Engine Control System: Specifications Hyundai Elantra V

Testing & Diagnostics 36 illustrations ~179 words

Specification

Throttle angle (°)Output voltage (V) [Vref = 5.0V]
TPS1TPS2
00.54.5
100.964.05
201.413.59
301.873.14
402.322.68
502.782.23
603.231.77
703.691.32
804.140.86
904.60.41
984.650.35
C.T (0)0.54.5
W.O.T (86)4.410.59

THROTTLE VALUE SPECIFICATION

Scheme 1

Scheme 1
Scheme 1
Pressure [kPa (kgf/cm 2 , psi)]Output Voltage (V)
20.0 (0.20, 2.9)0.79
46.7 (0.47, 6.77)1.84
101.3 (1.03, 14.7)4.0

OUTPUT VOLTAGE SPECIFICATION

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3: (M/T)
Scheme 3: (M/T)

Scheme 4

Scheme 4: (A/T)
Scheme 4: (A/T)
Temperature [°C (°F)]Resistance (kohms)
40 (-40)40.93 ~ 48.35
20 (-4)13.89 ~ 16.03
0 (32)5.38 ~ 6.09
10 (50)3.48 ~ 3.90
20 (68)2.31 ~ 2.57
40 (104)1.08 ~ 1.21
50 (122)0.76 ~ 0.85
60 (140)0.54 ~ 0.62
80 (176)0.29 ~ 0.34

RESISTANCE SPECIFICATION

Scheme 5

Scheme 5: (M/T)
Scheme 5: (M/T)

Scheme 6

Scheme 6: (A/T)
Scheme 6: (A/T)
TemperatureResistance (kohms)
°C°F
404048.14
20414.13 ~ 16.83
0325.79
20682.31 ~ 2.59
401041.15
601400.59
801760.32

RESISTANCE SPECIFICATION

Scheme 7

Scheme 7: (M/T)
Scheme 7: (M/T)

Scheme 8

Scheme 8: (A/T)
Scheme 8: (A/T)
ItemSpecification
Coil Resistance (ohms)774 ~ 946 [20°C (68°F)]

ITEM SPECIFICATION

Scheme 9

Scheme 9: Waveform
Scheme 9: Waveform

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11: (M/T)
Scheme 11: (M/T)

Scheme 12

Scheme 12: (A/T)
Scheme 12: (A/T)
ItemSpecification
Capacitance (pF)850 ~ 1, 150

ITEM SPECIFICATION

Scheme 13

Scheme 13: (M/T)
Scheme 13: (M/T)

Scheme 14

Scheme 14: (A/T)
Scheme 14: (A/T)

Scheme 15

Scheme 15: Removal
Scheme 15: Removal

Scheme 16

Scheme 16
Scheme 16
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Disconnect the knock sensor connector (A).
  3. Remove the intake manifold (Refer to " «INTAKE AND EXHAUST SYSTEM»(/hyundai/elantra/v-2010-2014/remont/exhaust/#intake-exhaust-system) " in EM group).
  4. Remove the installation bolt (A), and then remove the sensor from the cylinder block.
ItemSpecification
Heater Resistance (ohms)2.4 ~ 4.0 [20°C (68°F)]

HO2S [BANK 1/SENSOR 1] (LINEAR TYPE)

A/F Ratio (lambda)Output Voltage (V)
RICH0.6 ~ 1.0
LEAN0 ~ 0.4

HO2S [BANK 1/SENSOR 2] (BINARY TYPE)

ItemSpecification
Heater Resistance (ohms)Approx. 9.0 [20°C (68°F)]

ITEM SPECIFICATION

Scheme 17

Scheme 17: (M/T)
Scheme 17: (M/T)

Scheme 18

Scheme 18: (A/T)
Scheme 18: (A/T)
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T0.7 ~ 0.80.29 ~ 0.46
W.O.T3.85 ~ 4.351.93 ~ 2.18

OUTPUT VOLTAGE SPECIFICATION

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20: (M/T)
Scheme 20: (M/T)

Scheme 21

Scheme 21: (A/T)
Scheme 21: (A/T)
Pressure [kPa (kgf/cm 2 , in H2O)Output Voltage (V)
6.67 (-0.068, -26.8)0.5
02.5
+6.67 (0.068, 26.8)4.5

OUTPUT VOLTAGE SPECIFICATION

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23: (M/T)
Scheme 23: (M/T)

Scheme 24

Scheme 24: (A/T)
Scheme 24: (A/T)
ItemSpecification
Coil Resistance (ohms)13.8 ~ 15.2 [20°C (68°F)]

ITEM SPECIFICATION

Scheme 25

Scheme 25: (M/T)
Scheme 25: (M/T)

Scheme 26

Scheme 26: (A/T)
Scheme 26: (A/T)
ItemSpecification
Coil Resistance (ohms)22.0 ~ 26.0 [20°C (68°F)]

ITEM SPECIFICATION

Scheme 27

Scheme 27: (M/T)
Scheme 27: (M/T)

Scheme 28

Scheme 28: (A/T)
Scheme 28: (A/T)
ItemSpecification
Coil Resistance (ohms)6.9 ~ 7.9 [20°C (68°F)]

ITEM SPECIFICATION

Scheme 29

Scheme 29: (M/T)
Scheme 29: (M/T)

Scheme 30

Scheme 30: (A/T)
Scheme 30: (A/T)
ItemSpecification
Coil resistance (ohms)30.0 ~ 35.0 [20°C (68°F)]

ITEM SPECIFICATION

Scheme 31

Scheme 31: (M/T)
Scheme 31: (M/T)

Scheme 32

Scheme 32: (A/T)
Scheme 32: (A/T)
ItemSpecification
Coil Resistance (ohms)19.9 ~ 22.9 [20°C (68°F)

ITEM SPECIFICATION

Scheme 33

Scheme 33: (M/T)
Scheme 33: (M/T)

Scheme 34

Scheme 34: (A/T)
Scheme 34: (A/T)
ItemSpecification
Coil Resistance (ohms)3.4 ~ 4.4 [20°C (68°F)]

MOTOR SPECIFICATIONS

ItemSpecification
Coil Resistance (kohms)3.44 ~ 5.16 [20°C (68°F)]

POSITION SENSOR

Scheme 35

Scheme 35: (M/T)
Scheme 35: (M/T)

Scheme 36

Scheme 36: (A/T)
Scheme 36: (A/T)
