfunctioning. | Replace corner sensor (FL). |
| DTC No. | CONSULT indication | DTC detection condition | Troubleshooting |
|---|---|---|---|
| B2701 | SENSOR HARNESS OPEN [CR-FL] [B2701] | Corner sensor (FL) harness circuit is open. | Check corner sensor (FL) circuit. |
- CHECK HARNESS CORNER SENSOR (FL) SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect sonar control unit connector and corner sensor (FL) connector. Check continuity between sonar control unit harness connector and corner sensor (FL) harness connector. Sonar control unit Corner sensor (FL) Continuity Connector Terminal Connector Terminal M47 3 E154 1 Existed Check continuity between sonar control unit harness connector and ground. Sonar control unit Ground Continuity Connector Terminal M47 3 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK HARNESS CORNER SENSOR (FL) GROUND CIRCUIT Check continuity between sonar control unit harness connector and corner sensor (FL) harness connector. Sonar control unit Corner sensor (FL) Continuity Connector Terminal Connector Terminal M47 12 E154 2 Existed Is the inspection result normal? YES: INSPECTION END NO: Repair harness or connector.
| DTC No. | CONSULT indication | DTC detection condition | Troubleshooting |
|---|---|---|---|
| B2702 | CORNER SENSOR [FR] [B2702] | Corner sensor (FR) is malfunctioning. | Replace corner sensor (FR). |
| DTC No. | CONSULT indication | DTC detection condition | Troubleshooting |
|---|---|---|---|
| B2703 | SENSOR HARNESS OPEN [CR-FR] [B2703] | Corner sensor (FR) harness circuit is open. | Check corner sensor (FR) circuit. |
- CHECK HARNESS CORNER SENSOR (FR) SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect sonar control unit connector and corner sensor (FR) connector. Check continuity between sonar control unit harness connector and corner sensor (FR) harness connector. Sonar control unit Corner sensor (FR) Continuity Connector Terminal Connector Terminal M47 4 E152 1 Existed Check continuity between sonar control unit harness connector and ground. Sonar control unit Ground Continuity Connector Terminal M47 4 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK HARNESS CORNER SENSOR (FR) GROUND CIRCUIT Check continuity between sonar control unit harness connector and corner sensor (FR) harness connector. Sonar control unit Corner sensor (FR) Continuity Connector Terminal Connector Terminal M47 12 E152 2 Existed Is the inspection result normal? YES: INSPECTION END NO: Repair harness or connector.
| DTC No. | CONSULT indication | DTC detection condition | Troubleshooting |
|---|---|---|---|
| B2704 | CORNER SENSOR [RL] [B2704] | Corner sensor (RL) is malfunctioning. | Replace corner sensor (RL). |
| DTC No. | CONSULT indication | DTC detection condition | Troubleshooting |
|---|---|---|---|
| B2705 | SENSOR HARNESS OPEN [CR-RL] [B2705] | Corner sensor (RL) harness circuit is open. | Check corner sensor (RL) circuit. |
- CHECK HARNESS CORNER SENSOR (RL) SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect sonar control unit connector and corner sensor (RL) connector. Check continuity between sonar control unit harness connector and corner sensor (RL) harness connector. Sonar control unit Corner sensor (RL) Continuity Connector Terminal Connector Terminal M47 5 B259 1 Existed Check continuity between sonar control unit harness connector and ground. Sonar control unit Ground Continuity Connector Terminal M47 5 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK HARNESS CORNER SENSOR (RL) GROUND CIRCUIT Check continuity between sonar control unit harness connector and corner sensor (RL) harness connector. Sonar control unit Corner sensor (RL) Continuity Connector Terminal Connector Terminal M47 12 B259 2 Existed Is the inspection result normal? YES: INSPECTION END NO: Repair harness or connector.
