Body Network System: Overview Hyundai Genesis I

Scheme 67

Description

The driver door module is a part of a Controller Area Network (CAN), and performs CAN communication with the FAM, IPM, ADM, and IMS. Driver controls driver side power window switch button located inside of the driver side door to operate power window, mirror, door lock and unlock.

1. Two manual operations (up and down) for four p/windows. However, on the driver's seat the auto up/down operation must be possible.
2. Opening and closing the quarter glass by the quarter glass switch.
3. Window UP/DOWN operation.
4. Manually operating the mirror position by the manual switch (Up, Down, Right, and Left)
5. Saving and replacing the mirror position by the MEMORY switch --> For 2 persons
6. Out side mirror AUTO reverse operation
7. Out side mirror FOLD/UNFOLD power control
8. CENTRAL DOOR LOCK/UNLOCK function
9. Illumination control

Outside Mirror Memory Operation By The Memory Switch

1. If position switch (POS1 or POS2) is pressed within 5 seconds after pressing the memory switch under ignition 2 on, it registers current mirror position. (Memory permit status lasts for 5 seconds after memory switch ON. After 5 seconds, memory permits status terminates. In other words, current position is registered if the position switch (POS1 or POS2) is turned on, during the memory permit status). However, RH side mirror position is not registered during the LH side mirror manual switch operation.
2. Memory permit status is released if any of the following conditions is met If 5 seconds is elapsed after the memory switch is turned on If the ignition 2 is turned off When saving is completed If Ignition switch of the CAN communication data sent by the IPM is not "Run" or "Start". If Inhibit switch of the CAN communication data sent by the FAM is not "P". If vehicle speed of the CAN communication data sent by the cluster is "3 Km/h" or more.
3. Memory is cleared if the battery is removed.

Outside Mirror Memory And Replay Operation By Keyless

1. Memory operation Outside mirror LH position is registered in the driver side power window switch when the ignition is turned off from on.
2. Replay prohibit condition If the mirror switch on the LH side is pressed If Ignition switch of the CAN communication data sent by the IPM is not "Run" or "Start". If Inhibit switch of the CAN communication data sent by the IPM is not "P". If vehicle speed of the CAN communication data sent by the CLUSTER is "3Km/h" or more.

General Description

All 13 units which consists of the Body Electrical Control System are linked by CAN *1 line.

They are IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System), DATC (Dual Auto Temperature Control Module).

*1 CAN (Controller Area Network) : CAN is serial bus communication type which links not only communication system but also control units each other.

*2 LIN (Local Interconnect Network) : LIN is serial communication type which is used in electrical control system. (This is less expensive.)

Scheme 68

DTC Description

B1602 CAN ERROR

Refer to DTC B1602 : CAN ERROR .

This is DTC which is related with communication error between IPM and other units.

( Control Units : IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System))

Case1: After short between ADM CAN Low Line and High Line, short to ground together.

Case2: After short between ADM CAN Low Line and High Line, short to power together.

This code is occurred when It is not possible to transmit data by CAN Line in those way of Software and Hardware. But, It is possible to receive data by CAN Line.

This code reports BUS OFF status when data transmit error count number is over 255. The purpose is to verify the status of CAN controller and CAN communication line when error is detected.

According to operation condition, some of module which are connected to CAN line may not detect B1603.

Also, B1602 coincides with B1603 at all times.

All 13 units which consists of the Body Electrical Control System are linked by CAN *1 line.

They are IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System), DATC (Dual Auto Temperature Control Module).

*1 CAN (Controller Area Network) : CAN is serial bus communication type which links not only communication system but also control units each other.

*2 LIN (Local Interconnect Network) : LIN is serial communication type which is used in electrical control system. (This is less expensive.)

This code is outputted when the serial communication protocol is broken between DDM and RLDM by open, short or noise.

Refer to DTC B1681 : DDM AND REAR LH SERIAL COMMUNICATION ERROR .

This code is outputted when the serial communication protocol is broken between DDM and RRDM by open, short or noise.

L/H Mirror is controlled by pressing direction switch (UP, DOWN, LEFT, RIGHT) with IG ON after R/H Mirror is selected by Power Window Main Switch.

Case1 : DDM sets DTC when the change value of assist mirror position is less than 0.1V for 5sec while it is not reached to the aimed position.

Case2 : DDM sets DTC when there is counter-direction output which is 0.25V and above while assist mirror is turning to one direction.

Case3 : DDM sets DTC when there is no movement signal from positioning sensor in assist mirror.

