Automatic Transaxle Control System: Specifications Hyundai Tucson II

Automatic Trans 16 illustrations ~647 words

Specifications

ItemSpecification
TypeHall Effect Sensor, 2 pins (Power: 9 V, Signal)
Operation condition40 ~ 150°C [-40 ~ 302°F]
Sensor length52.7~52.9 mm (2.0748~2.0827 in.)
Air gap0.95~1.65 mm (0.0374~0.0650 in.)

INPUT SPEED SENSOR SPECIFICATIONS

Scheme 34

Scheme 34: Removal
Scheme 34: Removal

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39
  1. Remove the battery and the battery tray. (Refer to «CHARGING SYSTEM»(ref-583688) .)
  2. Remove the under cover (A).
  3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-583681) .)
  4. Remove the valve body cover (A) and eyebolt (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~ 32.6 lb-ft) CAUTION: The gasket of the eyebolt use new one. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
  5. Remove the plate and the detend spring (A) after removing the bolt. Tightening torque: 24.5 ~ 35.3 N.m (2.5 ~ 3.6 kgf.m, 18.1 ~ 26.0 lb-ft)
  6. Remove the bolt (3ea) after disconnecting the solenoid valve connector (A) and the oil temperature sensor connector (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Be careful not to damage the harness lock connector.
  7. Remove the valve body assembly (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
  8. Disconnect the input & output speed sensor connector (A).
  9. Remove the input & output speed sensor (B) after removing the bolts (2ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
ItemSpecification
TypeHall Effect Sensor, 2 pins (Power: 9 V, Signal)
Operation condition40 ~ 150°C [-40 ~ 302°F]
Sensor length33.6 ~ 33.8 mm (1.3228 ~ 1.3307 in.)
Air gap0.25 ~ 1.9 mm (0.0098 ~ 0.0748 in.)

OUTPUT SPEED SENSOR SPECIFICATIONS

Scheme 40

Scheme 40: Removal
Scheme 40: Removal

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45
  1. Remove the battery and the battery tray. (Refer to «CHARGING SYSTEM»(ref-583688) .)
  2. Remove the under cover (A).
  3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-583681) .)
  4. Remove the valve body cover (A) and eyebolt (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~ 32.6 lb-ft) CAUTION: The gasket of the eyebolt use new one. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
  5. Remove the plate and the detend spring (A) after removing the bolt. Tightening torque: 24.5 ~ 35.3 N.m (2.5 ~ 3.6 kgf.m, 18.1 ~ 26.0 lb-ft)
  6. Remove the bolt (3ea) after disconnecting the solenoid valve connector (A) and the oil temperature sensor connector (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Be careful not to damage the harness lock connector.
  7. Remove the valve body assembly (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
  8. Disconnect the input & output speed sensor connector (A).
  9. Remove the input & output speed sensor (B) after removing the bolts (2ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
ItemSpecification
TypeNegative Thermal Coefficient Type
Operation temperature40 ~ 165°C [-40 ~ 329°F]
Resistance4.81 kohms ~ 39 ohms
FailsafeOil temperature set to default value [80°C (176°F)]

TRANSAXLE OIL TEMPERATURE SENSOR SPECIFICATIONS

Scheme 46

Scheme 46: Removal
Scheme 46: Removal

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48

Scheme 49

Scheme 49
Scheme 49
  1. Remove the battery and the battery tray. (Refer to «CHARGING SYSTEM»(ref-583688) .)
  2. Remove the under cover (A).
  3. Replace new gasket and the plug after draining the automatic transaxle fluid by removing the drain plug. (Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-583681) .)
  4. Remove the valve body cover (A) and eyebolt (B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~ 32.6 lb-ft) CAUTION: The gasket of the eyebolt use new one. NOTE: Remove installation bolts in the engine room first and then remove others under the vehicle.
  5. Disconnect the oil temperature sensor connector (A).
  6. Remove the oil temperature sensor (A) after removing a bolt. Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Be careful not to damage the harness lock connector.
