Scheme 50: Components Location

Scheme 51

Scheme 51: Components

Scheme 52

Scheme 52: Removal

Scheme 53

Scheme 53

Scheme 54

Scheme 54

Scheme 55

Scheme 55

Scheme 56

Scheme 56
  1. Pull the gear knob (A) in the direction of the "F" and remove it, and then remove the console upper cover (B). (Refer to «INTERIOR»(ref-583702-S42378456302013102900000) .)
  2. Remove the center console assembly. (Refer to «INTERIOR»(ref-583702-S42378456302013102900000) .)
  3. Take off the clip (A) and the clamp (B) and then remove the shift cable (C).
  4. Disconnect sports mode connector (A).
  5. Remove the shift lever assembly (B) by removing the bolts (A-4ea). Tightening torque: 8.8 ~ 13.7 N.m (0.9 ~ 1.4 kgf.m, 6.5 ~ 10.1 lb-ft)
  6. Remove the shift cable assembly in the vehicle after removing the nuts (B) and the retainer (A). Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft)
  7. Remove the cable from the bracket at transaxle assembly side (Refer to «AUTOMATIC TRANSAXLE SYSTEM»(ref-583681) .)
  8. Remove the shift cable at cabin room.

Description

  1. Integrated one unit for input & output speed sensor
  2. Differential current type (low: 7 mA, high: 14 mA)
  3. Failsafe: 4th gear hold (D), 2nd ~ 4th manual shift (S)
  1. Integrated one unit for input & output speed sensor
  2. Differential current type (low: 7 mA, high: 14 mA)
  3. Failsafe: 4th gear hold (D), 2nd ~ 4th manual shift (S)
ItemSpecification
TypeCombination of output signals from 4 terminals
Power supply12 V
Range detection7-position (P, R, N, D, X, Y, Z)
Failsafe1st, 2nd gear is prohibited.

INHIBITOR SWITCH SPECIFICATIONS

Scheme 57

Scheme 57: Removal

Scheme 58

Scheme 58

Scheme 59

Scheme 59
  1. Set room side lever and T/M side lever to "N" position.
  2. Remove the battery and the battery tray. (Refer to «CHARGING SYSTEM»(ref-583688) .)
  3. Remove the air cleaner assembly. (Refer to «INTAKE MANIFOLD»(ref-583687-S27685555792013102900000) .)
  4. Remove the shift cable mounting nut (B).
  5. Disconnect the inhibitor switch connector (A).
  6. Remove the manual control lever (A) and the washer (B) after removing a nut (C). CAUTION: When installing, fix the manual control lever and the inhibitor switch with Ø5 mm (0.1969 in.) fixing jig. And then tighten the inhibitor assembly mounting bolts.
  7. Remove the inhibitor assembly (A) after removing the bolts (2ea). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: When installing, tighten the inhibitor assembly mounting bolt lightly.
