Automatic Transmission - Automatic Transaxle/transmission - External Controls: Removal & Installation Ford Transit VII

Automatic Trans 9 illustrations ~319 words

Installation

Pinpoint Test B

B15 ACL

Scheme 8

Scheme 8: Selector Lever
Scheme 8: Selector Lever
ItemPart NumberDescription
1Selector lever cable eyelet (part of 7E395)
2Selector lever cable retainer (part of 7E395)
37C453Selector lever assembly
4W702751Selector lever nut (4 required)
514489Selector lever electrical connector

ITEM DESCRIPTION CHART

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10
  1. Remove the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-356767) .
  2. Remove the selector lever cable from the selector lever. Move the selector lever to the PARK position. Remove the selector lever cable eyelet from the ball stud. Squeeze the tabs and remove the selector lever cable from the selector lever assembly.
  3. Disconnect the selector lever assembly electrical connector.
  4. Remove the 4 nuts and the selector lever assembly.

Scheme 11

Scheme 11
Scheme 11
  1. Install the selector lever assembly and the 4 nuts. Tighten to 9 N.m (80 lb-in).
  2. Connect the selector lever assembly electrical connector.
  3. Install the selector lever cable on the selector lever. Move the selector lever to the PARK position. Install the selector lever cable in the selector lever assembly. Install the selector lever cable eyelet on the ball stud.
  4. Install the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-356767) .
  5. Adjust the selector lever cable. For additional information, refer to «SELECTOR LEVER CABLE ADJUSTMENT»(ref-356776-S33638305092010022700000) .

Scheme 12

Scheme 12: Selector Lever Bezel
Scheme 12: Selector Lever Bezel
ItemPart NumberDescription
17348Selector lever knob screw
27213Selector lever knob
3Selector lever light
47A213Selector lever bezel

ITEM DESCRIPTION CHART

Scheme 13

Scheme 13: Removal
Scheme 13: Removal
  1. Remove the selector lever knob. For additional information, refer to «SELECTOR LEVER KNOB»(ref-356776-S31390162502010022700000) .
  2. Remove the selector lever bezel. Unclip the bezel. Unclip the lamp.

Scheme 14

Scheme 14: Installation
Scheme 14: Installation
  1. Install the selector lever bezel. Clip in the lamp. Clip in the bezel.
  2. Install the selector lever knob. For additional information, refer to «SELECTOR LEVER KNOB»(ref-356776-S31390162502010022700000) .

Scheme 15

Scheme 15: Selector Lever Knob
Scheme 15: Selector Lever Knob
ItemPart NumberDescription
17348Selector lever knob screw
27213Selector lever knob

ITEM DESCRIPTION CHART

Scheme 16

Scheme 16: Removal
Scheme 16: Removal
  1. Remove the floor console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-356767) .
  2. Disconnect the Overdrive (O/D) switch electrical connector.
  3. Remove the selector lever knob. Remove and discard the screw. Pull off the knob.

Pinpoint Test B

B3 O/D