| DTC No. | CONSULT indication | DTC detection condition | Troubleshooting |
|---|---|---|---|
| B2706 | CORNER SENSOR [RR] [B2706] | Corner sensor (RR) is malfunctioning. | Replace corner sensor (RR). |
| DTC No. | CONSULT indication | DTC detection condition | Troubleshooting |
|---|---|---|---|
| B2707 | SENSOR HARNESS OPEN [CR-RR] [B2707] | Corner sensor (RR) harness circuit is open. | Check corner sensor (RR) circuit. |
- CHECK HARNESS CORNER SENSOR (RR) SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect sonar control unit connector and corner sensor (RR) connector. Check continuity between sonar control unit harness connector and corner sensor (RR) harness connector. Sonar control unit Corner sensor (RR) Continuity Connector Terminal Connector Terminal M47 6 B256 1 Existed Check continuity between sonar control unit harness connector and ground. Sonar control unit Ground Continuity Connector Terminal M47 6 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK HARNESS CORNER SENSOR (RR) GROUND CIRCUIT Check continuity between sonar control unit harness connector and corner sensor (RR) harness connector. Sonar control unit Corner sensor (RR) Continuity Connector Terminal Connector Terminal M47 12 B256 2 Existed Is the inspection result normal? YES: INSPECTION END NO: Repair harness or connector.
AV CONTROL UNIT: Diagnosis Procedure
- CHECK FUSE Check for blown fuses. Power source Fuse No. Battery 34 Is the inspection result normal? YES: GO TO 2. NO: Be sure to eliminate cause of malfunction before installing new fuse.
- CHECK POWER SUPPLY CIRCUIT Check voltage between AV control unit harness connectors and ground. Signal name Connector No. Terminal No. Ignition switch position Value (Approx.) Battery power supply M208 19 OFF Battery voltage ACC power supply M208 7 ACC Battery voltage Is the inspection result normal? YES: GO TO 3. NO: Repair harness or connector.
- CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect AV control unit connectors. Check continuity between AV control unit harness connectors and ground. Signal name Connector No. Terminal No. Ignition switch position Continuity Ground M208 20 OFF Existed Is the inspection result normal? YES: INSPECTION END NO: Repair harness or connector.
FRONT DISPLAY UNIT: Diagnosis Procedure
- CHECK FUSE Check for blown fuses. Power source Fuse No. Battery 34 Is the inspection result normal? YES: GO TO 2. NO: Be sure to eliminate cause of malfunction before installing new fuse.
- CHECK POWER SUPPLY CIRCUIT Check voltage between display unit harness connector and ground. Signal name Connector No. Terminal No. Ignition switch position Value (Approx.) Battery power supply M195 11 OFF Battery voltage ACC power supply M195 23 ACC Battery voltage Is the inspection result normal? YES: GO TO 3. NO: Repair harness or connector.
- CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect display unit connector. Check continuity between display unit harness connector and ground. Signal name Connector No. Terminal No. Ignition switch position Continuity Ground M195 12 OFF Existed Is the inspection result normal? YES: INSPECTION END NO: Repair harness or connector.
BOSE AMP.: Diagnosis Procedure
- CHECK FUSE Check for blown fuses. Power source Fuse No. Battery 8 Is the inspection result normal? YES: GO TO 2. NO: Be sure to eliminate cause of malfunction before installing new fuse.
- CHECK POWER SUPPLY CIRCUIT Check voltage between BOSE amp. harness connector and ground. Signal name Connector No. Terminal No. Ignition switch position Value (Approx.) Battery power supply B42 11 OFF Battery voltage Is the inspection result normal? YES: GO TO 3. NO: Check harness between BOSE amp. and fuse.
- CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect BOSE amp. connector. Check continuity between BOSE amp. harness connector and ground. Signal name Connector No. Terminal No. Ignition switch position Continuity Ground B42 12 OFF Existed Is the inspection result normal? YES: INSPECTION END NO: Repair harness or connector.
AROUND VIEW MONITOR CONTROL UNIT: Diagnosis Procedure
- CHECK FUSE Check for blown fuses. Power source Fuse No. Battery 34 Ignition switch ACC 19 Is inspection result normal? YES: GO TO 2. NO: Be sure to eliminate cause of malfunction before installing new fuse.
- CHECK POWER SUPPLY CIRCUITS Check voltage between around view monitor control unit harness connector and ground. Signal name Connector No. Terminal No. Ignition switch position Value (Approx.) Battery power supply B46 2 OFF Battery voltage ACC power supply B46 4 ACC Battery voltage Is inspection result normal? YES: GO TO 3. NO: Check harness between around view monitor control unit and fuse.
- CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect around view monitor control unit connector. Check continuity between around view monitor control unit harness connector and ground. Signal name Connector No. Terminal No. Ignition switch position Continuity Ground B46 1 OFF Existed Is inspection result normal? YES: INSPECTION END NO: Repair harness or connector.
