Automatic Transaxle Diagnosis: Specifications Hyundai Elantra III facelift

Automatic Trans 66 illustrations ~1515 words

Specification

TEMP.(°C)RESISTANCE (kohms)TEMP.(°C)RESISTANCE (kohms)
40(-40°F)139.580 (176°F)1.08
20(-4°F)47.7100 (212°F)0.63
0 (32°F)18.6120 (248°F)0.38
20 (68°F)8.1140 (284°F)0.25
40 (104°F)3.8160 (320°F)0.16
60 (140°F)1.98

TEMPERATURE AND RESISTANCE SPECIFICATION CHART

Scheme 119

Scheme 119: Schematic Diagram

Scheme 120

Scheme 120: Monitor Scantool Data

Scheme 121

Scheme 121

Scheme 122

Scheme 122
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "TRANSAXLE FLUID TEMPERATURE SENSOR" parameter on the scantool Specification : Increasing Gradually
  4. Does "TRANSAXLE FLUID TEMPERATURE SENSOR" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Throughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-381766-S36670084372010123100000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-381766-S20300869642010123100000) " procedure
TEMP.(°C)RESISTANCE (kohms)TEMP.(°C)RESISTANCE (kohms)
40(-40°F)139.580 (176°F)1.08
20(-4°F)47.7100 (212°F)0.63
0 (32°F)18.6120 (248°F)0.38
20 (68°F)8.1140 (284°F)0.25
40 (104°F)3.8160 (320°F)0.16
60 (140°F)1.98

TEMPERATURE AND RESISTANCE SPECIFICATION CHART

Scheme 123

Scheme 123: Schematic Diagram

Scheme 124

Scheme 124: Monitor Scantool Data

Scheme 125

Scheme 125

Scheme 126

Scheme 126
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "TRANSAXLE FLUID TEMPERATURE SENSOR" parameter on the scantool Specification : Increasing Gradually
  4. Does "TRANSAXLE FLUID TEMPERATURE SENSOR" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Throughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-381766-S32272237182010123100000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-381766-S17605653952010123100000) " procedure
TEMP.(°C)RESISTANCE (kohms)TEMP.(°C)RESISTANCE (kohms)
40(-40°F)139.580 (176°F)1.08
20(-4°F)47.7100 (212°F)0.63
0 (32°F)18.6120 (248°F)0.38
20 (68°F)8.1140 (284°F)0.25
40 (104°F)3.8160 (320°F)0.16
60 (140°F)1.98

TEMPERATURE AND RESISTANCE SPECIFICATION CHART

Scheme 127

Scheme 127: Schematic Diagram

Scheme 128

Scheme 128: Monitor Scantool Data

Scheme 129

Scheme 129

Scheme 130

Scheme 130
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "TRANSAXLE FLUID TEMPERATURE SENSOR" parameter on the scantool Specification : Increasing Gradually
  4. Does "TRANSAXLE FLUID TEMPERATURE SENSOR" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Throughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-381766-S36700471482010123100000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-381766-S15983900502010123100000) " procedure

Input shaft & Output shaft speed sensor

  1. Type : Hall sensor
  2. Current consumption : 22mA (MAX)
  3. sensor body and sensor connector have been unified as one.

Scheme 131

Scheme 131: Schematic Diagram

Scheme 132

Scheme 132: Signal Waveform

Scheme 133

Scheme 133: Monitor Scantool Data

Scheme 134

Scheme 134

Scheme 135

Scheme 135

Scheme 136

Scheme 136
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "INPUT SPEED SENSOR" parameter on the scantool
  4. Driving at speed of over 30 km/h Specification : Increasing Gradually
  5. Does "Input Speed Sensor" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Throughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-381766-S00892171282010123100000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-381766-S22549283522010123100000) " procedure

Input shaft & Output shaft speed sensor

  1. Type : Hall sensor
  2. Current consumption : 22mA (MAX)
  3. sensor body and sensor connector have been unified as one.

Scheme 137

Scheme 137: Schematic Diagram

Scheme 138

Scheme 138: Signal Waveform

Scheme 139

Scheme 139

Scheme 140

Scheme 140: Monitor Scantool Data

Scheme 141

Scheme 141

Scheme 142

Scheme 142
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "OUTPUT SPEED SENSOR" parameter on the scantool
  4. Driving at speed of over 30 km/h Specification : Increasing Gradually
  5. Does "output speed sensor" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Throughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-381766-S37536268972010123100000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-381766-S41065805252010123100000) " procedure

Solenoid Valve for Pressure Control

  1. Sensor type : Normal open 3-way
  2. Operating temperature : -30°C~130°C
  3. Frequency :PCSV-A, B, C, D :50Hz (at the ATF temp. -20°C above)

VFS : 400~1000

* KM series : 35Hz

  1. Internal resistance : 3.5 ± 0.2 ohms(20°C)
  2. Surge voltage : 56 V

Scheme 143

Scheme 143: Signal Waveform

Scheme 144

Scheme 144: Monitor Scantool Data

Scheme 145

Scheme 145

Scheme 146

Scheme 146

Scheme 147

Scheme 147
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "TCC SOL. VALVE" parameter on the scantool
  4. Select "D RANGE" and Operate "TCC SOLENOID DUTY" more than 35%
  5. Does "TCC SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or PCM/TCM's connector or was repaired and PCM/TCM memory was not cleared. Throughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-381766-S05727001742010123100000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-381766-S08960535982010123100000) " procedure

