Driver Assistance System (Dca): Removal & Installation Infiniti FX50 II рестайлинг

Collision/avoidance 2 illustrations ~145 words

REMOVAL

  1. Remove front bumper fascia. Refer to " «EXPLODED VIEW»(ref-524010-S42009083622013012500000) ".
  2. Remove air guide lower (LH). Refer to " «EXPLODED VIEW»(ref-523998-S30110479132013012500000) ".
  3. Disconnect ICC sensor integrated unit connector.
  4. Remove mounting bolts from ICC sensor integrated unit.
  5. Remove ICC sensor integrated unit.

INSTALLATION

Install in the reverse order of removal.

CAUTIONAlways perform the laser beam aiming adjustment and check the operation after the replacement, removal, and installation of ICC sensor integrated unit. Refer to " ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT (ICC SENSOR INTEGRATED UNIT): DESCRIPTION ".

Scheme 49

Scheme 49: Exploded View
Scheme 49: Exploded View
  1. Remove clips on the back of the luggage side finisher lower (RH) to obtain space for work. Refer to " «EXPLODED VIEW»(ref-524011-S25532630132013012500000) ".
  2. Disconnect brake booster control unit connector.
  3. Remove mounting bolts from brake booster control unit.
  4. Remove brake booster control unit.

Install in the reverse order of removal.

Scheme 50

Scheme 50: Exploded View
Scheme 50: Exploded View
  1. Remove the instrument lower panel LH. Refer to " «EXPLODED VIEW»(ref-524023-S07630960972013012500000) ".
  2. Remove mounting screw from ICC warning chime.
  3. Remove ICC warning chime from the instrument lower panel LH.

Install in the reverse order of removal.