SONAR CONTROL UNIT (WITH AROUND VIEW MONITOR): Diagnosis Procedure
- CHECK FUSE Check for blown fuses. Power source Fuse No. Ignition switch ACC or ON 19 Is the inspection result normal? YES: GO TO 2. NO: Be sure to eliminate cause of malfunction before installing new fuse.
- CHECK POWER SUPPLY CIRCUIT Turn ignition switch ON. Check voltage between sonar control unit harness connector and ground. Signal name Connector No. Terminal No. Ignition switch position Value (Approx.) Battery power supply M47 13 ACC Battery voltage Is the inspection result normal? YES: GO TO 3. NO: Repair or replace sonar control unit power supply harness.
- CHECK GROUND CIRCUIT Turn ignition switch OFF. Disconnect sonar control unit connector. Check continuity between sonar control unit harness connector and ground. Signal name Connector No. Terminal No. Ignition switch position Continuity Ground M47 24 OFF Existed Is the inspection result normal? YES: INSPECTION END NO: Repair or replace sonar control unit ground harness.
- CHECK CONTINUITY RGB DIGITAL IMAGE SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect display unit connector and AV control unit connector. Check continuity between front display unit harness connector and AV control unit harness connector. Front display unit AV control unit Continuity Connector Terminals Connector Terminals M397 27 M396 157 Existed 28 158 Check continuity between front display unit harness connector and ground. Front display unit Ground Continuity Connector Terminals M397 27 Not existed 28 Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK RGB DIGITAL IMAGE SIGNAL Connect AV control unit connector. Turn ignition switch ON. Check signal between front display unit harness connector and ground. (+) (-) Condition Voltage (Approx.) Front display unit Connector Terminal M397 27 Ground - 3.0 V 28 Is the inspection result normal? YES: Replace front display unit. Refer to " «EXPLODED VIEW»(ref-523997-S07380420072013012500000) ". NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ".
- CHECK CONTINUITY COMPOSITE IMAGE SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect AV control unit connector and front display unit connector. Check continuity between AV control unit harness connector and front display unit harness connector. AV control unit Front display unit Continuity Connector Terminal Connector Terminal M210 68 M195 18 Existed Check continuity between AV control unit harness connector and ground. AV control unit Ground Continuity Connector Terminal M210 68 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK COMPOSITE SIGNAL Connect AV control unit connector and front display unit connector. Turn ignition switch ON. Check signal between AV control unit harness connector and ground. (+) (-) Condition Reference value AV control unit Connector Terminal M210 68 Ground At DVD image is displayed. Is the inspection result normal? YES: Replace front display unit. Refer to " «EXPLODED VIEW»(ref-523997-S07380420072013012500000) ". NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ".
- CHECK CONTINUITY DISK EJECT SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect multifunction switch connector and AV control unit connector. Check continuity between multifunction switch harness connector and AV control unit harness connector. Multifunction switch AV control unit Continuity Connector Terminal Connector Terminal M72 14 M209 29 Existed Check continuity between multifunction switch harness connector and ground. Multifunction switch Ground Continuity Connector Terminal M72 14 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK AV CONTROL UNIT VOLTAGE Connect multifunction switch connector and AV control unit connector. Turn ignition switch ON. Check voltage between AV control unit harness connector and ground. (+) (-) Condition Voltage (Approx.) AV control unit Connector Terminal M209 29 Ground Pressing the eject switch 0 V Except for above 5.0 V Is the inspection result normal? YES: Replace preset switch. Refer to " «EXPLODED VIEW»(ref-523997-S24310413232013012500000) ". NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ".
- CHECK CONTINUITY MODE CHANGE SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect BOSE amp. connector and AV control unit connector. Check continuity between BOSE amp. harness connector and AV control unit harness connector. BOSE amp. AV control unit Continuity Connector Terminal Connector Terminal B41 17 M209 30 Existed Check continuity between BOSE amp. harness connector and ground. BOSE amp. Ground Continuity Connector Terminal B41 17 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK MODE CHANGE SIGNAL Connect BOSE amp. connector. Turn ignition switch ON. Check signal between BOSE amp. harness connector and ground. (+) (-) Condition Voltage (Approx.) BOSE amp. Connector Terminal B41 17 Ground Driver's Audio Stage ON 0 V Driver's Audio Stage OFF 8.5 V Is the inspection result normal? YES: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ". NO: Replace BOSE amp. Refer to " «EXPLODED VIEW»(ref-523997-S39783477532013012500000) ".