Refer to DTC B1910 : OUTSIDE MIRROR - LEFT HORIZONTAL MOTOR OR SENSOR ERROR .

Case1 : DDM sets DTC when the change value of assist mirror position is less than 0.1V for 5sec while it is not reached to the aimed position.

Case2 : DDM sets DTC when there is counter-direction output which is 0.25V and above while assist mirror is turning to one direction.

Case3 : DDM sets DTC when there is no movement signal from positioning sensor in assist mirror.

The assist door module is a part of CAN, and performs CAN communication with the FAM, IPM, DDM, and IMS. The driver can control the power window, mirror, door (lock/unlock) by using buttons of the ADM on the door of the driver's seat.

1. Operating the power window by buttons
2. Central Door LOCK/UNLOCK function
3. Manually operating the mirror position by the manual SW (Up, Down, Right, and Left)
4. Saving and replacing the mirror position by the memory switch --> For 2 persons
5. Out side mirror AUTO reverse operation
6. Illumination control

1. IMS Message from DDM is sent to RETURN1 or RETURN2, out side mirror returns to the position stored.
2. Memory permit status is released if any of the following conditions is met If 5 seconds is elapsed after the memory switch is turned on If the ignition 2 is turned off When saving is completed If Ignition switch of the CAN communication data sent by the IPM is not "Run" or "Start". If Inhibit switch of the CAN communication data sent by the FAM is not "P". If vehicle speed of the CAN communication data sent by the cluster is "3Km/h" or more.
3. Memory is cleared if the battery is removed

Outside Mirror Memory And Replay Operation By The Memory Switch

1. IMS message from DDM is sent to RETURN1 or RETURN2, O/S MIRROR returns to the position stored.
2. Replacing not stored position doesn't work.
3. If RETURN Message is sent during replacing, the last Message has priority.
4. Replacing Prohibition Conditions. If the mirror switch on the LH side is pressed If Ignition switch of the CAN communication data sent by the IPM is not "Run". If Inhibit switch of the CAN communication data sent by the IPM is not "P". If vehicle speed of the CAN communication data sent by the CLUSTER is "3Km/h".

All 13 units which consists of the Body Electrical Control System are linked by CAN *1 line.

They are IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System), DATC (Dual Auto Temperature Control Module).

*1 CAN (Controller Area Network) : CAN is serial bus communication type which links not only communication system but also control units each other.

*2 LIN (Local Interconnect Network) : LIN is serial communication type which is used in electrical control system. (This is less expensive.)

Scheme 69

B1602 CAN ERROR

Refer to DTC B1602 : CAN ERROR .

This is DTC which is related with communication error between IPM and other units.

( Control Units : IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System))

Case1: After short between ADM CAN Low Line and High Line, short to ground together.

Case2: After short between ADM CAN Low Line and High Line, short to power together.

This code is occurred when It is not possible to transmit data by CAN Line in those way of Software and Hardware. But, It is possible to receive data by CAN Line.

This code reports BUS OFF status when data transmit error count number is over 255. The purpose is to verify the status of CAN controller and CAN communication line when error is detected.

According to operation condition, some of module which are connected to CAN line may not detect B1603.

Also, B1602 coincides with B1603 at all times.

R/H Mirror is controlled by pressing direction switch (UP, DOWN, LEFT, RIGHT) with IG ON after R/H Mirror is selected by Power Window Main Switch.

Scheme 70

Case1 : ADM sets DTC when the change value of assist mirror position is less than 0.1V for 5sec while it is not reached to the aimed position.

Case2 : ADM sets DTC when there is counter-direction output which is 0.25V and above while assist mirror is turning to one direction.

Case3 : ADM sets DTC when there is no movement signal from positioning sensor in assist mirror.

Refer to DTC B1912 : OUTSIDE MIRROR - RIGHT HORIZONTAL MOTOR OR SENSOR .

Case1 : ADM sets DTC when the change value of assist mirror position is less than 0.1V for 5sec while it is not reached to the aimed position.

Case2 : ADM sets DTC when there is counter-direction output which is 0.25V and above while assist mirror is turning to one direction.

Case3 : ADM sets DTC when there is no movement signal from positioning sensor in assist mirror.

All 13 units which consists of the Body Electrical Control System are linked by CAN *1 line.

They are IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System), DATC (Dual Auto Temperature Control Module).

*1 CAN (Controller Area Network) : CAN is serial bus communication type which links not only communication system but also control units each other.

