Automatic Transaxle Control System: Other Hyundai Tucson II

Automatic Trans 2 illustrations ~986 words

Connector [CHG-A]

PinDescriptionPinDescription
131
232Shift solenoid F (SS-B)
3Pressure control solenoid A (VFS-LINE)33Shift solenoid E (SS-A)
4Torque Converter Clutch solenoid (VFS-T/Con)34Ground (Power 1)
5Shift solenoid C (35R_VFS)35Ground (Power 2)
6Input speed sensor power36Sports mode down switch
7Output speed sensor power37Sports mode up switch
8Input speed sensor signal38Sports mode Select switch
9Output speed sensor signal39
1040Inhibitor switch signal (S1)
1141
1242
1343
1444
1545
1646
17Shift solenoid A (VFS-UD)47Solenoid supply power 1
18Shift solenoid B (VFS-26)48Solenoid supply power 2
19Shift lock solenoid49TCM Input power 1 (For solenoid)
20Shift solenoid D (VFS-OD)50TCM Input power 2 (For solenoid)
2151Reserved
22Rear lamp relay52Reserved
2353Oil temperature sensor (-)
24Start relay54Oil temperature sensor (+)
25Inhibitor switch signal (S2)55
26Inhibitor switch signal (S3)56
27Inhibitor switch signal (S4)57
2858
2959
3060

TCM TERMINAL FUNCTION (CONNECTOR CHG-A)

Connector [CHG-K]

PinDescriptionPinDescription
1Power ground31Power ground
2Battery power (B+)32Battery power (B+)
3Power ground33CAN High
4Battery power (B+)34CAN Low

TCM TERMINAL FUNCTION (CONNECTOR CHG-K)

