STARTER SPECIFICATIONS
| Application | Specification | |
|---|---|---|
| Amperage | 60 Amps | |
| Armature Maximum Runout | 0.004" (0.10 mm) | |
| Brush Length | (1) | |
| Commutator Outside Diameter | 1.118-1.157" (28.4-29.4 mm) | |
| Insulator Depth | 0.008-0.020" (0.2-0.5 mm) | |
| Maximum Speed | 5500 RPM | |
| No-Load Ratings | ||
| Maximum Draw | 90 Amps | |
| Minimum RPM | 2800 | |
| Number Of Pinion Teeth | 8 | |
| Pinion Gap | 0.020-0.079" (0.5-2.0 mm) | |
| Rated Output | 12 Volts (0.9 kW) | |
| Rated Time | 30 Seconds | |
| Terminal Voltage | 11.5 Volts | |
| Type | Direct Drive | |
| (1) Bottom of limit line that is stamped into brush. (Scheme 1) | ||
| (1) | Bottom of limit line that is stamped into brush. (Scheme 1) |
STARTER SPECIFICATIONS
Scheme 1
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Battery Cable Terminal Nut | 9-12 (10-16) |
| Starter Mounting Bolts | 32-41 (43-55) |
| INCH Lbs. (N.m) | |
| Transaxle Range Switch | 88-106 (10-12) |
TORQUE SPECIFICATIONS
