Mirrors (Without Adp): Removal & Installation Infiniti FX50 II рестайлинг

REMOVAL

Base model

1. Remove the inside mirror cover.
2. Remove TORX bolt.
3. Disconnect harness connector from inside mirror.
4. Slide the inside mirror upward to remove.

Option model

1. Remove the rain sensor cover (LH and RH).
2. Disconnect harness connector from inside mirror.
3. Remove TORX bolt and slide inside mirror upward to remove.

INSTALLATION

Install in the reverse order of removal.

Scheme 26

1. Remove front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-524011-S09684262812013012500000) ".
2. Remove front door sash inner cover. Refer to " «EXPLODED VIEW»(ref-524065-S42048325062013012500000) ".
3. Disconnect door mirror harness connector.
4. Remove door mirror mounting nuts, and remove door mirror assembly.

Install in the reverse order of removal.

Scheme 27

1. Remove door mirror assembly. Refer to " «DOOR MIRROR ASSEMBLY: REMOVAL AND INSTALLATION»(ref-524069-S05933236092013012500000) ".
2. Remove glass mirror. Refer to " «GLASS MIRROR: REMOVAL AND INSTALLATION»(ref-524069-S10978731872013012500000) ".
3. Remove door mirror cover. Refer to " «DOOR MIRROR COVER: REMOVAL AND INSTALLATION»(ref-524069-S01655031382013012500000) ".
4. Remove screws (A) and connector, and then remove actuator (1).
5. Remove side camera. Side camera LH: Refer to " «REMOVAL AND INSTALLATION»(ref-523997-S30990619572013012500000) ". Side camera RH: Refer to " «REMOVAL AND INSTALLATION»(ref-523997-S38963290702013012500000) ".
6. Remove base cover and puddle lamp.

DOOR MIRROR COVER: Removal and Installation

Scheme 28

1. Remove the glass mirror. Refer to " «GLASS MIRROR: REMOVAL AND INSTALLATION»(ref-524069-S10978731872013012500000) ".
2. Remove the pawls, and disassemble the door mirror cover (1) from the mirror assembly.

Install in the reverse order of removal.