*2 LIN (Local Interconnect Network) : LIN is serial communication type which is used in electrical control system. (This is less expensive.)

Scheme 71

B1602 CAN ERROR

Refer to DTC B1602 : CAN ERROR .

This is DTC which is related with communication error between IPM and other units.

( Control Units : IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System))

Case1: After short between FAM CAN Low Line and High Line, short to ground together.

Case2: After short between FAM CAN Low Line and High Line, short to power together.

This code is occurred when It is not possible to transmit data by CAN Line in those way of Software and Hardware. But, It is possible to receive data by CAN Line.

This code reports BUS OFF status when data transmit error count number is over 255. The purpose is to verify the status of CAN controller and CAN communication line when error is detected.

According to operation condition, some of module which are connected to CAN line may not detect B1603.

Also, B1602 coincides with B1603 at all times.

FAM controls the low/high wiper relay according to rain sensor signal when the wiper auto switch is turned to ON under IG ON.

Note. The rain sensor is mounted on the interior side of the front windshield glass behind the rearview mirror. If driver turns the wiper switch to AUTO, this signal is inputted to FAM by LIN communication. FAM transmits 5 steps of signals (Slow <--> Fast) from the wiper auto switch to the rain sensor. At the slowest step among the INT switch, the rain sensor becomes the most insensitive status. At the fastest step among the INT switch, the rain sensor becomes the most sensitive status to measure the amount of rain. So, the sensitivity of the rain sensor depends on the steps of the INT switch. The rain sensor transmits the desired speed of a wiper by duty signal to FAM.

Scheme 72

[FAM output signal (FAM --> Rain sensor)]

FAM transmits sensitivity step signal from INT switch to the rain sensor by pulse signal.

Scheme 73

[FAM input signal (Rain sensor --> FAM)]

The Rain sensor transmits moisture status and the desired wiper speed to FAM by pulse signal.

Scheme 74

* The Rain sensor has various outputs according to each modes as below. (Duty cycle changes)

Rain sensor output signal (Rain sensor --> FAM)

RAIN SENSOR OUTPUT SIGNAL REFERENCE

FAM outputs this code when it detects internal error of rain sensor after wiper switch has been turned to AUTO under IG "ON" or IG "ON" & ENG "ON".

FAM controls the low/high wiper relay according to rain sensor signal when the wiper auto switch is turned to ON under IG ON.

As the wiper INT switch is set at AUTO mode, combination switch transmits value of INT step to ECW by LIN communication. And, ECW communicates with FAM by CAN.

[FAM output signal (FAM --> Rain sensor)]

FAM transmits sensitivity step signal from INT switch to the rain sensor by pulse signal.

[FAM input signal (Rain sensor --> FAM)]

The Rain sensor transmits moisture status and the desired wiper speed to FAM by pulse signal.

The Rain sensor has various outputs according to each modes as below. (Duty cycle changes)

Rain sensor output signal (Rain sensor --> FAM)

RAIN SENSOR OUTPUT SIGNAL REFERENCE

The rain sensor is attached to the front windshield glass. This code is outputted when the rain sensor is attached badly or detached from the front windshield glass.

Refer to DTC B1906 : RAIN SENSOR FAULT 2 .

FAM outputs this code when FAM can't receive data from the rain sensor.

1. In case of shaking the rain sensor after detaching from windshield.
2. In case each circuits of input and output are shorted to ground.
3. In case each circuits of input and output are shorted to power.
4. In case each circuits of input and output are open.
5. In case the rain sensor connector is disconnected.

All 13 units which consists of the Body Electrical Control System are linked by CAN *1 line.

They are IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System), DATC (Dual Auto Temperature Control Module).

*1 CAN (Controller Area Network) : CAN is serial bus communication type which links not only communication system but also control units each other.

*2 LIN (Local Interconnect Network) : LIN is serial communication type which is used in electrical control system. (This is less expensive.)

B1602 CAN ERROR

Refer to DTC B1602 : CAN ERROR .

This is DTC which is related with communication error between IPM and other units.

( Control Units : IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System))

Case1: After short between SCM CAN Low Line and High Line, short to ground together.

Case2: After short between SCM CAN Low Line and High Line, short to power together.

This code is occurred when It is not possible to transmit data by CAN Line in those way of Software and Hardware. But, It is possible to receive data by CAN Line.

This code reports BUS OFF status when data transmit error count number is over 255. The purpose is to verify the status of CAN controller and CAN communication line when error is detected.