- CHECK CONTINUITY BETWEEN AV CONTROL UNIT AND MICROPHONE CIRCUIT Turn ignition switch OFF. Disconnect AV control unit connector and microphone connector. Check continuity between AV control unit harness connector and microphone harness connector. AV control unit Microphone Continuity Connector Terminals Connector Terminals M210 71 R17 2 Existed 72 4 87 1 Check continuity between AV control unit harness connector and ground. AV control unit Ground Continuity Connector Terminals M210 72 Not existed 87 Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK VOLTAGE MICROPHONE VCC Connect AV control unit connector. Turn ignition switch ON. Check voltage between AV control unit harness connector. (+) (-) Voltage (Approx.) AV control unit Ground Connector Terminal M210 72 5.0 V Is the inspection result normal? YES: GO TO 3. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ".
- CHECK MICROPHONE SIGNAL Connect microphone connector. Check signal between AV control unit harness connector. (+) (-) Condition Reference value AV control unit AV control unit Connector Terminal Connector Terminal M210 87 M210 71 Give a voice. Is the inspection result normal? YES: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ". NO: Replace microphone. Refer to " «EXPLODED VIEW»(ref-523997-S04930970492013012500000) ".
- CHECK CONTINUITY CAMERA IMAGE SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect front display unit connector and around view monitor control unit connector. Check continuity between front display unit harness connector and around view monitor control unit harness connector. Front display unit Around view monitor control unit Continuity Connector Terminal Connector Terminal M195 8 B46 27 Existed Check continuity between front display unit harness connector and ground. Front display unit Ground Continuity Connector Terminal M195 8 Not existed Is inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK CAMERA IMAGE SIGNAL Connect front display unit connector and around view monitor control unit connector. Turn ignition switch ON. Check signal between front display unit harness connector and ground. (+) (-) Condition Reference value Front display unit Connector Terminal M195 8 Ground At camera image is displayed. Is inspection result normal? YES: Replace front display unit. Refer to " «EXPLODED VIEW»(ref-523997-S07380420072013012500000) ". NO: Replace around view monitor control unit. Refer to " «EXPLODED VIEW»(ref-523997-S13080796432013012500000) ".
- CHECK CONTINUITY COMMUNICATION SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect around view monitor control unit connector and front camera connector. Check continuity between around view monitor control unit harness connector and front camera harness connector. Around view monitor control unit Front camera Continuity Connector Terminal Connector Terminal B45 45 E155 6 Existed Check continuity between around view monitor control unit harness connector and ground. Around view monitor control unit Ground Continuity Connector Terminal B45 45 Not existed Is inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK COMMUNICATION SIGNAL Connect around view monitor control unit connector and front camera connector. Turn ignition switch ON. Check signal between around view monitor control unit harness connector and ground. (+) (-) Condition Reference value Around view monitor control unit Connector Terminal B45 45 Ground "CAMERA" switch is ON or shift position is "R". Is inspection result normal? YES: Replace around view monitor control unit. Refer to " «EXPLODED VIEW»(ref-523997-S13080796432013012500000) ". NO: Replace front camera. Refer to " «EXPLODED VIEW»(ref-523997-S16541900172013012500000) ".
- CHECK CONTINUITY FRONT CAMERA POWER SUPPLY AND GROUND CIRCUIT Turn ignition switch OFF. Disconnect around view monitor control unit connector and front camera connector. Check continuity between around view monitor control unit harness connector and front camera harness connector. Around view monitor control unit Front camera Continuity Connector Terminals Connector Terminals B45 44 E155 2 Existed 46 1 Check continuity between around view monitor control unit harness connector and ground. Around view monitor control unit Ground Continuity Connector Terminal B45 46 Not existed Is inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK VOLTAGE FRONT CAMERA POWER SUPPLY Connect around view monitor control unit connector and front camera connector. Turn ignition switch ON. Check voltage between around view monitor control unit harness connector. (+) (-) Condition Voltage (Approx.) Around view monitor control unit Connector Terminal B45 46 Ground "CAMERA" switch is ON or shift position is "R". 6.0 V Is inspection result normal? YES: GO TO 3. NO: Replace around view monitor control unit. Refer to " «EXPLODED VIEW»(ref-523997-S13080796432013012500000) ".
