Automatic Transaxle Control System: Removal & Installation Hyundai Tucson II

Automatic Trans 3 illustrations ~388 words

Installation

  1. Installation is the reverse of removal. CAUTION: Set room side lever and T/M side lever to "N" position.

Scheme 65

Scheme 65: TCM Connector And Terminal Function
Scheme 65: TCM Connector And Terminal Function

Replacement

Note. In the case of the vehicle equipped with immobilizer or button engine start system, perform "Key Teaching" procedure together. (Refer to IMMOBILIZER SYSTEM or BUTTON ENGINE START SYSTEM .)

Scheme 66

Scheme 66: Replacement
Scheme 66: Replacement

Scheme 67

Scheme 67
Scheme 67
  1. Turn ignition switch OFF and disconnect the negative (-) battery cable.
  2. Disconnect the TCM Connector (A).
  3. Remove the battery. (Refer to «CHARGING SYSTEM»(ref-583688) .)
  4. Remove the mounting bolts (A) and nut (B), and then remove the TCM (C). Tightening torque: 21.6 ~ 32.4 N.m (2.2 ~ 3.3 kgf.m, 15.9 ~ 23.9 lb-ft) 9.8 ~ 14.7 N.m (1.0 ~ 1.5 kgf.m, 7.2 ~ 10.9 lb-ft)
  1. Installation is the reverse of removal. CAUTION: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5 mm (0.0984 in.) thickness. Liquid gasket Part name: Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. (Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-583681) .)
  1. Installation is the reverse of removal. CAUTION: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5 mm (0.0984 in.) thickness. Liquid gasket Part name: Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. (Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-583681) .)
  1. Installation is the reverse of removal. CAUTION: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Continue to apply liquid gasket at application points at the valve body cover with Ø2.5 mm (0.0984 in.) thickness. Liquid gasket Part name: Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. (Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-583681) .)
  1. Installation is the reverse of removal.
  1. Installation is the reverse of removal. NOTE: After replacement or reinstallation procedure of the valve body assembly, must perform procedures below. Continue to apply liquid gasket at application points at the valve body cover with Ø 2.5 mm (0.0984 in.) thickness. Liquid gasket Part name: Threebond 1281B or LOCTITE FMD-546 Adding automatic transaxle fluid. Perform TCM learning after replacing the automatic transaxle to prevent slow automatic transaxle response, jerky acceleration and jerky startup (Refer to «TCM LEARNING»(ref-583723-S36593789312013121200000) ).
