Automatic Transaxle Control System: Adjustments Hyundai Elantra III facelift

Automatic Trans 1 illustration ~108 words

Adjustment

Adjusting method for the control cable

Scheme 118

Scheme 118: Adjustment
Scheme 118: Adjustment
  1. Set room side lever and T/M side lever (A) to "N" position.
  2. Connect the room side lever and shift cable. (refer to ' «INSTALLATION»(ref-381709-S08851844532010123100000) ')
  3. Connect the T/M side lever (A) to cable (B) in this following order; Push the cable (B) lightly to "F" direction shown in illustration to eliminate FREE PLAY of the cable (B). Tighten the adjusting nut (C).
  4. After adjusting the cable (B) according to procedure no. 2-3, check to be sure that this part operates surely at each range of T/M side corresponding to each position of room lever.
