Tightening Torques
| Items | N.m | Kgf.m |
|---|
| Transfer assembly mounting bolts | 60.8~65.7 | 6.2~6.7 |
| 4WD ECM mounting nuts | 9.8~11.8 | 1.0~1.2 |
| Coupling assembly mounting bolts | 56.9~64.7 | 5.8~6.6 |
| Propeller shaft mounting bolts | 49.0~68.6 | 5.0~7.0 |
| Transfer oil drain plug | 39.2~58.8 | 4.0~6.0 |
| Transfer oil filler plug | 39.2~58.8 | 4.0~6.0 |
Lubricants
| Engine | Items | Specification | Capacity |
|---|
| Gasoline 3.3 | Transfer oil | Hypoid gear oil API GL-5, SAE 75W/90 (SHELL SPIRAX X or equivalent) | 0.68 L (0.18 U.S.gal, 0.72 U.S.qt, 0.60 lmp.qt) |
| All | Transfer spline | TECHLUBE MEGAMAX - ALPHA OR EQUIVALENT | As required |
| All | Coupling oil | SHELL TF0870 | 0.485 L (0.13 U.S.gal., 0.51U.S.qt, 0.43 lmp.qt.) |
Special Service Tools
Tools (Number and name) Illustration Use 09431-45100 Oil seal installer Installation of transfer case oil seal. (Right side) 09473-3B100 Oil seal installer Installation of transfer case oil seal. (Both side) * In case of gasoline 3.0/3.3, Use it after install the coupling (A)
Scheme 1
Scheme 1: Special Service Tools
Scheme 2