- CHECK CONTINUITY FRONT CAMERA IMAGE SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect around view monitor control unit connector and front camera connector. Check continuity between around view monitor control unit harness connector and front camera harness connector. Around view monitor control unit Front camera Continuity Connector Terminals Connector Terminals B45 41 E155 3 Existed 42 4 Check continuity between around view monitor control unit harness connector and ground. Around view monitor control unit Ground Continuity Connector Terminals B45 41, 42 Not existed Is inspection result normal? YES: GO TO 4. NO: Repair harness or connector.
- CHECK FRONT CAMERA IMAGE SIGNAL Connect around view monitor control unit connector and front camera connector. Turn ignition switch ON. Check signal between around view monitor control unit harness connector. (+) (-) Condition Reference value Around view monitor control unit Around view monitor control unit Connector Terminal Connector Terminal B45 41 B45 42 "CAMERA" switch is ON or shift position is "R". Is inspection result normal? YES: Replace around view monitor control unit. Refer to " «EXPLODED VIEW»(ref-523997-S13080796432013012500000) ". NO: Replace front camera. Refer to " «EXPLODED VIEW»(ref-523997-S16541900172013012500000) ".
- CHECK CONTINUITY COMMUNICATION SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect around view monitor control unit connector and rear camera connector. Check continuity between around view monitor control unit harness connector and rear camera harness connector. Around view monitor control unit Rear camera Continuity Connector Terminal Connector Terminal B46 35 D111 4 Existed Check continuity between around view monitor control unit harness connector and ground. Around view monitor control unit Ground Continuity Connector Terminal B46 35 Not existed Is inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK COMMUNICATION SIGNAL Connect around view monitor control unit connector and rear camera connector. Turn ignition switch ON. Check signal between around view monitor control unit harness connector and ground. (+) (-) Condition Reference value Around view monitor control unit Connector Terminal B46 35 Ground "CAMERA" switch is ON or shift position is "R". Is inspection result normal? YES: Replace around view monitor control unit. Refer to " «EXPLODED VIEW»(ref-523997-S13080796432013012500000) ". NO: Replace rear camera. Refer to " «EXPLODED VIEW»(ref-523997-S09247880232013012500000) ".
- CHECK CONTINUITY REAR CAMERA POWER SUPPLY AND GROUND CIRCUIT Turn ignition switch OFF. Disconnect around view monitor control unit connector and rear camera connector. Check continuity between around view monitor control unit harness connector and rear camera harness connector. Around view monitor control unit Rear camera Continuity Connector Terminals Connector Terminals B46 36 D111 8 Existed 38 7 Check continuity between around view monitor control unit harness connector and ground. Around view monitor control unit Ground Continuity Connector Terminal B46 36 Not existed Is inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK VOLTAGE REAR CAMERA POWER SUPPLY Connect around view monitor control unit connector and rear camera connector. Turn ignition switch ON. Check voltage between around view monitor control unit harness connector and ground. (+) (-) Condition Voltage (Approx.) Around view monitor control unit Connector Terminal B46 36 Ground "CAMERA" switch is ON or shift position is "R". 6.0 V Is inspection result normal? YES: GO TO 3. NO: Replace around view monitor control unit. Refer to " «EXPLODED VIEW»(ref-523997-S13080796432013012500000) ".
- CHECK CONTINUITY REAR CAMERA IMAGE SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect around view monitor control unit connector and rear camera connector. Check continuity between around view monitor control unit harness connector and rear camera harness connector. Around view monitor control unit Rear camera Continuity Connector Terminals Connector Terminals B46 39 D111 5 Existed 40 1 Check continuity between around view monitor control unit harness connector and ground. Around view monitor control unit Ground Continuity Connector Terminals B46 39, 40 Not existed Is inspection result normal? YES: GO TO 4. NO: Repair harness or connector.
- CHECK REAR CAMERA IMAGE SIGNAL Connect around view monitor control unit connector and rear camera connector. Turn ignition switch ON. Check signal between around view monitor control unit harness connector. (+) (-) Condition Reference value Around view monitor control unit Around view monitor control unit Connector Terminal Connector Terminal B46 39 B46 40 "CAMERA" switch is ON or shift position is "R". Is inspection result normal? YES: Replace around view monitor control unit. Refer to " «EXPLODED VIEW»(ref-523997-S13080796432013012500000) ". NO: Replace rear camera. Refer to " «EXPLODED VIEW»(ref-523997-S09247880232013012500000) ".
