Special Tool(s)

SPECIAL TOOL SPECIFICATION World Diagnostic System (WDS) Vehicle Communications Module (VCM) with appropriate adapters, or equivalent diagnostic tool 73III Automotive Meter 105-R0057 or equivalent

Scheme 42

Scheme 43

SPECIAL TOOL SPECIFICATION Interior Auto Glass Cut-out Knife Kit 164-R2450 or equivalent Pneumatic Knife with Offset Blade 107-R1511 or equivalent The Pumper 164-R2459 or equivalent

Scheme 44

Scheme 45

SPECIAL TOOL SPECIFICATION Heavy Duty Riveter 501-D011 (D80L-23200-A) or equivalent

SPECIAL TOOL SPECIFICATION Heavy Duty Riveter 501-D011 (D80L-23200-A) or equivalent

Scheme 46

1. Remove the rear door trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-233716) .
2. Remove the watershield.
3. Remove the interior weatherstrip.
4. Remove the exterior weatherstrip.
5. Remove the nut and the rear window stabilizer.
6. Remove the 2 rivets retaining the rear door window glass to the rear door window glass run and bracket.
7. Remove the rear door window glass.
8. To install, reverse the removal procedure.

SPECIAL TOOL SPECIFICATION Interior Auto Glass Cut-Out Knife Kit 164-R2459 or equivalent Pneumatic Knife with Offset Blade 107-R1511 or equivalent

SPECIAL TOOL SPECIFICATION Heavy Duty Riveter 501-D011 (D80L-23200-A) or equivalent

Scheme 47

Scheme 48

1. Remove the rear door trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-233716) .
2. Remove the watershield.
3. Disconnect the rear door window regulator motor electrical connector.
4. Remove the rear door window regulator rivets.
5. Slide the rear door window regulator out of the rear door window glass run and bracket.
6. Remove the rear door window regulator.
7. Remove the bolts and the window regulator motor.
8. To install, reverse the removal procedure.

Scheme 49

1. Remove the rear door trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-233716) .
2. Remove the watershield.
3. Remove the rear door window glass to the rear door window glass run and bracket rivets.
4. Raise and support the rear door window glass to its full closed position.
5. Remove the rear door window glass run and bracket nuts.
6. Slide the rear window regulator out of the rear door window glass run and bracket and position aside.
7. Remove the rear door window glass run and bracket.
8. To install, reverse the removal procedure.

SPECIAL TOOL SPECIFICATION Heavy Duty Riveter 501-D011 (D80L-23200-A) or equivalent

Scheme 50

1. Remove the front door window glass. For additional information, refer to «FRONT DOOR WINDOW GLASS»(ref-233710-S35182511732006052600000) .
2. Disconnect the front door window regulator motor electrical connector.
3. Remove the window regulator rivets.
4. Remove the front door window regulator.
5. Remove the bolts and the window regulator motor.
6. To install, reverse the removal procedure.

SPECIAL TOOL SPECIFICATION Interior Auto Glass Cut-Out Knife Kit 164-R2450 or equivalent Pneumatic Knife with Offset Blade 107-R1511 or equivalent The Pumper 164-R2459 or equivalent

SPECIAL TOOL SPECIFICATION Heavy Duty Riveter 501-D011 (D80L-2300-A) or equivalent

Scheme 51

Scheme 52

1. Remove the front door window glass. For additional information, refer to «FRONT DOOR WINDOW GLASS»(ref-233710-S35182511732006052600000) .
2. Remove the exterior rear view mirror. For additional information, refer to «REAR VIEW MIRRORS»(ref-233768) .
3. Remove the front door window glass top run rivets.
4. Remove the front door window glass top run bolts.
5. Remove the front door window glass top run.
6. To install, reverse the removal procedure.

SPECIAL TOOL SPECIFICATION Heavy Duty Riveter 501-D011 (D80L-2300-A) or equivalent

Scheme 53

1. Remove the rear door window glass. For additional information, refer to «REAR DOOR WINDOW GLASS»(ref-233710-S22324462992006052600000) .
2. Remove the rear door window glass top run bolt.
3. Remove the rear door glass top run.
4. To install, reverse the removal procedure.
