Intake Air System (V6): Removal & Installation Honda Accord VII

Testing & Diagnostics 2 illustrations ~170 words

Throttle Body Removal/Installation

CAUTIONDo not insert your fingers into the installed throttle body when you turn the ignition switch ON (II) or while the ignition switch is ON (II). If you do, you will seriously injure your fingers if the throttle valve is activated.

Note. If you are replacing or cleaning the throttle body, begin from step 1. If you are removing the throttle body temporarily, begin from step 4 .

Scheme 698

Scheme 698
Scheme 698
  1. Connect the HDS while the engine is stopped.
  2. Select the INSPECTION MENU with the HDS.
  3. Do the TP POSITION CHECK in the ETCS TEST.
  4. Disconnect the MAP sensor connector (A).
  5. Remove the intake air duct (B).
  6. Disconnect the throttle body connector (C).
  7. Disconnect and plug the water bypass hoses (D).
  8. Remove the harness clip (E) and the throttle body (F).
  9. Install the parts in the reverse order of removal with a new gasket (G). NOTE: Do the ECM/PCM idle learn procedure after the throttle body has been replaced (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-220843-S14332728472006022100000) ). Refill the radiator with engine coolant (see «COOLANT CHECK»(ref-220837-S38798320322006022100000) ).

Scheme 699

Scheme 699: Accelerator Pedal Replacement
Scheme 699: Accelerator Pedal Replacement
  1. Remove the throttle cable (A) from the accelerator pedal (B).
  2. Remove the nuts (C) and the accelerator pedal.
  3. Install in the reverse order of removal.
