Throttle Body Removal/Installation
| CAUTION | Do not insert your fingers into the installed throttle body when you turn the ignition switch to ON (II) or while the ignition switch is in ON (II). If you do, you will seriously injure your fingers if the throttle valve is activated. |
Scheme 303
Scheme 304
- Make sure the ignition switch turned LOCK (0).
- Disconnect the MAP sensor connector (A).
- Remove the intake air duct (B).
- Disconnect the throttle body connector (C).
- Disconnect and plug the water bypass hoses (D).
- Remove the throttle body (E).
- Install the parts in the reverse order of removal with a new gasket (F), then refill the radiator with engine coolant (see «COOLANT CHECK»(ref-360063-S27042747542010042600000) ). NOTE: If it is in case of replacing or cleaning the throttle body, go to step 8. If it isn't, this proceedure is completely.
- Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard.
- Turn the ignition switch to ON (II).
- Reset the PCM with the HDS.
- Select the ETCS TEST in the INSPECTION MENU with the HDS.
- Select TP POSITION CHECK and clear the throttle position (TP) learned value.
- Turn the ignition switch to LOCK (0).
- Turn the ignition switch to ON (II), and wait 2 seconds without pressing the accelerator pedal.
- Do the PCM idle learn proceedure (see «IDLE SPEED INSPECTION»(ref-360079-S14524315512010042600000) ).