According to operation condition, some of module which are connected to CAN line may not detect B1603.

Also, B1602 coincides with B1603 at all times.

IMS (Integrated Memory System) is a system which can memorize the position of power seat (PTM), tilt/telescope handle (SCM), side mirror (DDM/ADM) by position sensor and restores them to a previous position. (Memory function is not allowed during driving for safety reason)

SCM sets this code when amount of change of the tilt motor position sensor is little than 12edge (6pulse) for 2sec. This means that tilt motor/sensor stuck due to open or short in circuit or external cause (compulsive restriction)

Refer to DTC B1959 : TILT POSITION SENSOR ERROR .

SCM sets this code when amount of change of the telescopic motor position sensor is little than 12edge (6pulse) for 2sec. This means that telescopic motor/sensor stuck due to open or short in circuit or external cause (compulsive restriction)

All 13 units which consists of the Body Electrical Control System are linked by CAN *1 line. They are IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System), DATC (Dual Auto Temperature Control Module).

*1 CAN (Controller Area Network) : CAN is serial bus communication type which links not only communication system but also control units each other.

*2 LIN (Local Interconnect Network) : LIN is serial communication type which is used in electrical control system. (This is less expensive.)

Scheme 75

B1602 CAN ERROR

Refer to DTC B1602 : CAN ERROR .

This is DTC which is related with communication error between IPM and other units.

( Control Units : IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System))

Case1: After short between FDM CAN Low Line and High Line, short to ground together.

Case2: After short between FDM CAN Low Line and High Line, short to power together.

This code is occurred when It is not possible to transmit data by CAN Line in those way of Software and Hardware. But, It is possible to receive data by CAN Line.

This code reports BUS OFF status when data transmit error count number is over 255. The purpose is to verify the status of CAN controller and CAN communication line when error is detected.

According to operation condition, some of module which are connected to CAN line may not detect B1603.

Also, B1602 coincides with B1603 at all times.

All 13 units which consists of the Body Electrical Control System are linked by CAN *1 line.

They are IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System), DATC (Dual Auto Temperature Control Module).

*1 CAN (Controller Area Network) : CAN is serial bus communication type which links not only communication system but also control units each other.

*2 LIN (Local Interconnect Network) : LIN is serial communication type which is used in electrical control system. (This is less expensive.)

Scheme 76

B1602 CAN ERROR

Refer to DTC B1602 : CAN ERROR .

This is DTC which is related with communication error between IPM and other units.

( Control Units : IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System))

Case1: After short between ADM CAN Low Line and High Line, short to ground together.

Case2: After short between ADM CAN Low Line and High Line, short to power together.

This code is occurred when It is not possible to transmit data by CAN Line in those way of Software and Hardware. But, It is possible to receive data by CAN Line.

This code reports BUS OFF status when data transmit error count number is over 255. The purpose is to verify the status of CAN controller and CAN communication line when error is detected.

According to operation condition, some of module which are connected to CAN line may not detect B1603.

Also, B1602 coincides with B1603 at all times.

FBWS is a parking assistant system. It has a supersonic sensor which radiates supersonic to front and rear side of the vehicle to detect supersonic reflected from an obstacle. It calculates distances between vehicle and obstacle if it detects reflected supersonic. It warns being obstacle to drivers through buzzer or displaying on cluster according to distance from obstacle. Warning level is divided into 3 step (warning level rises progressively according to distance from obstacle)

This code reports short to battery in power harness of front or rear supersonic sensor.

Refer to DTC B1621 : POWER ERROR .

This code reports an error in RX line. The purpose is to verify the status of FBWS UNIT, Sensor and Wire when error is detected.

Refer to DTC B1621 : POWER ERROR .

This code reports an error in RX line. The purpose is to verify the status of FBWS UNIT, Sensor and Wire when error is detected.

Refer to DTC B1621 : POWER ERROR .

This code reports an error in RX line. The purpose is to verify the status of FBWS UNIT, Sensor and Wire when error is detected.

Refer to DTC B1621 : POWER ERROR .

This code reports an error in RX line. The purpose is to verify the status of FBWS UNIT, Sensor and Wire when error is detected.

Refer to DTC B1621 : POWER ERROR .

This code reports an error in RX line. The purpose is to verify the status of FBWS UNIT, Sensor and Wire when error is detected.

Refer to DTC B1621 : POWER ERROR .

This code reports an error in RX line. The purpose is to verify the status of FBWS UNIT, Sensor and Wire when error is detected.

