Pgm-Fi System: Removal & Installation Honda Odyssey IV

A/F Sensor Replacement

Special Tools Required

O2 sensor socket wrench, Snap-on YA8875 or SWR2, or equivalent, commercially available

Scheme 205

1. Disconnect the front A/F sensor 6P connector (A), then remove the A/F sensor (B).
2. Install the parts in the reverse order of removal.

Scheme 206

1. Disconnect the rear A/F sensor 6P connector (A), then remove the rear A/F sensor (B).
2. Install the parts in the reverse order of removal.

Secondary HO2S Replacement

Special Tools Required

O2 sensor socket wrench. Snap-on YA8875 or SWR2, or equivalent, commercially available

Scheme 207

1. Disconnect the front secondary HO2S 4P connector (A), then remove the front secondary HO2S (B).
2. Install the parts in the reverse order of removal.

Scheme 208

1. Disconnect the rear secondary HO2S 4P connector (A), then remove the rear secondary HO2S (B).
2. Install the parts in the reverse order of removal.

Scheme 209

1. Move the auto-tensioner to remove tension from the drive belt, then remove the belt (See «DRIVE BELT AUTO-TENSIONER INSPECTION»(ref-294692-S24169726362008081300000) ).
2. Remove the crankshaft pulley; J35A6 engine (See «CRANKSHAFT PULLEY REMOVAL AND INSTALLATION»(ref-294693-S15567099932008081300000) ), J35A7 engine (See «CRANKSHAFT PULLEY REMOVAL AND INSTALLATION»(ref-294693-S24383497212008081300000) ).
3. Remove the upper and lower front covers from the engine; J35A6 engine (see step 9 «TIMING BELT INSTALLATION»(ref-294693-S04916246352008081300000) ), J35A7 engine (see step 9 «TIMING BELT INSTALLATION»(ref-294693-S37977508872008081300000) ).
4. Remove the CKP sensor (A) from the oil pump.
5. Install the parts in the reverse order of removal.
6. Do the CKP pattern clear/CKP pattern learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-372404-S40962752732010092500000) ).

Scheme 210

1. Lift the vehicle, and support it with jackstands. NOTE: Make sure the vehicle is level, because engine oil will drip out when you remove the sensor.
2. Remove the CKP sensor cover (A).
3. Disconnect the CKP sensor connector (B).
4. Remove the CKP sensor (C).
5. Install the parts in the reverse order of removal with a new O-ring (D).
6. Do the CKP pattern clear/CKP pattern learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-372404-S40962752732010092500000) ).
7. Check for engine oil level, and add more oil if needed.

Scheme 211

Scheme 212

1. Remove the timing belt; J35A6 engine (See «TIMING BELT REMOVAL»(ref-294693-S04808480932008081300000) ), J35A7 engine ('07 model) (See «TIMING BELT REMOVAL»(ref-294693-S38225917532008081300000) ), J35A7 engine ('08 model) (See «TIMING BELT REMOVAL»(ref-294693-S11925492842008081300000) ).
2. Remove the front camshaft pulley (CMP sensor pulse plate) (A).
3. Disconnect the CMP sensor 3P connector (B), then remove the back cover (C).
4. Remove the CMP sensor (A) from the back cover.
5. Install the parts in the reverse order of removal. Install the timing belt; J35A6 engine (See «TIMING BELT INSTALLATION»(ref-294693-S04916246352008081300000) ), J35A7 engine ('07 model) (See «TIMING BELT INSTALLATION»(ref-294693-S37977508872008081300000) ), J35A7 engine ('08 model) (See «TIMING BELT INSTALLATION»(ref-294693-S33549546832008081300000) ).
6. Do the CKP pattern clear/CKP pattern learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-372404-S40962752732010092500000) ).

Scheme 213

1. Remove the intake manifold (see «REMOVAL»(ref-294688-S26012406722008081300000) ).
2. Remove the injector rails and the injector base.
3. Disconnect the knock sensor 1P connector (A), then remove the knock sensor (B).
4. Install the parts in the reverse order of removal.

Scheme 214

1. Disconnect the MAF sensor 5P connector (A).
2. Remove the screws (B).
3. Remove the MAF sensor (C).
4. Install the parts in the reverse order of removal.

Scheme 215

1. Disconnect the MAF sensor/IAT sensor 5P connector (A).
2. Remove the screws (B).
3. Remove the MAF sensor/IAT sensor (C).
4. Install the parts in the reverse order of removal.

PCM Replacement

Special Tools Required

1. Honda diagnostic system (HDS) tablet tester
2. Honda interface module (HIM) and an iN workstation with the latest HDS software version
3. HDS pocket tester
4. GNA600 and an iN workstation with the latest HDS software version

Any one of the above updating tool can be used.

