Transfer Assembly Hyundai Santa Fe III

Transfer Case 23 illustrations ~635 words

Inspection

Information

  1. Transfer oil should be inspected and refilled every 60000 km (40000 mile)/4 year.

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5
  1. Remove the under cover (A).
  2. Remove the oil filler plug (A).
  3. Check the oil level. Information Oil level must be up to fill the hole, if not, add oil until it runs over.
  4. Install the oil filler plug with new gasket. Tightening torque: 39.2 ~ 58.8 N.m (4.0 ~ 6.0 kgf.m, 28.9 ~ 43.4 lb-ft)
  5. Install the under cover. Tightening torque: 7.8 ~ 9.8 N.m (0.8 ~ 1.0 kgf.m, 5.8 ~ 7.2 lb-ft)

Replacement

Information

Change
Normal UseSevere Use
No service required120000 km (80000 miles)

Severe driving conditions

  1. Driving in dusty, rough roads
  2. Driving in mountains areas
  3. Driving for patrol car, taxi, commercial car or vehicle towing
  4. Driving over 170 Km/h

* Transfer oil should be replaced if the transfer assembly is fall into the water.

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9
  1. Remove the under cover (A).
  2. Drain the transfer oil after loosening the drain plug (A).
  3. Install the drain plug with new gasket. Tightening torque: 58.9 ~ 78.5 N.m (6.0 ~ 8.0kgf.m, 43.4 ~ 57.9 lb-ft)
  4. Remove the oil filler plug (A).
  5. Add new oil through the filler plug hole. Standard oil : Hypoid gear oil API GL-5, SAE 75W/90 (SHELL SPIRAX X or equivalent) Oil capacity: Gasoline 3.3: About 0.68 L (0.18 U.S.gal, 0.72 U.S.qt, 0.60 lmp.qt) Information Filled up to lower filler plug thread level.
  6. Install the oil filler plug with new gasket. Tightening torque: 39.2 ~ 58.8 N.m (4.0 ~ 6.0 kgf.m, 28.9 ~ 43.4 lb-ft)
  7. Install the under cover. Tightening torque: 7.8 ~ 9.8N.m (0.8 ~ 1.0 kgf.m, 5.8 ~ 7.2 lb-ft)

Scheme 10

Scheme 10: Components Location
Scheme 10: Components Location

Scheme 11

Scheme 11: Removal
Scheme 11: Removal

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14
  1. Remove the following items; Sub frame assembly. (Refer to " «SUB FRAME»(/hyundai/santa-fe/iii-2012-2016/remont/suspension-front/#front-suspension-system-wheel-alignment) ") Front muffler. G 3.3 GDI (Refer to " «FRONT MUFFLER»(/hyundai/santa-fe/iii-2012-2016/remont/exhaust/#intake-and-exhaust-system) ") Drive shaft assembly. (Refer to " «FRONT DRIVESHAFT»(/hyundai/santa-fe/iii-2012-2016/remont/driveshaft-universal-joints/#driveshaft-assembly) ")
  2. Remove the propeller shaft (A). Tightening torque: 49.0 ~ 68.6 N.m (5.0 ~ 7.0 kgf.m, 36.2 ~ 50.6 lb-ft)
  3. Loosen the transfer upper & lower mounting bolts. (transfer side --> transaxle side)
  4. Loosen the transfer lower mounting blot. (transaxle side --> transfer side)

Scheme 15

Scheme 15: Installation
Scheme 15: Installation

Scheme 16

Scheme 16
Scheme 16
  1. Install in the reverse order of removal. NOTE: Be careful not to damage the O-ring (A). If the O-ring is damaged, replace with a new one. Smear and cover splines (B) with molybdenum type high pressure grease. TECHLUBE MEGAMAX - ALPHA OR EQUIVALENT Install the propeller shaft to be near runout marking (Transfer assembly 1ea, propeller shaft 1ea) each other.

Scheme 17

Scheme 17: Right side
Scheme 17: Right side

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22
  1. Remove the front muffler. G 3.3 GDI (Refer to " «FRONT MUFFLER»(/hyundai/santa-fe/iii-2012-2016/remont/exhaust/#intake-and-exhaust-system) ")
  2. Remove the driveshaft assembly. (RH side) (Refer to " «FRONT DRIVESHAFT»(/hyundai/santa-fe/iii-2012-2016/remont/driveshaft-universal-joints/#driveshaft-assembly) ")
  3. Remove the dust cover (A).
  4. Remove the oil seal (A, B).
  5. Install the oil seal with special service tools. NOTE: Apply lithium type grease between seal lips. Use the oil seal installer (09473-3B100) after install the coupling (A).
  6. Install the new dust cover (A).
  7. Add to transfer fluid. (Refer to " «TRANSFER FLUID»(/hyundai/santa-fe/iii-2012-2016/remont/transfer-case/#transfer-assembly) ")
  8. Install the drive shaft assembly. (RH side) (Refer to " «FRONT DRIVESHAFT»(/hyundai/santa-fe/iii-2012-2016/remont/driveshaft-universal-joints/#driveshaft-assembly) ")
  9. Install the front muffler. G 3.3 GDI (Refer to " «FRONT MUFFLER»(/hyundai/santa-fe/iii-2012-2016/remont/exhaust/#intake-and-exhaust-system) ")

Scheme 23

Scheme 23: Left side
Scheme 23: Left side

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25
  1. Remove the transfer assembly from the transaxle assembly. (Refer to Transfer Assembly - " «FRONT WHEEL TRANSFER ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/transfer-case/#transfer-assembly) ")
  2. Remove the oil seal (A).
  3. Install the oil seal with special service tools. NOTE: Apply lithium type grease between seal lips. Use the oil seal installer (09473-3B100) after install the coupling (A).
  4. Add to transfer fluid. (Refer to " «TRANSFER FLUID»(/hyundai/santa-fe/iii-2012-2016/remont/transfer-case/#transfer-assembly) ")
  5. Install the transfer assembly. (Refer to Transfer Assembly - " «FRONT WHEEL TRANSFER ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/transfer-case/#transfer-assembly) ")
