DTC P0113: IAT Sensor Circuit High Voltage Honda S2000 AP1

Testing & Diagnostics 5 illustrations ~356 words

Note. Before you troubleshoot, record all freeze data and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 28

Scheme 28: DTC P0113: IAT Sensor Circuit High Voltage

Scheme 28: DTC P0113: IAT Sensor Circuit High Voltage

Scheme 29

Scheme 29

Scheme 29

Scheme 30

Scheme 30

Scheme 30

Scheme 31

Scheme 31

Scheme 31

Scheme 32

Scheme 32

Scheme 32

Turn the ignition switch ON (II).
Check the IAT with a scan tool or the HDS. Is about -4 °F (-20 °C) or less, or 5 V indicated? YES - Go to step 3. NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the IAT sensor and the ECM.
Turn the ignition switch OFF.
Disconnect the IAT sensor 2P connector.
Connect IAT sensor 2P connector terminals No. 1 and No. 2 with a jumper wire.
Turn the ignition switch ON (II).
Check the IAT with a scan tool or the HDS. Is about -4 °F (-20 °C) or less, or 5 V indicated? YES - Go to step 8. NO - Replace the IAT sensor (see «SPECIAL TOOLS»(ref-221324-S23506078702006022400000) ).
Turn the ignition switch OFF.
Remove the jumper wire.
Turn the ignition switch ON (II).
Measure voltage between IAT sensor 2P connector terminal No. 2 and body ground. Is there about 5 V? YES - Go to step 13 . NO - Go to step 12.
Measure voltage between ECM connector terminal C25 and body ground. Is there about 5 V? YES - Repair open in the wire between the ECM (C25) and the IAT sensor. NO - Substitute a known-good ECM (see «HOW TO SUBSTITUTE THE ECM FOR TESTING PURPOSES»(ref-221328-S04997151962006022400000) ) and recheck. If normal IAT is indicated, replace the original ECM (see «ECM REPLACEMENT»(ref-221329-S30667517252006022400000) ).
Turn the ignition switch OFF.
Disconnect ECM connector C (31P).
Connect IAT sensor 2P connector terminal No. 1 to body ground with a jumper wire.
Check for continuity between ECM connector terminal C18 and body ground. Is there continuity? YES - Substitute a known-good ECM (see «HOW TO SUBSTITUTE THE ECM FOR TESTING PURPOSES»(ref-221328-S04997151962006022400000) ) and recheck. If normal IAT is indicated, replace the original ECM (see «ECM REPLACEMENT»(ref-221329-S30667517252006022400000) ). NO - Repair open in the wire between the ECM (C18) and the IAT sensor.