- CHECK CONTINUITY COMMUNICATION SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect around view monitor control unit connector and door mirror (driver side) connector. Check continuity between around view monitor control unit harness connector and door mirror (driver side) harness connector. Around view monitor control unit Door mirror (driver side) Continuity Connector Terminal Connector Terminal B45 47 D3 3 Existed Check continuity between around view monitor control unit harness connector and ground. Around view monitor control unit Ground Continuity Connector Terminal B45 47 Not existed Is inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK COMMUNICATION SIGNAL Connect around view monitor control unit connector and door mirror (driver side) connector. Turn ignition switch ON. Check signal between around view monitor control unit harness connector and ground. (+) (-) Condition Reference value Around view monitor control unit Connector Terminal B45 47 Ground "CAMERA" switch is ON or shift position is "R". Is inspection result normal? YES: Replace around view monitor control unit. Refer to " «EXPLODED VIEW»(ref-523997-S13080796432013012500000) ". NO: Replace side camera LH. Refer to " «EXPLODED VIEW»(ref-523997-S38663039642013012500000) ".
- CHECK CONTINUITY SIDE CAMERA LH POWER SUPPLY AND GROUND CIRCUIT Turn ignition switch OFF. Disconnect around view monitor control unit connector and door mirror (driver side) connector. Check continuity between around view monitor control unit harness connector and door mirror (driver side) harness connector. Around view monitor control unit Door mirror (driver side) Continuity Connector Terminals Connector Terminals B45 48 D3 6 Existed 50 18 Check continuity between around view monitor control unit harness connector and ground. Around view monitor control unit Ground Continuity Connector Terminal B45 48 Not existed Is inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK VOLTAGE SIDE CAMERA LH POWER SUPPLY Connect around view monitor control unit connector and door mirror (driver side) connector. Turn ignition switch ON. Check voltage between around view monitor control unit harness connector and ground. (+) (-) Condition Voltage (Approx.) Around view monitor control unit Connector Terminal B45 48 Ground "CAMERA" switch is ON or shift position is "R". 6.0 V Is inspection result normal? YES: GO TO 3. NO: Replace around view monitor control unit. Refer to " «EXPLODED VIEW»(ref-523997-S13080796432013012500000) ".
- CHECK CONTINUITY SIDE CAMERA LH IMAGE SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect around view monitor control unit connector and door mirror (driver side) connector. Check continuity between around view monitor control unit harness connector and door mirror (driver side) harness connector. Around view monitor control unit Door mirror (driver side) Continuity Connector Terminals Connector Terminals B45 51 D3 5 Existed 52 17 Check continuity between around view monitor control unit harness connector and ground. Around view monitor control unit Ground Continuity Connector Terminals B45 51, 52 Not existed Is inspection result normal? YES: GO TO 4. NO: Repair harness or connector.
- CHECK SIDE CAMERA LH IMAGE SIGNAL Connect around view monitor control unit connector and door mirror (driver side) connector. Turn ignition switch ON. Check signal between around view monitor control unit harness connector. (+) (-) Condition Reference value Around view monitor control unit Around view monitor control unit Connector Terminal Connector Terminal B45 51 B45 52 "CAMERA" switch is ON or shift position is "R". Is inspection result normal? YES: Replace around view monitor control unit. Refer to " «EXPLODED VIEW»(ref-523997-S13080796432013012500000) ". NO: Replace side camera LH. Refer to " «EXPLODED VIEW»(ref-523997-S38663039642013012500000) ".
- CHECK CONTINUITY COMMUNICATION SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect around view monitor control unit connector and door mirror (passenger side) connector. Check continuity between around view monitor control unit harness connector and door mirror (passenger side) harness connector. Around view monitor control unit Door mirror (passenger side) Continuity Connector Terminal Connector Terminal B46 33 D33 3 Existed Check continuity between around view monitor control unit harness connector and ground. Around view monitor control unit Ground Continuity Connector Terminal B46 33 Not existed Is inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK COMMUNICATION SIGNAL Connect around view monitor control unit connector and door mirror (passenger side) connector. Turn ignition switch ON. Check signal between around view monitor control unit harness connector and ground. (+) (-) Condition Reference value Around view monitor control unit Connector Terminal B46 33 Ground "CAMERA" switch is ON or shift position is "R". Is inspection result normal? YES: Replace around view monitor control unit. Refer to " «EXPLODED VIEW»(ref-523997-S13080796432013012500000) ". NO: Replace side camera RH. Refer to " «EXPLODED VIEW»(ref-523997-S26343990552013012500000) ".
