DTC P0325: Knock Sensor Circuit Malfunction Honda Pilot I

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 169

Scheme 170

Scheme 171

Scheme 172

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Start the engine. Hold the engine speed at 3,000 RPM without load (in Park or neutral) until the radiator fan comes on, then let it idle.
4. Hold the engine speed at 3,000-4,000 RPM for at least 10 seconds.
5. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0325 indicated? YES -Go to step 6. NO -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the knock sensor and the PCM.
6. Turn the ignition switch OFF.
7. Jump the SCS line with the HDS.
8. Disconnect the knock sensor subharness 1P connector.
9. Disconnect PCM connector C (44P).
10. Check for continuity between PCM connector terminal C42 and body ground. Is there continuity? YES -Repair short in the wire between the PCM (C42) and the knock sensor subharness, then go to step 19 . NO -Go to step 11.
11. Connect the knock sensor subharness 1P connector terminal to body ground with a jumper wire.
12. Check for continuity between PCM connector terminal C42 and body ground. Is there continuity? YES -Go to step 13. NO -Repair open in the wire between the PCM (C42) and the knock sensor subharness, then go to step 19 .
13. Remove the intake manifold (see «INTAKE MANIFOLD REMOVAL AND INSTALLATION»(ref-243299-S14780088452006082300000) ) and injector base.
14. Disconnect the knock sensor 1P connector.
15. Check for continuity between the knock sensor subharness 1P connector terminal and body ground. Is there continuity? YES -Repair short in the knock sensor subharness, then go to step 18 . NO -Go to step 16.
16. Check for an open in the knock sensor subharness. Is the harness OK? YES -Go to step 17. NO -Repair open in the knock sensor subharness, then go to step 19 .
17. Replace the knock sensor (see «KNOCK SENSOR REPLACEMENT»(ref-298125-S18091111302008091500000) ).
18. Install the intake manifold (see «INTAKE MANIFOLD REMOVAL AND INSTALLATION»(ref-243299-S14780088452006082300000) ) and injector base.
19. Reconnect all connectors.
20. Turn the ignition switch ON (II).
21. Reset the PCM with the HDS.
22. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-243313-S13405059332006082300000) ).
23. Hold the engine speed at 3,000-4,000 RPM for at least 10 seconds.
24. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0325 indicated? YES -Check for poor connections or loose terminals at the knock sensor and the PCM, then go to step 26 . NO -Go to step 25.
25. Monitor the OBD STATUS for DTC P0325 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES -Troubleshooting is complete. If any other Temporary DTCs or DTCs were indicated in step 24 , go to the indicated DTC's troubleshooting. NO -If the screen indicates FAILED, check for poor connections or loose terminals at the knock sensor and the PCM, then go to step 1 . If the screen indicates NOT COMPLETED, go to step 23 .
26. Update the PCM if it does not have the latest software (see «UPDATING THE PCM»(ref-243311-S19790429062006082300000) ), or substitute a known-good PCM (see «HOW TO SUBSTITUTE THE PCM»(ref-243311-S24543735662006082300000) ).
27. Start the engine. Hold the engine speed at 3,000 RPM without load (in Park or neutral) until the radiator fan comes on, then let it idle.
28. Hold the engine speed at 3,000-4,000 RPM for at least 10 seconds.
29. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0325 indicated? YES -Check for poor connections or loose terminals at the knock sensor and the PCM. If the PCM was updated, substitute a known-good PCM (see «HOW TO SUBSTITUTE THE PCM»(ref-243311-S24543735662006082300000) ), then go to step 27 . If the PCM was substituted, go to step 1 . NO -Go to step 30.
30. Monitor the OBD STATUS for DTC P0325 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES -If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(ref-298125-S08727755362008091500000) ). If any other Temporary DTCs or DTCs were indicated in step 29 , go to the indicated DTC's troubleshooting. NO -If the screen indicates FAILED, check for poor connections or loose terminals at the knock sensor and the PCM. If the PCM was updated, substitute a known-good PCM (see «HOW TO SUBSTITUTE THE PCM»(ref-243311-S24543735662006082300000) ), then go to step 27 . If the PCM was substituted, go to step 1 . If the screen indicates NOT COMPLETED, go to step 27 .