TCM TERMINAL INPUT/ OUTPUT SIGNAL (CONNECTOR CHG-A) Pin Description Condition Type Level Test result 1 - - - - - 2 - - - - - 3 Pressure control solenoid A (VFS-LINE) - Output 0 V/Battery voltage level 9 V < Battery voltage level < 16V 4 Torque Converter Clutch solenoid (VFS-T/Con) - Output 0 V/Battery voltage level 9 V < Battery voltage level < 16V 5 Shift solenoid C (35R_VFS) - Output 0 V/Battery voltage level 9 V < Battery voltage level < 16 V 6 Input speed sensor power ON Power 0 V/7.5 V 7.5 V OFF 0.3 V 7 Output speed sensor power ON Power 0 V/7.5 V 7.5 V OFF 0.3 V 8 Input speed sensor signal High Input 0.7 V/1.4 V Low 9 Output speed sensor signal High Input 0.7 V/1.4 V Low 10 - - - - - 11 - - - - - 12 - - - - - 13 - - - - - 14 - - - - - 15 - - - - - 16 - - - - - 17 Shift solenoid A (VFS-UD) - Output 0 V/Battery voltage level 9 V < Battery voltage level < 16 V Power supply: V_SOL2 18 Shift solenoid B (VFS-26) - Output 0 V/Battery voltage level 9 V < Battery voltage level < 16 V Power supply: V_SOL2 19 Shift lock solenoid High Output 0 V/Battery voltage level Battery voltage level Low 9 V < Battery voltage level < 16V 0.3 V 20 Shift solenoid D (VFS-OD) - Output 0 V/Battery voltage level 9 V < Battery voltage level < 16 V Power supply: V_SOL1 21 - - - - - 22 Rear lamp relay R ON Output 0 V/Battery voltage level 0.3 V Other 9 V < Battery voltage level < 16 V Battery voltage level 23 - - - - - 24 Start relay High Output 0 V/Battery voltage level Battery voltage level Low 9 V < Battery voltage level < 16 V 0.3 V 25 Inhibitor switch signal (S2) High Input 0V/Battery voltage level Battery voltage level Low 9 V < Battery voltage level < 16 V 0.3 V 26 Inhibitor switch signal (S3) High Input 0 V/Battery voltage level Battery voltage level Low 9 V < Battery voltage level < 16 V 0.3 V 27 Inhibitor switch signal (S4) High Input 0 V/Battery voltage level Battery voltage level Low 9 V < Battery voltage level < 16V 0.3 V 28 - - - - - 29 - - - - - 30 - - - - - 31 - - - - - 32 Shift solenoid F (SS-B) High Output 0 V/Battery voltage level Battery voltage level Low 9 V < Battery voltage level < 16 V 0.3 V 33 Shift solenoid E (SS-A) High Output 0 V/Battery voltage level Battery voltage level Low 9 V < Battery voltage level < 16 V 0.3 V 34 Ground (Power 1) - Ground 0 V 0 V 35 Ground (Power 2) - Ground 0 V 0 V 36 Sports mode down switch Down ON Input 0V/Battery voltage level 0.3 V Other 9 V < Battery voltage level < 16 V Battery voltage level 37 Sports mode up switch Up ON Input 0 V/Battery voltage level 0.3 V Other 9 V < Battery voltage level < 16V Battery voltage level 38 Sports mode select switch Sport mode Input 0 V/Battery voltage level 0.3 V Other 9 V < Battery voltage level < 16V Battery voltage level 39 - - - - - 40 Inhibitor switch signal (S1) High Input 0 V/Battery voltage level Battery voltage level Low 9 V < Battery voltage level < 16 V 0.3 V 41 - - - - - 42 - - - - - 43 - - - - - 44 - - - - - 45 - - - - - 46 - - - - - 47 Solenoid supply power 1 ON Power 0V/Battery voltage level Battery voltage level OFF 9 V < Battery voltage level < 16 V 0.3 V 48 Solenoid supply power 2 ON Power 0 V/Battery voltage level Battery voltage level OFF 9 V < Battery voltage level < 16V 0.3 V 49 TCM Input power 1 (For solenoid) Power Battery voltage level Battery voltage level 9 V < Battery voltage level < 16V 50 TCM Input power 2 (For solenoid) - Power Battery voltage level Battery voltage level 9 V < Battery voltage level < 16V 51 - - - - - 52 - - - - - 53 Oil temperature sensor (-) - Ground 0 V 0 V 54 Oil temperature sensor (+) ON Input 0 V/3.3 V Sensor level (0 V ~ 3.3 V) OFF 0.3 V 54 - - - - - 55 - - - - - 56 - - - - - 57 - - - - - 58 - - - - - 59 - - - - - 60

Scheme 68

Scheme 68: Connector [CHG-A]
Scheme 68: Connector [CHG-A]
PinDescriptionConditionTypeLevelTest result
1Power groundGround0 V0 V
2Battery power (B+)ONPower0 V/Battery voltage levelBattery voltage level
OFF9 V < Battery voltage level < 16 V0.3 V
3Power groundGround0 V0 V
4Battery power (B+)ONPower0 V/Battery voltage levelBattery voltage level
OFF9 V < Battery voltage level < 16 V0.3 V
5Power groundGround0 V0 V
6Battery power (B+)PowerBattery voltage levelBattery voltage level
9 V < Battery voltage level < 16 V

TCM TERMINAL INPUT/ OUTPUT SIGNAL (CONNECTOR CHG-K)

TCM Learning

When shift shock is occurred or parts related with the transaxle are replaced, TCM learning should be performed.

In the following case, TCM learning is required.

  1. Transaxle assembly replacement
  2. TCM replacement
  3. TCM upgrading

Scheme 69

Scheme 69
Scheme 69
  1. TCM learning condition ATF temperature: 60 ~ 115°C (140 ~ 239°F)
  2. TCM learning procedure Stop learning Repeat the below shift pattern four times or more with stepping on the brake. Driving learning Drive the vehicle through all gears at D range. Drive from stop to 1st to 2nd to 3rd to 4th to 5th to 6th with keeping fixed throttle open. Down shift from 6th to 5th, 5th to 4th, 4th to 3rd, 3rd to 2nd, 2nd to 1st. Repeat the above driving pattern four times or more. NOTE: Up-shift throttle open: 15~30%
