AUTOMATIC DRIVE POSITIONER SYSTEM LINKED OPERATION
Description
Door mirror control is included in automatic drive positioner system. Refer to automatic drive positioner system for more details.
Refer to " AUTOMATIC DRIVE POSITIONER SYSTEM: SYSTEM DESCRIPTION ".
Scheme 1
Component Description
| Component | Function | |
|---|---|---|
| Automatic drive positioner control unit | Door mirror is supplied with power after receiving the input of the MIRROR SWITCH and CHANGEOVER SWITCH. | |
| Door mirror remote control switch | Mirror switch | It transmits mirror face adjust operation to AUTOMATIC DRIVE POSITIONER CONTROL UNIT. |
| Changeover switch | It transmits the LH/RH control of door mirror that supplies power to AUTOMATIC DRIVE POSITIONER CONTROL UNIT. | |
| Open/close switch | Power is supplied to folding mirror from door remote control switch when operating switch. | |
| Door mirror | Door mirror motor | It makes mirror face operate from side to side and up and down via integrated motor. |
| Folding motor | The door mirror operates because power is received from power supply when pressing door mirror remote control switch. | |
System Description
The sensor built in inside mirror detects the brightness of headlight of the vehicle behind and automatically changes the light transmission to decrease the brightness.
| Component | Function |
|---|---|
| Auto anti-dazzling inside mirror | It automatically changes the light transmittance according to the brightness of the light from the headlight of the vehicle behind. |
MIRROR SWITCH: Description
It operates angle of the door mirror face.
It transmits mirror face adjust operation to AUTOMATIC DRIVE POSITIONER CONTROL UNIT.
CHANGEOVER SWITCH: Description
Changeover switch is integrated into door mirror remote control switch.
Changeover switch has three positions (L, N and R).
It changes door mirror motor operation by transmitting control signal to automatic drive positioner control unit.
