Driver Information System (Dis): Removal & Installation Hyundai Genesis I рестайлинг

Variant coding when replace the DIS head unit

DIS head unit delivers the necessary expertise such as multi media, air conditioning, trip computer and drive information. For these reasons, further information of vehicle have to be inputted to new DIS head unit when the DIS head unit is replaced.

Note. Below description is only using the GDS.

Installation

1. Install the Multi media Jack.
2. Connect the Multi Media Jack connector.
3. Install the under cover to the floor console.

Scheme 91

1. Disconnect the negative(-) battery terminal.
2. Disconnect the Multi Media Jack connector after from the floor console.
3. To inspect USB/IPOD port, check the voltage between NO. 1 and 4 terminal of. Standard value: 5V
4. To inspect AUX Jack, check the voltage between NO. 14 terminal of Jack output connector and NO. 4 terminal of USB/IPOD input port at AUX input. Standard value: 5V

Scheme 92

Scheme 93

1. Remove the rear roof trim. (Refer to the «ROOF TRIM»(ref-590392-S04478021052013121700000) )
2. Disconnect the GPS cable (C) and XM radio cable (D) after removing a nut (B).
3. Remove the roof antenna (A).

Scheme 94

1. Remove the hands free mic.
