DTC P2118: Throttle Actuator Current Range/Performance Problem Honda Crosstour I

Testing & Diagnostics 7 illustrations ~671 words

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 268

Scheme 268: DTC P2118: Throttle Actuator Current Range/Performance Problem
Scheme 268: DTC P2118: Throttle Actuator Current Range/Performance Problem

Scheme 269

Scheme 269
Scheme 269

Scheme 270

Scheme 270
Scheme 270

Scheme 271

Scheme 271
Scheme 271

Scheme 272

Scheme 272
Scheme 272

Scheme 273

Scheme 273
Scheme 273

Scheme 274

Scheme 274
Scheme 274
  1. Turn the ignition switch to ON (II).
  2. Clear the DTC with the HDS.
  3. Slowly press the accelerator pedal to the floor.
  4. Check for Pending or Confirmed DTCs with the HDS. Is DTC P2118 indicated? YES -Go to next step. NO -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the throttle body and the PCM.
  5. Turn the ignition switch to LOCK (0).
  6. Jump the SCS line with the HDS.
  7. Disconnect the throttle body 6P connector.
  8. Disconnect PCM connector B (49P).
  9. Check for continuity between PCM connector terminal B33 and throttle body 6P connector terminal No. 3. Is there continuity? YES -Go to next step. NO -Repair an open in the wire between the throttle body and the PCM (B33), then go to step 18 .
  10. Disconnect PCM connector C (49P).
  11. Check for continuity between throttle body 6P connector terminals No. 1 and No. 2. Is there continuity? YES -Repair a short in the wires between throttle body 6P connector terminal No. 2 (ETCS- line) and No. 1 (ETCS+ line), then go to step 18 . NO -Go to next step.
  12. Check for continuity between body ground and throttle body 6P connector terminals No. 1 and No. 2 individually. Is there continuity? YES -Repair a short in the wire between the throttle body 6P connector and body ground, then go to step 18 . NO -Go to next step.
  13. At the throttle body side, measure the resistance between throttle body 6P connector terminals No. 1 and No. 2 with the throttle fully closed. Is there about 1.0 ohms or less? YES -Go to next step. NO -Go to step 17 .
  14. Connect throttle body 6P connector terminals No. 1 and No. 2 with a jumper wire.
  15. Check for continuity between PCM connector terminals C2 and C3. Is there continuity? YES -Go to next step. NO -Repair an open in the wire between the throttle body and the PCM (C2, C3), then go to step 18 .
  16. At the throttle body side, check for continuity between body ground and throttle body 6P connector terminals No. 1 and No. 2 individually. Is there continuity? YES -Go to next step. NO -Go to step 26 .
  17. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(ref-360078-S26693253132010042600000) ).
  18. Reconnect all connectors.
  19. Turn the ignition switch to ON (II).
  20. Reset the PCM with the HDS.
  21. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-360079-S22847966492010042600000) ).
  22. Turn the ignition switch to LOCK (0).
  23. Turn the ignition switch to ON (II).
  24. Slowly press the accelerator pedal to the floor.
  25. Check for Pending or Confirmed DTCs with the HDS. Is DTC P2118 indicated? YES -Check for poor connections or loose terminals at the throttle body and the PCM, then go to step 1 . NO -Troubleshooting is complete. If any other Pending or Confirmed DTCs are indicated, go to the indicated DTC's troubleshooting.
  26. Reconnect all connectors.
  27. Update the PCM if it does not have the latest software (see «PCM UPDATE»(ref-360080-S11980508702010042600000) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(ref-360056-S32194616542010042600000) ).
  28. Turn the ignition switch to LOCK (0).
  29. Turn the ignition switch to ON (II).
  30. Slowly press the accelerator pedal to the floor.
  31. Check for Pending or Confirmed DTCs with the HDS. Is DTC P2118 indicated? YES -Check for poor connections or loose terminals at the throttle body and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(ref-360056-S32194616542010042600000) ), then go to step 28 . If the PCM was substituted, go to step 1 . NO -If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(ref-360080-S27881728262010042600000) ). If any other Pending or Confirmed DTCs are indicated, go to the indicated DTC's troubleshooting.