Solenoid Valve for Pressure Control

  1. Sensor type : Normal open 3-way
  2. Operating temperature : -30°C~130°C
  3. Frequency :PCSV-A, B, C, D :50Hz (at the ATF temp. -20°C above)

VFS : 400~1000

* KM series : 35Hz

  1. Internal resistance : 3.5 ± 0.2 ohms(20°C)
  2. Surge voltage : 56 V

Scheme 148

Scheme 148: Signal Waveform

Scheme 149

Scheme 149: Monitor Scantool Data

Scheme 150

Scheme 150

Scheme 151

Scheme 151

Scheme 152

Scheme 152

Scheme 153

Scheme 153

Scheme 154

Scheme 154
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "VF SOL. VALVE" parameter on the scantool
  4. Shift gear at each position.
  5. Does "VF SOL DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or PCM/TCM's connector or was repaired and PCM/TCM memory was not cleared. Throughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-381766-S01677395412010123100000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-381766-S34479324712010123100000) " procedure

Solenoid Valve for Pressure Control

  1. Sensor type : Normal open 3-way
  2. Operating temperature : -30°C~130°C
  3. Frequency :PCSV-A, B, C, D :50Hz (at the ATF temp. -20°C above)

VFS : 400~1000

* KM series : 35Hz

  1. Internal resistance : 3.5 ± 0.2 ohms(20°C)
  2. Surge voltage : 56 V

Scheme 155

Scheme 155: Signal Waveform

Scheme 156

Scheme 156: Monitor Scantool Data

Scheme 157

Scheme 157

Scheme 158

Scheme 158

Scheme 159

Scheme 159

Scheme 160

Scheme 160

Scheme 161

Scheme 161

Scheme 162

Scheme 162
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "VF SOL. VALVE" parameter on the scantool
  4. Shift gear at each position.
  5. Does "ON/OFF SOL VALVE" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or PCM/TCM's connector or was repaired and PCM/TCM memory was not cleared. Throughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-381766-S34877352832010123100000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-381766-S37481240032010123100000) " procedure

Solenoid Valve for Pressure Control

  1. Sensor type : Normal open 3-way
  2. Operating temperature : -30°C~130°C
  3. Frequency :PCSV-A, B, C, D :50Hz (at the ATF temp. -20°C above)

VFS : 400~1000

* KM series : 35Hz

  1. Internal resistance : 3.5 ± 0.2 ohms(20°C)
  2. Surge voltage : 56 V

Scheme 163

Scheme 163: Signal Waveform

Scheme 164

Scheme 164

Scheme 165

Scheme 165: Monitor Scantool Data

Scheme 166

Scheme 166

Scheme 167

Scheme 167

Scheme 168

Scheme 168

Scheme 169

Scheme 169

Scheme 170

Scheme 170
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "PCSV-A (OD & LR) SOLENOID VALVE" parameter on the scantool
  4. Shift gear at each position.
  5. Does "PCSV-A (OD & LR) SOLENOID VALVE" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or PCM/TCM's connector or was repaired and PCM/TCM memory was not cleared. Throughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-381766-S34016442792010123100000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-381766-S32760652812010123100000) " procedure

Solenoid Valve for Pressure Control

  1. Sensor type : Normal open 3-way
  2. Operating temperature : -30°C~130°C
  3. Frequency :PCSV-A, B, C, D :50Hz (at the ATF temp. -20°C above)

VFS : 400~1000

* KM series : 35Hz

  1. Internal resistance : 3.5 ± 0.2 ohms(20°C)
  2. Surge voltage : 56 V

Scheme 171

Scheme 171: Signal Waveform

Scheme 172

Scheme 172: Monitor Scantool Data

Scheme 173

Scheme 173

Scheme 174

Scheme 174

Scheme 175

Scheme 175

Scheme 176

Scheme 176

Scheme 177

Scheme 177
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "PCSV-B (2-4SOLENOID VALVE)" parameter on the scantool
  4. Shift gear at each position.
  5. Does "PCSV-B (2-4SOLENOID VALVE)" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or PCM/TCM's connector or was repaired and PCM/TCM memory was not cleared. Throughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-381766-S15509413982010123100000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-381766-S22562485402010123100000) " procedure

Solenoid Valve for Pressure Control

  1. Sensor type : Normal open 3-way
  2. Operating temperature : -30°C~130°C
  3. Frequency :PCSV-A, B, C, D :50Hz (at the ATF temp. -20°C above)

VFS : 400~1000

* KM series : 35Hz

  1. Internal resistance : 3.5 ± 0.2 ohms(20°C)
  2. Surge voltage : 56 V

Scheme 178

Scheme 178: Signal Waveform

Scheme 179

Scheme 179: Monitor Scantool Data

Scheme 180

Scheme 180

Scheme 181

Scheme 181

Scheme 182

Scheme 182

Scheme 183

Scheme 183

Scheme 184

Scheme 184
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "PCSV-C (UD) SOLENOID VALVE" parameter on the scantool
  4. Shift gear at each position.
  5. Does "PCSV-C (UD) SOLENOID VALVE" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or PCM/TCM's connector or was repaired and PCM/TCM memory was not cleared. Throughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-381766-S31281506962010123100000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-381766-S02623228182010123100000) " procedure