Refer to DTC B1621 : POWER ERROR .

This code reports an error in RX line. The purpose is to verify the status of FBWS UNIT, Sensor and Wire when error is detected.

Refer to DTC B1621 : POWER ERROR .

This code reports an error in RX line. The purpose is to verify the status of FBWS UNIT, Sensor and Wire when error is detected.

All 13 units which consists of the Body Electrical Control System are linked by CAN *1 line.

They are IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System), DATC (Dual Auto Temperature Control Module).

*1 CAN (Controller Area Network) : CAN is serial bus communication type which links not only communication system but also control units each other.

*2 LIN (Local Interconnect Network) : LIN is serial communication type which is used in electrical control system. (This is less expensive.)

Scheme 77

B1602 CAN ERROR

Refer to DTC B1602 : CAN ERROR .

This is DTC which is related with communication error between IPM and other units.

( Control Units : IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System))

Case1: After short between ADM CAN Low Line and High Line, short to ground together.

Case2: After short between ADM CAN Low Line and High Line, short to power together.

This code is occurred when It is not possible to transmit data by CAN Line in those way of Software and Hardware. But, It is possible to receive data by CAN Line.

This code reports BUS OFF status when data transmit error count number is over 255. The purpose is to verify the status of CAN controller and CAN communication line when error is detected.

According to operation condition, some of module which are connected to CAN line may not detect B1603.

Also, B1602 coincides with B1603 at all times.

IMS (Integrated Memory System) is a system which can memorize the position of power seat (PTM), tilt/telescope handle (SCM), side mirror (DDM/ADM) by position sensor and restores them to a previous position. (Memory function is not allowed during driving for safety reason)

PSM sets this code when amount of change of the Slide motor position sensor is little than 12edge (6pulse) for 2sec. This means that Slide motor/sensor stuck due to open or short in circuit or external cause (compulsive restriction)

Refer to DTC B1954 : SLIDE MOTOR OR SENSOR ERROR .

PSM sets this code when amount of change of the Recline motor position sensor is little than 12edge (6pulse) for 2sec. This means that Recline motor/sensor stuck due to open or short in circuit or external cause (compulsive restriction)

Refer to DTC B1954 : SLIDE MOTOR OR SENSOR ERROR .

PSM sets this code when amount of change of the Front height motor position sensor is little than 8edge (4pulse) for 1sec. This means that Front height motor/sensor stuck due to open or short in circuit or external cause (compulsive restriction)

Refer to DTC B1954 : SLIDE MOTOR OR SENSOR ERROR .

PSM sets this code when amount of change of the Rear height motor sensor is little than 8edge (4pulse) for 1sec. This means that rear height motor/sensor stuck due to open or short in circuit or external cause (compulsive restriction)

Refer to DTC B1602 : CAN ERROR .

This code is outputted when the signal line of cruise switch is short to ground.

Refer to DTC B1602 : CAN ERROR .

This code is outputted when the signal line of audio1 switch is short to ground or power.

Refer to DTC B1602 : CAN ERROR .

This code is outputted when the signal line of audio2 switch is short to ground or power.

Refer to DTC B1602 : CAN ERROR .

This code is outputted when MFSW receives over two signals of light switch at the same time.

Refer to DTC B1602 : CAN ERROR .

This code is outputted when MFSW receives over two signals (turn right & turn left) of turn signal at the same time.

Refer to DTC B1602 : CAN ERROR .

This code is outputted when MFSW receives over two signals (OFF & INT, OFF & LOW, OFF & HIGH, INT & LOW, INT & HIGH, LOW & HIGH) of wiper switch at the same time.

All 13 units which consists of the Body Electrical Control System are linked by CAN *1 line.

They are IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System), DATC (Dual Auto Temperature Control Module).

1. *1. CAN (Controller Area Network) : CAN is serial bus communication type which links not only communication system but also control units each other.
2. *2. LIN (Local Interconnect Network) : LIN is serial communication type which is used in electrical control system. (This is less expensive.)

Scheme 78

B1602 CAN ERROR

Refer to DTC B1602 : CAN ERROR .

This is DTC which is related with communication error between IPM and other units.

( Control Units : IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System))

Case1: After short between ADM CAN Low Line and High Line, short to ground together.

Case2: After short between ADM CAN Low Line and High Line, short to power together.

This code is occurred when It is not possible to transmit data by CAN Line in those way of Software and Hardware. But, It is possible to receive data by CAN Line.