- CHECK CONTINUITY SIDE CAMERA RH POWER SUPPLY AND GROUND CIRCUIT Turn ignition switch OFF. Disconnect control unit connector and door mirror (passenger side) connector. Check continuity between around view monitor control unit harness connector and door mirror (passenger side) harness connector. Around view monitor control unit Door mirror (passenger side) Continuity Connector Terminals Connector Terminals B46 32 D33 18 Existed 34 6 Check continuity between around view monitor control unit harness connector and ground. Around view monitor control unit Ground Continuity Connector Terminal B46 34 Not existed Is inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK VOLTAGE SIDE CAMERA RH POWER SUPPLY Connect around view monitor control unit connector and door mirror (passenger side) connector. Turn ignition switch ON. Check voltage between around view monitor control unit harness connector and ground. (+) (-) Condition Voltage (Approx.) Around view monitor control unit Connector Terminal B46 34 Ground "CAMERA" switch is ON or shift position is "R". 6.0 V Is inspection result normal? YES: GO TO 3. NO: Replace around view monitor control unit. Refer to " «EXPLODED VIEW»(ref-523997-S13080796432013012500000) ".
- CHECK CONTINUITY SIDE CAMERA RH IMAGE SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect around view monitor control unit connector and door mirror (passenger side) connector. Check continuity between around view monitor control unit harness connector and door mirror (passenger side) harness connector. Around view monitor control unit Door mirror (passenger side) Continuity Connector Terminals Connector Terminals B46 29 D33 5 Existed 30 17 Check continuity between around view monitor control unit harness connector and ground. Around view monitor control unit Ground Continuity Connector Terminals B46 29, 30 Not existed Is inspection result normal? YES: GO TO 4. NO: Repair harness or connector.
- CHECK SIDE CAMERA RH IMAGE SIGNAL Connect around view monitor control unit connector and door mirror (passenger side) connector. Turn ignition switch ON. Check signal between around view monitor control unit harness connector. (+) (-) Condition Reference value Around view monitor control unit Around view monitor control unit Connector Terminal Connector Terminal B46 29 B46 30 "CAMERA" switch is ON or shift position is "R". Is inspection result normal? YES: Replace around view monitor control unit. Refer to " «EXPLODED VIEW»(ref-523997-S13080796432013012500000) ". NO: Replace side camera RH. Refer to " «EXPLODED VIEW»(ref-523997-S26343990552013012500000) ".
- CHECK STEERING SWITCH SIGNAL A CIRCUIT Disconnect AV control unit connector and spiral cable connector. Check continuity between AV control unit harness connector and spiral cable harness connector. AV control unit Spiral cable Continuity Connector Terminal Connector Terminal M208 6 M36 24 Existed Check continuity between AV control unit harness connector and ground. AV control unit Ground Continuity Connector Terminal M208 6 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK SPIRAL CABLE Check spiral cable. Is the inspection result normal? YES: GO TO 3. NO: Replace spiral cable. Refer to " «EXPLODED VIEW»(ref-523991-S30900375582013012500000) ".
- CHECK AV CONTROL UNIT VOLTAGE Connect AV control unit connector and spiral cable connector. Turn ignition switch ON. Check voltage between AV control unit harness connector. (+) (-) Voltage (Approx.) AV control unit AV control unit AV control unit AV control unit Connector Terminal Connector Terminal M208 6 M208 15 5.0 V Is the inspection result normal? YES: GO TO 4. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ".
- CHECK STEERING SWITCH Turn ignition switch OFF. Check steering switch. Refer to " «COMPONENT INSPECTION»(ref-523997-S29347878432013012500000) ". Is the inspection result normal? YES: INSPECTION END NO: Replace steering switch. Refer to " «EXPLODED VIEW»(ref-523991-S13963794372013012500000) ".
Component Inspection
Measure the resistance between the steering switch connector terminals 14 to 17 and 15 to 17.
