Specifications
| Item | Specification | ||
|---|---|---|---|
| Model | RADIO/CDP/MP3/XM | RADIO/6CDC/MP3/XM | |
| Power supply | DC 14.4V | ||
| Rated output | Max 3.2Vrms | ||
| Load Impedance | 10KohmsX 4 | ||
| Antenna | 80PF 75ohms | ||
| Tuning type | PLL synthesized type | ||
| External amplifier&sub woofer | External amplifier&sub woofer | ||
| Frequency range/Channel space | FM | 87.5~107.9 MHz/200KHz | |
| AM | 530~1710KHz/9KHz | ||
AUDIO UNIT SPECIFICATION
* XM: Satellite Radio
| Item | Specification | |
|---|---|---|
| Power supply | Microcomputer | DC 5V |
| Illumination | DC 14.4V | |
| Operation Temperature | 20°C~ +65°C (-4°F ~ 149°F) | |
| Dark current | MAX 0.5mA | |
KEYBOARD UNIT SPECIFICATION
| Item | Specification |
|---|---|
| Voltage | DC 14.4V |
| Picture Size | 144(H) X 51(V) mm (5.6(H) X 2(V) inches) |
| Operation Temperature | 20°C~ +70°C (-4°F ~ 158°F) |
| View Angle | H/V: -45~+45/-35~ +25degrees |
MONITOR UNIT SPECIFICATION
| Model | General | Premium | DIS | ||||
|---|---|---|---|---|---|---|---|
| Item | Input Power | Speaker Impedance (ohms) | Input Power | Speaker Impedance (ohms) | Input Power | Speaker Impedance (ohms) | |
| Front door | Door speaker | 25W | 2 ± 0.3 | 25W | 2 ± 0.3 | 25W | 2 ± 0.3 |
| MAX 50W | MAX 50W | MAX 50W | |||||
| Tweeter speaker | 25W | 3.4 ± 0.5 | 8 Vrms | 3.6 | 8 Vrms | 3.6 | |
| MAX 50W | |||||||
| Middle speaker | 8 Vrms | 1.9 ± 0.25 | |||||
| Rear door | Door speaker | 25W | 2 ± 0.3 | 25W | 2 ± 0.3 | 25W | 2 ± 0.3 |
| MAX 50W | MAX 50W | MAX 50W | |||||
| Tweeter speaker | 8 Vrms | 3.6 | 8 Vrms | 3.6 | |||
| Center speaker | 8 Vrms | 2.15 ± 0.25 | 8 Vrms | 2.15 ± 0.25 | |||
| Sub woofer speaker | 25W | 2 ± 0.3 | 16 Vrms | 4.8 ± 1 | 16 Vrms | 4.8 ± 1 | |
| MAX 50W | |||||||
| Surround speaker | 8 Vrms | 2.15 ± 0.25 | 8 Vrms | 2.15 ± 0.25 | |||
| Center tweeter speaker | 8 Vrms | 3.6 | |||||
| Speaker Number | 7 EA | 14 EA | 17 EA | ||||
SPEAKER
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
- Disconnect the negative (-) battery terminal.
- Remove the crash pad lower panel (A).
- Remove the connector (A).
- Remove the mounting screws and then remove the audio unit (A).
- Remove the connector (A). NOTE: When the compact disc is not ejected, do not remove it forcibly
- When separate the CD ROM drive, if necessary, remove the screws (5EA) on the head unit.
- Remove the connector (A).
- Remove the CD ROM drive (A).
Scheme 15
Scheme 16
Scheme 17
- Disconnect the negative (-) battery terminal.
- Remove the cluster fascia panel. (Refer to the " «CRASH PAD»(ref-590392-S04150349602013121700000) ")
- Remove the crash pad side garnish (A) after removing the screws.
- Remove the center fascia panel (A) after removing the screws.
- Remove the connectors (A).
- Remove the keyboard unit (A) after removing the screws.
Scheme 18
Scheme 19
Scheme 20
Scheme 21
- Disconnect the negative (-) battery terminal.
- Remove the cluster fascia panel. (Refer to the " «CRASH PAD»(ref-590392-S04150349602013121700000) ")
- Remove the crash pad side garnish (A) after removing the screws.
- Remove the center fascia panel (A) after removing the screws.
- Remove the connectors (A).
- Remove the monitor unit (A) after removing the screws.
Scheme 22
