DTC P0108: MAP Sensor Circuit High Voltage Honda Pilot I

Testing & Diagnostics 4 illustrations ~548 words

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 117

Scheme 117: DTC P0108: MAP Sensor Circuit High Voltage
Scheme 117: DTC P0108: MAP Sensor Circuit High Voltage

Scheme 118

Scheme 118
Scheme 118

Scheme 119

Scheme 119
Scheme 119

Scheme 120

Scheme 120
Scheme 120
  1. Turn the ignition switch ON (II).
  2. Check the MAP SENSOR in the DATA LIST with the HDS. Is about 160 kPa (47.1 in.Hg, 1,197 mmHg), or 4.49 V or more indicated? YES -Go to step 3. NO -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the MAP sensor and the PCM.
  3. Turn the ignition switch OFF.
  4. Disconnect the MAP sensor 3P connector.
  5. Connect MAP sensor 3P connector terminals No. 2 and No. 3 with a jumper wire.
  6. Turn the ignition switch ON (II).
  7. Check the MAP SENSOR in the DATA LIST with the HDS. Is about 160 kPa (47.1 in.Hg, 1,197 mmHg), or 4.49 V or more indicated? YES -Go to step 8. NO -Go to step 18 .
  8. Remove the jumper wire from the MAP sensor 3P connector.
  9. Measure voltage between MAP sensor 3P connector terminals No. 1 and No. 3. Is there about 5 V? YES -Go to step 14 . NO -Go to step 10.
  10. Turn the ignition switch OFF.
  11. Jump the SCS line with the HDS.
  12. Disconnect PCM connector B (44P).
  13. Check for continuity between PCM connector terminal B33 and MAP sensor 3P connector terminal No. 3. Is there continuity? YES -Go to step 25 . NO -Repair open in the wire between the PCM (B33) and the MAP sensor, then go to step 20 .
  14. Turn the ignition switch OFF.
  15. Jump the SCS line with the HDS.
  16. Disconnect PCM connector B (44P).
  17. Check for continuity between PCM connector terminal B30 and MAP sensor 3P connector terminal No. 2. Is there continuity? YES -Go to step 25 . NO -Repair open in the wire between the PCM (B30) and the MAP sensor, then go to step 20 .
  18. Turn the ignition switch OFF.
  19. Replace the MAP sensor (see «MAP SENSOR REPLACEMENT»(ref-298125-S21402634012008091500000) ).
  20. Reconnect all connectors.
  21. Turn the ignition switch ON (II).
  22. Reset the PCM with the HDS.
  23. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-243313-S13405059332006082300000) ).
  24. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0108 indicated? YES -Check for poor connections or loose terminals at the MAP sensor and the PCM, then go to step 1 . NO -Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting.
  25. Reconnect all connectors.
  26. Update the PCM if it does not have the latest software (see «UPDATING THE PCM»(ref-243311-S19790429062006082300000) ), or substitute a known-good PCM (see «HOW TO SUBSTITUTE THE PCM»(ref-243311-S24543735662006082300000) ).
  27. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0108 indicated? YES -Check for poor connections or loose terminals at the MAP sensor and the PCM. If the PCM was updated, substitute a known-good PCM (see «HOW TO SUBSTITUTE THE PCM»(ref-243311-S24543735662006082300000) ), then recheck. If the PCM was substituted, go to step 1 . NO - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(ref-298125-S08727755362008091500000) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting.
