BCM (Body Control Module): Specifications Hyundai Genesis I

Communication Devices 2 illustrations

Specifications

ItemsSpecifications
Rated voltageDC 12V
Operating voltageDC 9 ~ 16V
Operating temperature30°C ~ 75°C (-4°F ~ 158°F)
FAM operating temperature40°C ~ 105°C (-40°F ~ 221°F)
Insulation resistanceIPM : 3mA
DDM:2mA
ADM:2mA
SCM:2mA
IMS:2mA
PDM:1mA
FAM:1mA

SPECIFICATIONS CHART

Scheme 1

Scheme 1: Components
Scheme 1: Components

Scheme 2

Scheme 2: Schematic Diagrams
Scheme 2: Schematic Diagrams

IPM : Instrument Panel Module

FAM : Front Area Module

DDM : Driver Door Module

ADM : Assist Door Module

SCM : Steering Control Module

SMK: Smart Key

PDM : Power Distribution Module

CLU : Cluster

MFSW: Multi Function Switch

PSM : Power Seat Module

FBWS : Front Back Warning System

PTM : Power Trunk Module

ECW: Electronic Control Wiper

ESCL : Electronic Steering Column Lock
