Starters: Diagnosis Hyundai Accent II рестайлинг

Starter 2 illustrations ~327 words

STARTER RELAY TEST

Note. For circuit identification, see WIRING DIAGRAMS .

  1. Check continuity between relay terminals No. 3 and 5, and between terminals No. 1 and 2. Continuity should exist between terminals No. 3 and 5. Continuity should not exist between terminals No. 1 and 2. If continuity is as specified, go to next step. If continuity is not as specified, replace starter relay.
  2. Apply battery voltage and ground between terminals No. 3 and 5. Continuity should now exist between terminals No. 1 and 2. If continuity is not as specified, replace starter relay. If continuity is as specified, starter relay is okay at this time.

CLUTCH PEDAL SWITCH TEST (M/T)

Disconnect clutch pedal switch connector, located on pedal assembly bracket. Using ohmmeter, check continuity between switch terminals. Continuity should exist with switch depressed. Continuity should not exist with switch released. If continuity is not as specified, replace clutch pedal switch.

NO-LOAD TEST

  1. Place the starter motor in a vise equipped with soft jaws and connect a fully charged 12 volt battery to starter motor as follows: Connect a test ammeter (100 amp scale) and carbon pile rheostat as shown is the illustration. Connect a voltmeter (15 volt scale) across starter motor. Rotate carbon pile to the off position. Connect the battery cable from battery's negative post to the starter motor body. (Scheme 5)
  2. Adjust until battery voltage shown on the voltmeter reads 11 volts.
  3. Confirm that the maximum amperage is within the specifications and that the starter motor turns smoothly and freely. For specifications, see «STARTER SPECIFICATIONS»(ref-168305-S21087773842004110400000).

Scheme 5

Scheme 5
Scheme 5

Return Test

Disconnect field coil wire from starter solenoid terminal "M". Apply battery voltage to starter solenoid terminal "M" and ground starter case. (Scheme 6) Manually pull out pinion drive and then release it. Pinion drive should return quickly to original position. If pinion drive does not return to original position, replace solenoid. See OVERHAUL.

Scheme 6

Scheme 6: Return Test
Scheme 6: Return Test

FIELD COIL TEST

Information not available from manufacturer.