Standard
Between terminals 14 and 17
ENTER switch ON: 2003 - 2043 ohms
TALK switch ON: 716 - 730 ohms
MENU DOWN switch ON: 318 - 324 ohms
MENU UP switch ON: 120 - 122 ohms
SOURCE switch ON: 0 ohms
Between terminals 15 and 17
CANCEL/BACK switch ON: 716 - 730 ohms
PHONE switch ON: 318 - 324 ohms
VOL UP switch ON: 120 - 122 ohms
VOL DOWN switch ON: 0 ohms
Scheme 23
- CHECK STEERING SWITCH SIGNAL B CIRCUIT Disconnect AV control unit connector and spiral cable connector. Check continuity between AV control unit harness connector and spiral cable harness connector. AV control unit Spiral cable Continuity Connector Terminal Connector Terminal M208 16 M36 31 Existed Check continuity between AV control unit harness connector and ground. AV control unit Ground Continuity Connector Terminal M208 16 Not existed Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK SPIRAL CABLE Check spiral cable. Is the inspection result normal? YES: GO TO 3. NO: Replace spiral cable. Refer to " «EXPLODED VIEW»(ref-523991-S30900375582013012500000) ".
- CHECK AV CONTROL UNIT VOLTAGE Connect AV control unit connector and spiral cable connector. Turn ignition switch ON. Check voltage between AV control unit harness connector. (+) (-) Voltage (Approx.) AV control unit AV control unit Connector Terminal Connector Terminal M208 16 M208 15 5.0 V Is the inspection result normal? YES: GO TO 4. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ".
- CHECK STEERING SWITCH Turn ignition switch OFF. Check steering switch. Refer to " «COMPONENT INSPECTION»(ref-523997-S18142368842013012500000) ". Is the inspection result normal? YES: INSPECTION END NO: Replace steering switch. Refer to " «EXPLODED VIEW»(ref-523991-S13963794372013012500000) ".
Measure the resistance between the steering switch connector terminals 14 to 17 and 15 to 17.
Standard
Between terminals 14 and 17
ENTER switch ON: 2003 - 2043 ohms
TALK switch ON: 716 - 730 ohms
MENU DOWN switch ON: 318 - 324 ohms
MENU UP switch ON: 120 - 122 ohms
SOURCE switch ON: 0 ohms
Between terminals 15 and 17
CANCEL/BACK switch ON: 716 - 730 ohms
PHONE switch ON: 318 - 324 ohms
VOL UP switch ON: 120 - 122 ohms
VOL DOWN switch ON: 0 ohms
- CHECK STEERING SWITCH SIGNAL GND CIRCUIT Disconnect AV control unit connector and spiral cable connector. Check continuity between AV control unit harness connector and spiral cable harness connector. AV control unit Spiral cable Continuity Connector Terminal Connector Terminal M208 15 M36 33 Existed Connect AV control unit connector. Is the inspection result normal? YES: GO TO 2. NO: Repair harness or connector.
- CHECK SPIRAL CABLE Check spiral cable. Is the inspection result normal? YES: GO TO 3. NO: Replace spiral cable. Refer to " «EXPLODED VIEW»(ref-523991-S30900375582013012500000) ".
- CHECK GROUND CIRCUIT Connect AV control unit connector. Check continuity between AV control unit harness connector and ground. AV control unit Ground Continuity Connector Terminal M208 15 Not existed Is the inspection result normal? YES: GO TO 4. NO: Replace AV control unit. Refer to " «EXPLODED VIEW»(ref-523997-S22178566452013012500000) ".
- CHECK STEERING SWITCH Turn ignition switch OFF. Check steering switch. Refer to " «COMPONENT INSPECTION»(ref-523997-S34966230572013012500000) ". Is the inspection result normal? YES: INSPECTION END NO: Replace steering switch. Refer to " «EXPLODED VIEW»(ref-523991-S13963794372013012500000) ".
Measure the resistance between the steering switch connector terminals 14 to 17 and 15 to 17.
Standard
Between terminals 14 and 17
ENTER switch ON: 2003 - 2043 ohms
TALK switch ON: 716 - 730 ohms
MENU DOWN switch ON: 318 - 324 ohms
MENU UP switch ON: 120 - 122 ohms
SOURCE switch ON: 0 ohms
Between terminals 15 and 17
CANCEL/BACK switch ON: 716 - 730 ohms
PHONE switch ON: 318 - 324 ohms
VOL UP switch ON: 120 - 122 ohms
VOL DOWN switch ON: 0 ohms
