Driver Assistance System (Ldw & Ldp): Removal & Installation Infiniti FX50 II рестайлинг

Collision/avoidance 2 illustrations ~149 words

REMOVAL

  1. Remove the lane camera cover.
  2. Remove the sun-visor holder and front roof finisher. And then disengage front side metal clip of the map lamp assembly. Keep a service area. Refer to " «EXPLODED VIEW»(ref-524011-S05519117592013012500000) ".
  3. Remove the bolts.
  4. Disconnect lane camera unit connector, and remove lane camera unit.

Note. When replace the lane camera bracket, remove the headlining assembly.

INSTALLATION

Installation is the reverse order of removal.

CAUTIONRemove the camera lens cap for replacement. Never give an impact to the lane camera unit. Perform the camera aiming every time the lane camera unit is removed and installed. Refer to " CAMERA AIMING ADJUSTMENT: DESCRIPTION ".

Scheme 15

Scheme 15: Exploded View
Scheme 15: Exploded View
  1. Remove the instrument driver lower panel. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
  2. Disengage the pawls. Then remove warning systems switch.

Install in the reverse order of removal.

Scheme 16

Scheme 16: Exploded View
Scheme 16: Exploded View
  1. Remove the console finisher assembly. Refer to " «EXPLODED VIEW»(ref-524023-S26869316852013012500000) ".
  2. Remove the sonar control unit. Refer to " «EXPLODED VIEW»(ref-523997-S17068345302013012500000) ".
  3. Remove the screw.
  4. Disconnect the connector. And remove lane departure warning buzzer.

Installation is the reverse order of removal.