This code reports BUS OFF status when data transmit error count number is over 255. The purpose is to verify the status of CAN controller and CAN communication line when error is detected.

According to operation condition, some of module which are connected to CAN line may not detect B1603. Also, B1602 coincides with B1603 at all times.

All 13 units which consists of the Body Electrical Control System are linked by CAN *1 line.

They are IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System), DATC (Dual Auto Temperature Control Module).

*1 CAN (Controller Area Network) : CAN is serial bus communication type which links not only communication system but also control units each other.

*2 LIN (Local Interconnect Network) : LIN is serial communication type which is used in electrical control system. (This is less expensive.)

B1602 CAN ERROR

Refer to DTC B1602 : CAN ERROR .

This is DTC which is related with communication error between IPM and other units.

( Control Units : IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System))

Case1: After short between CLU CAN Low Line and High Line, short to ground together.

Case2: After short between CLU CAN Low Line and High Line, short to power together.

This code is occurred when It is not possible to transmit data by CAN Line in those way of Software and Hardware. But, It is possible to receive data by CAN Line.

This code reports BUS OFF status when data transmit error count number is over 255. The purpose is to verify the status of CAN controller and CAN communication line when error is detected.

According to operation condition, some of module which are connected to CAN line may not detect B1603.

Also, B1602 coincides with B1603 at all times.

EMS ECU calculates estimated fuel vapor pressure by fuel level value. Fuel vapor pressure is changed by fuel level variation. Fuel vapor pressure is essential factor to monitor operation of EVAP. Control System.

By the way, in case the fuel level is too low or too high, it's hard to get reliable value of fuel vapor pressure. So, EMS ECU judges whether fuel level is suitable to monitor EVAP. Control System precisely. After power is inputted to a fuel sender from a cluster, fuel level value from a fuel sender is inputted to a cluster.

This code is outputted when signal circuit of a fuel sender is open or shorted to GND.

All 13 units which consists of the Body Electrical Control System are linked by CAN *1 line.

They are IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System), DATC (Dual Auto Temperature Control Module).

*1 CAN (Controller Area Network) : CAN is serial bus communication type which links not only communication system but also control units each other.

*2 LIN (Local Interconnect Network) : LIN is serial communication type which is used in electrical control system. (This is less expensive.)

Scheme 79

B1602 CAN ERROR

Refer to DTC B1602 : CAN ERROR .

This is DTC which is related with communication error between IPM and other units.

( Control Units : IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System))

Case1: After short between ADM CAN Low Line and High Line, short to ground together.

Case2: After short between ADM CAN Low Line and High Line, short to power together.

This code is occurred when It is not possible to transmit data by CAN Line in those way of Software and Hardware. But, It is possible to receive data by CAN Line.

This code reports BUS OFF status when data transmit error count number is over 255. The purpose is to verify the status of CAN controller and CAN communication line when error is detected.

According to operation condition, some of module which are connected to CAN line may not detect B1603.

Also, B1602 coincides with B1603 at all times.

All 13 units which consists of the Body Electrical Control System are linked by CAN *1 line.

They are IPM (Inter Panel Module), FAM (Front Area Module), PDM (Power Distribution Module), DDM (Drive Door Module), ADM (Assist Door Module), ECW (Electronic Control Wiper), CLU (Cluster), MFSW (Multi Function Switch), PSM (Power Seat Module), SCM (Steering Control Module), PTM (Power Trunk Lid Module), FBWS (Front Back Warning System), DATC (Dual Auto Temperature Control Module).

*1 CAN (Controller Area Network) : CAN is serial bus communication type which links not only communication system but also control units each other.

*2 LIN (Local Interconnect Network) : LIN is serial communication type which is used in electrical control system. (This is less expensive.)

Scheme 80

This code reports the malfunction of NEC MCU inside PDM. This is the case which there is the NEC MCU communication error.

Refer to DTC B1987 : SUB MICOM FAILED .

This code is outputted when power circuit is shorted to battery.

(During no power supply from PDM to ESCL)

Refer to DTC B1987 : SUB MICOM FAILED .

This code is outputted when ground circuit is shorted to battery.

(During no power supply from PDM to ESCL)

Refer to DTC B1987 : SUB MICOM FAILED .

This code is outputted when power circuit is shorted to ground.

(During no power supply from PDM to ESCL)

Refer to DTC B1987 : SUB MICOM FAILED .

This code is outputted when the immobilizer data circuit is shorted to ground.

(In this case, it is not possible to get authorization although the fob is in the holder.)
