BRUSH ASSEMBLY
- Ensure brushes slide freely in brush holder. If brushes do not slide freely, check for dirt or contamination. Clean brushes and recheck operation. Replace brushes if brushes still do not slide freely. See «OVERHAUL»(ref-168305-S13851095262004110400000).
- To check brush holder for a short to ground, check continuity between insulated brush holder and grounded brush holder. (Scheme 9) No continuity should exist. Replace brush holder if continuity exists. See «OVERHAUL»(ref-168305-S13851095262004110400000).
- Inspect brushes for cracks. Using caliper, measure brush length. For specification, see «STARTER SPECIFICATIONS»(ref-168305-S21087773842004110400000). Replace brushes if length is not within specification. See «OVERHAUL»(ref-168305-S13851095262004110400000).
Scheme 9
OVERHAUL
| CAUTION | DO NOT immerse starter components in cleaning solvent. Immersing yoke and field coil assembly and/or armature will damage insulation. Wipe these components with a cloth only. DO NOT immerse drive unit in cleaning solvent. Overrunning clutch is factory lubricated and solvent will wash lubrication from clutch. Drive unit may be cleaned with a brush moistened with cleaning solvent and wiped dry using a cloth. |
STARTER ASSEMBLY
Note. Use illustration for exploded view of starter. (Scheme 10)
