Audio, Visual & Navigation System (Without Navigation): Removal & Installation Infiniti FX50 II рестайлинг

BEFORE REPLACEMENT

When replacing AV control unit, save or print current vehicle specification with CONSULT configuration before replacement.

AFTER REPLACEMENT

Removal and Installation

Note. After the ignition switch is turned OFF, the AV control unit continues operating for approximately 30 seconds. Therefore, data corruption may occur if battery voltage is cut off within 30 seconds.

REMOVAL

1. Remove front display unit. Refer to " «EXPLODED VIEW»(ref-524059-S32556523132013012500000) ".
2. Remove AV control unit with a unified meter and A/C amp. as a single unit from the body.
3. Remove bracket screws, and then remove AV control unit.

INSTALLATION

Installation is the reverse order of removal.

Scheme 126

Scheme 127

1. Remove cluster lid D. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
2. Remove front display unit mounting screws.
3. Disconnect connector, and remove front display unit.

Installation is the reverse order of removal.

Scheme 128

1. Remove front door finisher. Refer to " «EXPLODED VIEW»(ref-524011-S09991688552013012500000) ".
2. Remove front door speaker mounting bolts.
3. Disconnect connector and remove front door speaker.

Installation is the reverse order of removal.

Scheme 129

1. Remove rear door finisher. Refer to " «EXPLODED VIEW»(ref-524011-S42629557552013012500000) ".
2. Remove rear door speaker mounting bolts.
3. Disconnect connector and remove rear door speaker.

Installation is the reverse order of removal.

Scheme 130

1. Remove speaker grille. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
2. Remove front squawker mounting screws.
3. Disconnect connector and remove front squawker.

Installation is the reverse order of removal.

Scheme 131

1. Remove luggage side finisher upper. Refer to " «EXPLODED VIEW»(ref-524011-S25532630132013012500000) ".
2. Remove rear squawker mounting screws.
3. Remove rear squawker.

Installation is the reverse order of removal.

Scheme 132

1. Remove center speaker grille. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
2. Remove center speaker mounting screws, lift up the center speaker and disconnect connector.
3. Remove center speaker.

Installation is the reverse order of removal.

Scheme 133

1. Pull up luggage finisher cover and hang the strap to upper body.
2. Remove woofer clamp.
3. Remove harness clip and connector.
4. Remove woofer.

Installation is the reverse order of removal.

Scheme 134

Scheme 135

1. Remove luggage floor spacer (LH). Refer to " «EXPLODED VIEW»(ref-524011-S25532630132013012500000) ".
2. Remove BOSE amp. mounting nuts.
3. Disconnect connector and remove BOSE amp.

Installation is the reverse order of removal.

Scheme 136

1. Remove luggage floor spacer (RH). Refer to " «EXPLODED VIEW»(ref-524011-S25532630132013012500000) ".
2. Remove nuts, and then satellite radio tuner (1).

Scheme 137

Install in the reverse order of removal.

Scheme 138

Refer to " COMPONENTS " for symbols in the figure.

1. Remove headlining (rear). Keep a service area. Refer to " «EXPLODED VIEW»(ref-524011-S05519117592013012500000) ".
2. Remove antenna base mounting nut.
3. Disconnect connector and remove antenna base.

Installation is the reverse order of removal.

Refer to " EXPLODED VIEW ".

Scheme 139

1. Remove cluster lid D. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
2. Remove multifunction switch mounting screws.
3. Disconnect connector and remove multifunction switch.

Installation is the reverse order of removal.

Refer to " EXPLODED VIEW ".

Scheme 140

1. Remove cluster lid C. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
2. Remove preset switch mounting screws (A), (B) and (C).
3. Disconnect connector and remove preset switch (2).

Scheme 141

Installation is the reverse order of removal.

Note. When installing preset switch, do not allow the print wire that connects preset switch and multifunction switch to get caught in between AV control unit and preset switch.

Scheme 142

1. Remove console box assembly. Refer to " «EXPLODED VIEW»(ref-524023-S26869316852013012500000) ".
2. Press the pawl from the back of console box assembly to remove USB connector.

Install in the reverse order of removal.

Refer to " EXPLODED VIEW ".

Scheme 143

1. Remove map lamp assembly. Refer to " «EXPLODED VIEW»(ref-524011-S05519117592013012500000) ".
2. Remove microphone, stretching pawls of map lamp assembly.

Installation is the reverse order of removal.

Scheme 144

1. Remove back door outside finisher upper. Refer to " «EXPLODED VIEW»(ref-524010-S42647225612013012500000) ".
2. Remove door handle cover. Refer to " «EXPLODED VIEW»(ref-524010-S42647225612013012500000) ".
3. Remove rear view camera mounting screws and rear view camera harness connector.
4. Remove rear view camera.

1. Installation is the reverse order of removal.
2. Adjust the guide line position if the guide line position is shifted after installing the rear view camera. Refer to " «ADJUSTMENT»(ref-524059-S27504458812013012500000) ".

Scheme 145

Scheme 146

1. Draw lines on rearward area of the vehicle passing through the following points: 200 mm (7.87 in) from both sides of the vehicle, and 0.5 m (1.64 ft), 1.0 m (3.28 ft) from the rear end of the bumper.
2. Set into "Adjust offset of rear view camera" mode of Confirmation/Adjustment mode.
3. Rotate the center dial, and then select the guiding line pattern so that its angle is aligned with the correction line of the rear of the vehicle. Selected pattern: 7
4. Fine adjust the guiding line so that its position is aligned to the correction line by pressing the up/down/left/right switches. Pressing "ENTER" enable the camera control unit to memory the adjusted guiding line position.

Up/Down adjustment range: -20 - 20

Left/Right adjustment range: -20 - 20

Scheme 147

Scheme 148

1. Remove luggage floor spacer (LH). Refer to " «EXPLODED VIEW»(ref-524011-S25532630132013012500000) ".
2. Remove TEL adapter unit screws, disconnect TEL adapter unit connector and remove the TEL adapter unit.

Install in the reverse order of removal.

Scheme 149