Note. Make sure the HDS is loaded with the latest software version. If you are replacing the PCM after substituting a known-good PCM, reinstall the original PCM, then do this procedure. During the procedure, if any READ DATA, WRITE DATA, or other data checks fail, note the failure, then continue.

Scheme 216

Scheme 217

1. Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard.
2. Turn the ignition switch to ON (II).
3. Make sure the HDS communicates with the PCM and other vehicle systems. If it doesn't, go to the «DLC CIRCUIT TROUBLESHOOTING»(ref-355276-S19683854952010012200000) . If you are returning from DLC circuit troubleshooting, skip steps 4 through 9 , 20 through 25 , and 28 through 30 , and do this after replacing the PCM: Replace the engine oil (See «ENGINE OIL REPLACEMENT»(ref-294681-S40314378162008081300000) ) and the engine oil filter (See «ENGINE OIL FILTER REPLACEMENT»(ref-294681-S20652754922008081300000) ). Replace the ATF (see «ATF REPLACEMENT»(ref-372405-S32147418802010092500000) ). Clean the throttle body (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-294690-S36483830972008081300000) ).
4. Select the PGM-FI system with the HDS.
5. Select the INSPECTION MENU with the HDS.
6. Select the ETCS TEST, then select the TP POSITION CHECK, and follow the screen prompts. NOTE: If the TP POSITION CHECK indicates FAILED, continue with this procedure.
7. Select the REPLACE PCM MENU, then select READ DATA and follow the screen prompts. NOTE: Doing this step copies (READS) the engine oil life data from the original PCM so you can later download (WRITE) it into the new PCM. If READ DATA indicates FAILED, continue with this procedure.
8. Select the A/T system with the HDS.
9. Select the REPLACE TCM/PCM MENU, then select READ DATA and follow the screen prompts. NOTE: Doing this step copies (READS) the ATF life data from the original PCM so you can later download (WRITE) it into the new PCM. If READ DATA indicates FAILED, continue with this procedure.
10. Turn the ignition switch to LOCK (0).
11. Jump the SCS line with the HDS.
12. Remove the power steering fluid reservoir from the body.
13. Remove the cover (D).
14. Disconnect PCM connectors A, B, and C. NOTE: PCM connectors A, B, and C have symbols (A=[], B= delta, C=o) embossed on them for identification.
15. Loosen or remove the bolts (E), then remove the PCM (F).
16. Install the parts in the reverse order of removal.
17. Open the SCS with the HDS.
18. Turn the ignition switch to ON (II).
19. Manually input the VIN to the PCM with the HDS. NOTE: DTC P0630 VIN Not Programmed or Mismatch may be stored because the VIN has not been programmed into the PCM; ignore it, and continue this procedure.
20. If the READ DATA (engine oil life) failed in step 7 , go to step 23 . Otherwise, go to step 21.
21. Select the PGM-FI system with the HDS.
22. Select the REPLACE PCM MENU, then select WRITE DATA and follow the screen prompts. NOTE: If the WRITE DATA indicates FAILED, continue with this procedure.
23. If the READ DATA (ATF life) failed in step 9 , go to step 26 . Otherwise go to step 24.
24. Select the A/T SYSTEM with the HDS.
25. Select the REPLACE TCM/PCM MENU, then select WRITE DATA and follow the screen prompts. NOTE: If the WRITE DATA indicates FAILED, continue with this procedure.
26. Select IMMOBI system with the HDS.
27. Enter the immobilizer code with the PCM replacement procedure in the HDS; it allows you to start the engine.
28. If the TP POSITION CHECK failed in step 6 clean the throttle body (see «AIR CLEANER REMOVAL/INSTALLATION»(ref-294690-S36483830972008081300000) ), then go to step 29.
29. If the READ DATA failed in step 7 or the WRITE DATA failed in step 22 , replace the engine oil (See «ENGINE OIL REPLACEMENT»(ref-294681-S40314378162008081300000) ) and the engine oil filter (See «ENGINE OIL FILTER REPLACEMENT»(ref-294681-S20652754922008081300000) ), then go to step 30.
30. If the READ DATA failed in step 9 or the WRITE DATA failed in step 25 , replace the ATF (see «ATF REPLACEMENT»(ref-372405-S32147418802010092500000) ), then go to step 31.
31. Select PGM-FI system, and reset the PCM with the HDS.
32. Update the PCM if it does not have the latest software (see «PCM UPDATE»(ref-355276-S11014552242010012200000) ).
33. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-294703-S06414002682008081300000) ).
34. Do the CKP pattern learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-372404-S40962752732010092500000) ).
