Specification
| Fuel Level Sensor | Specification | ||||
|---|---|---|---|---|---|
| Float Position | 8/8 | 7/8 | 6/8 | 2/8 | MIL ON |
| Fuel Level Sender A Resist. (ohms) | 4 | 15.5 | 15.5 | 41 | 74.6 |
| Fuel Level Senor B Resist. (0) | 4 | 20.5 | 41.5 | 100 | 100 |
| Quantity ( l ) | 74.5 | 64.3 | 56.2 | 23.7 | 11.6 |
SPECIFICATION CHART
Scheme 65
Scheme 66
- Connect GDS.
- IG "ON" and engine "OFF".
- Select "DTC Analysis" mode.
- After erase DTC, keep the vehicle condition within "the enable conditions" (Refer to " «DTC DETECTING CONDITION»(ref-345951-S11997417612009102300000) " table).
- Is the same DTC occurred again? YES Go to next procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or CLU's connector or was repaired and CLU memory was not cleared. T-horoughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-345951-S10124662282009102300000) " procedure.
