Intake Air System: Removal & Installation Honda S2000 AP1

Throttle Body Removal/Installation

Note. Do not adjust the throttle stop screw. After reassembly, adjust the cruise control actuator cable (see CRUISE CONTROL ACTUATOR CABLE REPLACEMENT ), and the throttle cable (see THROTTLE CABLE ADJUSTMENT ). The TP sensor is not removable.

Scheme 174

Scheme 175

Scheme 176

Scheme 177

Scheme 178

Scheme 179

1. Fully open the throttle valve, then remove the throttle cable (A) from the throttle link (B).
2. Remove the cable housing (C) from the cable bracket (D).
3. Remove the nuts (A), then remove the accelerator pedal (B) along with the throttle cable (C) and the actuator cable (D).
4. Pull the throttle cable (C) and the actuator cable (D) out toward the passenger compartment.
5. Remove the throttle cable (A) and the actuator cable (B) from the accelerator pedal bracket (C).
6. Install in the reverse order of removal.
7. After installing, start the engine. Hold the engine speed at 3,000 rpm without load (in neutral) until the radiator fan comes on, then let it idle.
8. Hold the cable sheath, removing all slack from the cable.
9. Turn the adjusting nut (A) until it is 3 mm (1/8 in.) away from the cable bracket (B).
10. Tighten the locknut (C). The cable free play should now be 4-6 mm (3/16-1/4 in.). If free play is not within specs, loosen the locknut, turn the adjusting nut until the free play is as specified, then retighten the locknut.
11. With the cable properly adjusted, check the throttle valve to be sure it opens fully when you push the accelerator pedal to the floor. Also check the throttle valve to be sure it returns to the idle position whenever you release the accelerator pedal.

Scheme 180

1. Check cable free play at the throttle linkage. Cable free play (A) should be 4-6 mm (3/16-1/4 in.).
2. If free play (A) is not within spec (4-6 mm, 3/16-1/4 in.) loosen the locknut (B), turn the adjusting nut (C) until the free play is as specified, then retighten the locknut.
3. With the cable properly adjusted, check the throttle valve to be sure it opens fully when you push the accelerator pedal to the floor. Also check the throttle valve to be sure it returns to the idle position whenever you release the accelerator pedal.

Scheme 181

1. Remove the air cleaner housing cover (A).
2. Remove the air cleaner element (B) from the air cleaner housing (C).
3. Check the air cleaner element for damage or clogging. If there is damage or clogging, replace the air cleaner element. NOTE: Do not clean the air cleaner element by blowing if off with compressed air.
4. Clean and remove any debris from inside the air cleaner housing.
5. Install the parts in the reverse order of removal.
