Description
The AUX JACK on the center console is for customers who like to listen to external portable music players like the MP3, iPod and etc., through the vehicle's sound system when it is linked to this jack. The customer has this added option.
In case of distortions from media connected to the AUX source, the audio unit may not be defective but the output level of the used media does not match the specification of the AUX input.
Note. Hyundai-iPod cable must be used to iPod playback. The Apple-iPod cable supplied with the player will NOT work.
Scheme 23
Scheme 24
- Remove the floor console (A). (Refer to " «CONSOLE»(ref-590392-S06749088792013121700000) ")
- Disconnect the jack assembly connector from the floor console.
- Remove the Multi media Jack (A) from the floor console.
Scheme 25
Introduction to XM radio
XM-Radio is a Satellite Based Radio Broadcast System that operates around 2.3 GHz from two 15, 000 watts satellites; one named "ROCK," at 115 Degrees West, the other named "ROLL" at 85.0 Degrees West. Or another way of saying, the satellites are positioned over the East and West Coasts of US. The service covers only US.
Due to the limitations of satellite transmission, the signal is not able to penetrate buildings, so it cannot effectively cover dense urban areas. The terrestrial repeater network extends SDARS coverage and allows providers to reach the greatest number of subscribers and provide quality coverage. The repeaters receive the XM signal directly from the satellites and then re-transmit it to XM radios anywhere.
XM provides digitalized radio programs in terms of channels. Each channel is a program that the user can tune to. A category is a group of channels. Examples of categories are classical, news and sports.
XM is a paid service. That means users have to make a subscription to XM before they can enjoy the programs. However, XM does give some free-to-air channels. The users can listen to one of them without making any subscription.
Scheme 26
Scheme 27
| XM1 | XM band |
|---|---|
| CH 100 | Channel Number |
| Dance | Category name |
| Dance hits | Channel name |
| Britney Jean Spears | Artist name |
| TOXIC | Song title |
| P1/P2/P3/P4/P5/P6 | Preset channel number |
| 100 | Current preset channel number |
| *The disc icons reflect the actual disc status in the CD changer (for CDC Models). | |
| * User can select the base display of channel info. (Option 1 or Option 2) | |
| * Information display mode is extended mode. (Display allowable characters.) | |
MAIN DISPLAY IN XM MODE
