Automatic Transmission - Automatic Transaxle/transmission - External Controls: Specifications Ford Transit VII

Automatic Trans 1 illustration

TORQUE SPECIFICATIONS

DescriptionN.m
Exhaust pipe nuts47
Selector lever cable grommet nuts9
Selector lever nuts9

TORQUE SPECIFICATIONS

Overview

Scheme 1

Scheme 1: External Controls
Scheme 1: External Controls
ItemPart NumberDescription
17210Selector lever assembly
2Selector lever bezel
37L010Selector lever knob
4Transmission Control Switch (TCS) (part of 7L010)
5Selector lever cable grommet (part of 7E395)
67E395Selector lever cable
77E364Selector lever cable retaining bracket
87B229Selector lever cable bracket
9Selector lever cable adjuster (part of 7E395)
10Manual control lever

ITEM DESCRIPTION CHART

The transaxle external controls system consists of the following components

  1. Selector lever cable and bracket
  2. Transmission Range (TR) sensor
  3. Brake Shift Interlock Actuator (BSIA)
  4. Selector lever

The selector lever controls the transaxle gear selection through the selector lever cable. The cable detent and selector lever locking position is controlled by the selector lever knob.
